dji Mavic pro User Manual page 27

Using the Battery
Battery Level Indicators
Turning ON/OFF
Turning On: Press the Power Button once, then press again and hold for 2 seconds to turn on. The remote
controller system status screen will display the current battery level.
Turning Off: Press the Power Button once, then press again and hold for 2 seconds to turn off.
Low Temperature Notice:
1. Battery capacity is significantly reduced when flying in low temperature (-10°C and 5°C) environments.
2. Batteries cannot be used in extremely low temperature (< -10°C) environments.
It is recommended to fully charged the battery when taking off in temperature between -10°C and 5°C.
3. End the flight as soon as the DJI GO app displays the "Low Battery Level Warning" in low temperature
environments.
4. Keep the battery indoors to warm it before flying in low temperature environments.
5. To ensure optimal performance of the battery, keep the battery temperature above 20°C.
In cold environments, insert the battery into the battery compartment and turn on the aircraft for
approximately 1-2 minutes to warm up before taking off.
Checking the Battery Level
The Battery Level Indicators display how much power remains. When the battery is turned off, press the
Power Button once, the Battery Level Indicators will light up to display the current battery level. See below
for details.
The Battery Level Indicators will also show the current battery level during charging and
discharging. The indicators are defined below.
: LED is on.
: LED is off.
: LED is flashing.
Mavic Pro User Manual
LED1
LED2
LED3
LED4
Power Button
©
2016 DJI All Rights Reserved.
27
