Nortec GS Installation Manual page 76

Air Inlet
ø
6 in
(150 mm)
Figure 38:
Product Specifications
70
50.8
(1290)
32.7
(830)
Exhaust Outlet*
ø
150 mm - GS 450-CS/NX
62.2
(1580)
Power In
ø
3/4 in (19 mm)
Nortec GS 450
32.3
(821)
Steam Outlet
ø
4 in (100 mm)
4.3
(108)
* Metric to imperial size adaptor supplied with unit
** BSPP to NPT adaptor supplied with unit
*** 1-1/4 in to 1 in NPT adaptor supplied with unit
2583703_EN_1608
27.7
1.6
(705)
(42)
Gas Inlet***
1 in NPT
Water Inlet**
3/4 in BSPP
1.0
(25)
Drain Outlet
7/8 in (23 mm)
Condensate Outlet
(CS/NX only)
1/2 in (13 mm)
Nortec GS
ø
ø
