Preflight Checklist - dji Mavic pro User Manual

GPS Signal Strong
Flight Limits
Maximum Flight Aircraft's altitude cannot
Altitude exceed the specified value.
Flight distance must be within
Max Radius
the max radius.
GPS Signal Weak
Flight Limits
Height is restricted to 16 feet (5
meters) when the GPS signal is
Maximum weak and Downward Vision System
Flight is activated. Height is restricted
Altitude to 164 feet (50 meters) when the
GPS signal is weak and Downward
Vision System is inactivated.
Max Radius No limits
If the aircraft flies out of the limit, you can still control the aircraft, but you cannot fly it any farther.
If the aircraft flies out of the max radius, it will fly back within range automatically when
GPS signal is strong.
For safety reasons, please do not fly close to airports, highways, railway stations, railway lines,
city centers, or other sensitive areas. Fly the aircraft only within your line of sight.
No-Fly Zones
All No-Fly Zones are listed on the DJI official website at http://www.dji.com/flysafe/no-fly. No-Fly
Zones are divided into Airports and Restricted Areas. Airports include major airports and flying
fields where manned aircraft operate at low altitudes. Restricted Areas include border lines between
countries or sensitive institute.

Preflight Checklist

1. Remote controller, Intelligent Flight Battery, and mobile device are fully charged.
2. Propellers are mounted correctly and firmly.
3. Micro SD card has been inserted, if necessary.
4. Gimbal is functioning normally.
5. Motors can start and are functioning normally.
6. The DJI GO app is successfully connected to the aircraft.
7. Ensure that the sensors for the Forward and Downward Vision System are clean.
Blinking Green
Blinking Yellow
DJI GO App Aircraft Status Indicator
Warning: Height
None.
limit reached.
Rapid red flashing
Warning: Distance
when close to the max
limit reached.
radius limit.
DJI GO App
Warning: Height limit
reached.
©
Mavic Pro User Manual
Aircraft Status Indicator
None.
2016 DJI All Rights Reserved.
49
