dji Mavic pro User Manual page 28

Mavic Pro User Manual
Battery Level Indicators
LED1 LED2
Charging the Intelligent Flight Battery
1. Connect the Battery Charger to a power source (100-240V, 50/60Hz).
2. Connect the Battery to the Charger to start charging.
3. The Battery Level Indicator will display the current battery level as it is charging.
4. The Intelligent Flight Battery is fully charged when the Battery Level Indicators are all off. Detach the
battery from the Charger.
5. Allow battery temperature to drop to room temperature before storing for an extended period.
6. The charger will stop charging the battery if the battery cell's temperature is not within the operating
range (5°C to 40°C).
Always turn off the battery before inserting it or removing it from the Mavic Pro. Never insert or
remove a battery when it is turned on.
Intelligent Flight Battery
28
©
2016 DJI All Rights Reserved.
LED3 LED4 Battery Level
87.5%~100%
75%~87.5%
62.5%~75%
50%~62.5%
37.5%~50%
25%~37.5%
12.5%~25%
0%~12.5%
=0%
Charger
Power Outlet
