- Page 1 Model ST-15S1 User Guide DAB / FM / AM Tuner...
- Page 2 DEUTSCH dovuti ad uso continuato a fini professionali. GARANTIE Bei Garantiefragen wenden Sie sich bitte an Ihren Marantz-Händler. HEBEN SIE IHRE QUITTING GUT AUF Die Quittung dient Ihnen als bleibende Unterlage für Ihren wertvollen Einkauf Das Aufbewahren der Quittung ist wichtig, da die darin enthaltenen Angaben für Versicherungswecke oder bei Korrespondenz...
- Page 3 - Keine Gegenstände durch die Belüftungsschlitze stecken. Français - Das Netzkabel nicht mit feuchten oder nassen Händen anfassen. Le ST-15S1 est conforme à la directive EMC et à la directive sur - Decken Sie die Lüftungsöffnungen nicht mit einem Tischtuch, einer les basses tensions.
-
Page 4: Table Of Contents
CONTENTS FEATURES .............................1 BEFORE USE ............................2 PART NAMES AND FUNCTIONS ......................3 FRONT PANEL ..............................3 REAR PANEL..............................4 CONNECTIONS............................5 CONNECTING THE ANTENNA TERMINALS ....................5 CONNECTING THE AMPLIFIER ........................6 OPERATION ............................7 LISTENING TO FM/AM ............................7 LISTENING TO DAB BROADCAST .........................13 SEARCH MODE ...............................15 SORT MODE (SORTING COMPONENTS) .....................16 OTHER OPERATION ...........................18 LAST FUNCTION MEMORY ..........................18... -
Page 5: Before Use
Note For heat dispersal, do not install this equipment in a Your Marantz product has been prepared to comply with the confined space such as a book case or similar unit. household power and safety requirements that exist in your area. -
Page 6: Part Names And Functions
Memo Some of the functions can be operated with the remote • Please be sure to unplug the cord when you leave home control unit (Accessory of Marantz’s integrated amplifier for, say, a vacation. PM-11/15 series etc.). • Noise may be generated if a near-by television set is on during AM, FM or DAB broadcasting reception. -
Page 7: Rear Panel
This is used for connection to external data or a connectors on a Marantz equipment, set the switch to computer to access services that will likely be added in EXTERNAL. -
Page 8: Connections
CONNECTIONS CONNECTING THE ANTENNA TERMINALS 7 Connecting a DAB outdoor antenna • If good reception cannot be achieved with the included DAB indoor antenna, use a DAB outdoor antenna. Connect an F male type connector to the coaxial cable and connect the antenna to the DAB COAX 75 Ω/ohms terminal. 7 Installing the DAB indoor antenna q DAB station reception ( page 13). -
Page 9: Connecting The Amplifier
CONNECTIONS 7 Connecting the optical output CONNECTING THE AMPLIFIER connector Note • If you want to enjoy listening to the digital output audio of Use an optical digital connecting cable available on the the DAB, connect to an amplifier outfitted with a digital market. -
Page 10: Operation
C1 ~ C10 90.1 MHz D1 ~ D10 90.1 MHz E1 ~ E10 90.1 MHz F1 ~ F10 90.1 MHz G1 ~ G10 90.1 MHz DAB/FM/AM TUNER ST-15S1 DAB/FM/AM TUNER ST-15S1 H1 ~ H10 90.1 MHz DISPLAY DISPLAY MENU MENU TUNED TUNED... - Page 11 • To preset other channels, repeat steps 2 to 6. • A total of 100 broadcast stations can be preset — 10 stations (channels 1 to 10) in each of groups A to J. DAB/FM/AM TUNER ST-15S1 DAB/FM/AM TUNER ST-15S1 DISPLAY...
- Page 12 • RT allows the RDS station to send text messages that appear on the display. Note • The following RDS functions are not applicable where there is no RDS signal, and pressing the DISPLAY button q will not alter display. DAB/FM/AM TUNER ST-15S1 DAB/FM/AM TUNER ST-15S1 DISPLAY DISPLAY MENU MENU...
-
Page 13: Pty Search
• The station name is displayed on the display after searching stops. • If no other station broadcasting the designated program type is found when all the frequencies are searched, “NO programme” is displayed. DAB/FM/AM TUNER ST-15S1 DAB/FM/AM TUNER ST-15S1 DISPLAY DISPLAY MENU... - Page 14 The program type of the tuned in broadcast is displayed. r CT: The current time is displayed. • When the “STATION NAME” is not registered, q is not displayed. DAB/FM/AM TUNER ST-15S1 DAB/FM/AM TUNER ST-15S1 DISPLAY DISPLAY MENU MENU TUNED...
- Page 15 Use the procedure described at “Auto tuning”, “Manual tuning” or “Recalling preset stations” to tune in the desired frequency. Example: To register “MARANTZ” as the FM station name at preset channel “A2”. Press the MENU button !4 to select menu.
-
Page 16: Listening To Dab Broadcast
OPERATION LISTENING TO DAB BROADCAST 7 About DAB (Digital Audio Broadcasting) • Since the DAB system is broadcasted in digital format, DAB system can supply crystal-clear audio and stable reception even in mobile objects. DAB is a new generation radio which can provide data service and supplementary multi-media services. •... -
Page 17: Preset Stations
( page 5). You may want to re-tune at a later date if you move the ST-15S1 or if you want to receive a newly introduced ensemble. Press the AUTO TUNE button e. Turn the GYRO TUNING dial !1 to select the station. -
Page 18: Search Mode
• The search mode at this time is set to “Sorted list search mode”. Press the ENTER button !3 to display the first channel at Preset. • You can select any component from the preset. DAB/FM/AM TUNER ST-15S1 DAB/FM/AM TUNER ST-15S1 DISPLAY DISPLAY MENU... -
Page 19: Sort Mode (Sorting Components)
Press the ENTER button !3 to set the sort mode. Turn the GYRO TUNING dial !1 to select “Sort Mode (S. Component)”. DAB/FM/AM TUNER ST-15S1 DAB/FM/AM TUNER ST-15S1 Press the ENTER button !3 to set the sort mode to “Sort... - Page 20 Bit Error Rate : Noise may be generated and reception quality may become poor at bit error rates above 0.05. If a rate above 0.05 is displayed, move the antenna in DAB/FM/AM TUNER ST-15S1 DAB/FM/AM TUNER ST-15S1 DISPLAY DISPLAY...
-
Page 21: Other Operation
• If step 3 does not work,start over from step 1. • If the microprocessor has been initialized all the button settings are reset to the default values (the values set upon shipment from the factory). DAB/FM/AM TUNER ST-15S1 DAB/FM/AM TUNER ST-15S1 DISPLAY DISPLAY... -
Page 22: Convenient Feature
CONTROLLER This button is used to select radio presets or select stations and menu options. ST-15S1 can be controlled by the remote controller supplied with Marantz integrated amplifier PM-11/15 series. You can x 1, ¡ buttons (TUNING buttons) perform following operations using the controller. -
Page 23: Troubleshooting
DAB stations start broadcasting. station name. I hear a burbling sound on • DAB like other digital media is good • Use the ST-15S1’s “Tuning aid” while some stations. at producing quality audio from a low repositioning your antenna to get the... -
Page 24: Specifications & Dimensional Drawings
Channel separation ........100 dB (1 kHz) Registration Card ............1 Selectivity ......40 dB (at adjacent channel) * For purposes of improvement, specifications and design are subject to change without notice. 440.0 DAB/FM/AM TUNER ST-15S1 DAB/FM/AM TUNER ST-15S1 DISPLAY DISPLAY MENU MENU... -
Page 25: Others
In the event of difficulty, refer to your dealer or write directly wool, scouring powders or harsh chemical agents (e.g., lye to the nearest location to you that is listed on the Marantz solution), alcohol, thinner, benzine, insecticide or other Authorized Service Station list. - Page 26 You can find your nearest authorized distributor or dealer on our website. is a registered trademark. Printed in China 08/2006 00M22CW851310 mzh-d...
