5.10.2 Permissible Control Signal Inputs

Table 17
shows the different permissible control signal inputs the Nortec GS humidifier can handle.
Table 17: Permissible Control Signal Inputs
Humidity Control with External Con-
troller Control Signals
0-5 VDC (potentiometer 135-10kΩ)
Humidistat (24 V On/Off)
Installation
54
1-5 VDC
0-10 VDC
2-10 VDC
0-20 VDC
0-16 VDC
3.2-16 VDC
0-20 mA
4-20 mA
Humidity Control with Internal PI
Controller Humidity Sensor Signals
0-5 VDC (potentiometer 135-10kΩ)
1-5 VDC
0-10 VDC
2-10 VDC
0-20 VDC
0-16 VDC
3.2-16 VDC
0-20 mA
4-20 mA
2583703_EN_1608
Digital Inputs (via Modbus,
BACnet IP/MSTP slave)
BACnet IP
BACnet MSTP Slave
Modbus
Lonworks (Option)
BACnet MSTP BTL Certified (Option)
BACnet IP BTL Certified (Option)
