- Page 1 Product Replacement on a Prorated Basis Knife Grommets Warranty Limitations Drop Down Utility Pocket Features Double Cylinder Setup - Using Apeks Twin Tank Kit Basic Setup Pre-dive Inspection Attaching the MP Hose to the First Stage BC Inspection Checklist GripLock™ Cylinder Band Components Post-dive Care and Maintenance Threading the GripLock™...
-
Page 2: Copyright Notice
This manual is copyrighted, all rights reserved. It may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine-readable form without prior consent in writing from Apeks. It may not be distributed through the internet or computer bulletin board systems without prior consent in writing from Apeks. -
Page 3: Safety Information
This manual provides essential instruction for the proper fitting, adjustment, inspection and care of your new BC. Because Apeks is utilizing patented BC technology, it is very important to take the time to read these instructions in order to understand and fully enjoy the features that are unique to your specific model. - Page 4 U.S. Coast Guard regulations for a life preserver or personal flotation device (PFD). If you become unconscious in the water without a buddy present to immediately give assistance, you may suffer serious injury or death from drowning. © 2014 Apeks...
- Page 5 If you have any questions regarding your Buoyancy Compensator or the information found in this manual, please contact your regional Apeks Dealer or Distributor. Distributor information is available on the Apeks website at: www.apeks.co.uk...
-
Page 6: Dealer Inspection And Service
Authorized Apeks Dealer or Distributor. NOTE: It is important to obtain prescribed dealer service for your BC at least once annually, from an Authorized Apeks Dealer or Distributor. Your personal safety and the mechanical integrity of your BC depends on it. © 2014 Apeks... - Page 7 Table of Contents ANNUAL SERVICE & INSPECTION RECORD Purchase Date: Store Name: Country: BC Model: Serial Number: Black Ice serial # is located on Black Ice serial # tag in pocket. DATE DEALER NAME CITY, STATE COUNTRY TECH INITIALS © 2014 Apeks...
-
Page 8: Warranty Information
Apeks warrants to the original purchaser for the useful life of the product, from the date of purchase, that the product will be free from defects in materials and workmanship, provided that it receives normal use, proper care and prescribed dealer service subject to the limitations listed below. -
Page 9: Warranty Limitations
This warranty gives you specific legal rights. You may have rights which vary from state to state and country to country. APEKS DISCLAIMS AND EXCLUDES ANY LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES IN THE U.S. AND CERTAIN FOREIGN COUNTRIES DO NOT ALLOW EXCLUSIONS OR LIMITATIONS OF LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAG- ES, SO THIS MAY NOT APPLY TO YOU. - Page 10 The BC waistband has a simple to use, quick release clip. Web-slides allow for ease of adjustment by simply pulling forward on the waistband D-rings. The D-rings can easily be removed from the web-slides for extra waist adjustment. © 2014 Apeks...
- Page 11 A drop down utility pocket provides additional space for dive accessories such as lights, masks, etc. to be stored securely. Removable Back Pad The back pad in the Black Ice is considered optional and can be removed. It is held in place by simple hook and loop attachments. Knife Grommets Located on the left side pocket are two grommets which can accommodate an optional knife.
-
Page 12: Basic Setup
Apeks recommends that you bring your buoyancy compensator, together with your regulator, to your Authorized Apeks Dealer or Distributor for the installation of the MP inflator hose and other accessories. The retailer can also answer any questions you may have pertaining to the information in this manual. -
Page 13: Attaching The Mp Hose To The First Stage
3. Check to ensure the o-ring is present and in good condition. Screw the threaded end of the hose into the port and tighten to 40 in-lbs. (4.5 Nm) with a 9/16” wrench. © 2014 Apeks... -
Page 14: Griplock™ Cylinder Band Components
Insert the open end of the cylinder band into the large opening of the bail, around the slide bar and out the small opening of the bail. Secure the hook and loop on the band to hold the bail on place. © 2014 Apeks... -
Page 15: Adjusting The Griplock™ Cylinder Band
1. There are three macro settings for cylinder size. A. Larger cylinder B. Al 80 cf (7.25 in/184 mm) C. Smaller cylinder 2. Adjust the macro adjustment for the proper cylinder size. 3. Secure the hook and loop after cylinder size is selected. © 2014 Apeks... -
Page 16: Securing The Griplock™ Cylinder Band
BC straight, parallel with the cylinder. NOTE: Over-tightening the valve strap can result in the BC being drawn in towards the cylinder which may be uncomfortable to wear. © 2014 Apeks... - Page 17 The pre-locked position ensures your fingers do not get caught in the lever. 4. Push the lever down into the locked position. Verify the lever is secured in the locked position. Once the cylinder band is set up, further adjustment is typically not needed. © 2014 Apeks...
-
Page 18: Donning And Adjustment Procedures
BC lobe, fully extend each torso strap to its maximum length by pushing straight up on the slide buckle. 4. While your dive buddy lifts and holds the BC/cylinder behind you, place your arms through the BC torso straps as if you were putting on a jacket. © 2014 Apeks... - Page 19 Adjusting the shoulder straps too tightly will transfer the cylinder weight from the hips to the shoulders, restricting your arm movement and decreasing comfort. 8. If necessary, readjust the waist buckle and chest strap so that they are comfortably snug, but not restricting. © 2014 Apeks...
- Page 20 Hold the nut securely with a 3/8” box wrench and tighten the bolt with a medium size Phillips screwdriver. 4. Don the BC over your exposure suit to check the fit. © 2014 Apeks...
- Page 21 Phillips screwdriver. 5. Secure hoop and loop cover. Slide the shoulder retainer sleeve back in place and connect shoulder strap buckle. 6. Don the BC over your exposure suit to check the fit. © 2014 Apeks...
- Page 22 The chest strap on your BC is removable. To remove the chest strap, unweave the straps from the male and female parts of the chest buckle. For each strap, pull the free end through the plastic rings connected to the strap. Pull the strap through the plastic rings that are connected to the BC. © 2014 Apeks...
-
Page 23: Weight Integration Features
Refer to the model-specific label, usually found in the pocket of your BC, to find the designated lift capacity, and load weight pouches accordingly (see photo above). © 2014 Apeks... - Page 24 Loading Weight into the SureLock II™ Weight Pouches Apeks recommends that each pouch is loaded with equal amounts of weight for optimum balance, preventing the tendency to roll to one side during the dive. Also, it is strongly recommended that each weight pouch is fully loaded with four separate block weights.
- Page 25 & loop (c). Apeks recommends that the pouches be completely filled with four separate block weights (two per compartment); however, if you need to partially fill the pouch, load the bottom compartment first. Use the diagram for proper weight placement.
- Page 26 Table of Contents Loading Soft Weight into the SureLock II™ Weight Pouches Apeks recommends block weights be used in the SureLock II weight pouch for the best fit and ease of insertion. Soft weights may be used, but it is critical that the weights be loaded and secured correctly.
-
Page 27: Installing The Surelock Ii™ Weight Pouches On Your Bc
Installing the SureLock II™ Weight Pouches on your BC CAUTION: Apeks strongly recommends that you do not attempt to don your BC when it is fully loaded with weight. You may otherwise risk injury due to muscle strain or a temporary loss of balance. -
Page 28: Releasing Surelock Ii™ Weight Pouches
To avoid injuring other divers, always look below you before dropping weight. NOTE: In addition to becoming familiar with the weight system yourself, it is very important to explain its function to your dive buddy so that he/she is equally familiar with it. © 2014 Apeks... -
Page 29: Non-Releasable Weight
(trim) pockets after the BC has been secured to the cylinder. The non-releasable weight pockets are designed to hold single rectangular block weights. To avoid accidental loss of weight, Apeks strongly advises against using small bullet-shaped weights and shot weight. -
Page 30: Inflation Methods Using A Powerline Inflator
While continuing to exhale into the mouthpiece, depress the oral inflator button (b) to inflate the BC. Immediately after exhaling, release the oral inflator button to prevent air from escaping. © 2014 Apeks... -
Page 31: Deflation Via Oral Inflator
You can vent air from the BC by firmly pulling straight down on the power inflator. This dump valve provides an effective and convenient way to vent air from the BC while in either an upright or facedown swimming position. © 2014 Apeks... - Page 32 To dump air as quickly as possible, always use the flat valve at the highest point in the water column. For example, the lower rear valve work best while making a headfirst descent, or swimming in a facedown position; the right shoulder valve works best when in an upright position. Flat Valve © 2014 Apeks...
-
Page 33: Special Features
SPECIAL FEATURES Knife Grommets Your BC has two grommet holes designed to accept many of the specialty BC knives available from Apeks. For information on available knife models, consult with your Apeks Authorized Dealer or Distributor. To attach or remove the knife and sheath from the BC, refer to the instructions provided with the knife. - Page 34 Table of Contents SPECIAL FEATURES Drop Down Utility Pocket Your BC has a drop down utility pocket to provide additional space for dive accessories such as lights, masks, etc. to be stored securely. © 2014 Apeks...
- Page 35 SPECIAL FEATURES Double Cylinder Setup - Using Apeks Twin Tank Kit The Black Ice Twin Tank Kit (P/N 427106) allows mounting of twin cylinders to your BC in all sizes. Please see mounting instructions provided with the kit. Before adapting your BC for use with double cylinders, it is important to compare the lift capacity of your particular BC size and model with the buoyancy specifications of the cylinders, the amount of weight you will carry, and the type of exposure suit you will wear.
-
Page 36: Pre-Dive Inspection
WARNING: If you can hear any leaks, or if the bladder begins to deflate within 10 minutes, DO NOT attempt to use the BC until it has received service from an Authorized Apeks Dealer or Distributor. 4. Make a final check of the cylinder band’s tension to ensure that it is securely fastened to the cylinder. -
Page 37: Post-Dive Care & Maintenance
After rinsing, inflate the BC, and allow it to dry inside and out. Store the BC partially inflated, away from direct sunlight and in a clean, dry area. Do not store the BC in an enclosed space, such as a car trunk, where temperatures may fall below 0ºF (-18ºC) or rise above 120ºF (49ºC). © 2014 Apeks...
