Battery Level Indicators While Charging
LED1 LED2
Battery Protection LED Display
The table below shows battery protection mechanisms and corresponding LED patterns.
Battery Level Indicators while Charging
LED1 LED2 LED3
After these issues are resolved, press the Power Button to turn off the Battery Level Indicator. Unplug the
Intelligent Flight Battery from the charger and plug it back in to resume charging. You do not need to un-
plug and plug in the charger in the event of a room temperature error; the charger will resume charging
when the temperature is within the allowable range.
DJI does not take any responsibility for damage caused by third-party chargers.
How to discharge the Intelligent Flight Battery before transport the batteries for long trip:
Fly the Mavic Pro outdoors until there is less than 20% of power left, or until the battery can no
longer be turned on.
LED3 LED4
LED4 Blinking Pattern
LED2 blinks twice per second
LED2 blinks three times per second Short circuit detected
LED3 blinks twice per second
LED3 blinks three times per second Over-voltage charger detected
LED4 blinks twice per second
LED4 blinks three times per second Charging temperature is too high
Mavic Pro User Manual
Battery Level
0%~25%
25%~50%
50%~75%
75%~100%
Fully Charged
Battery Protection Item
Over current detected
Over charge detected
Charging temperature is too low
©
