PELLET STOVES Contents INSTALLATION AND USE MANUAL page LED 1 SIGNALS DURING OPERATION..................34 4.17. ALARM SIGNALLING ........................34 4.18. Shutdown mode due to alarm.....................35 4.19. 5. MAINTENANCE AND CLEANING ......................36 DAILY AND WEEKLY CLEANING BY THE USER.................36 5.1. Before each lighting........................36 5.1.1.
PELLET STOVES Chapter 1 INSTALLATION AND USE MANUAL page INTRODUCTION Dear Customer, We wish to thank you for choosing one of our products, specifically a stove from the Pellet line. Products built with Oyster technology, thanks to a perfectly sealed frame, do not consume oxygen by taking all the air from the environment outside so therefore can be placed inside every home properly insulated and within passive houses.
Page 5
PELLET STOVES Chapter 1 INSTALLATION AND USE MANUAL page SYMBOLS USED IN THE MANUAL ATTENTION This warning sign indicates that the message to which it refers should be carefully read and understood, because failure to comply with what these notices say can cause serious damage to the stove and put the user's safety at risk.
PELLET STOVES Chapter 1 INSTALLATION AND USE MANUAL page 1. WARNINGS AND GUARANTEE CONDITIONS SAFETY INSTRUCTIONS 1.1. Installation of the stove, making the electrical connections, checking operation, maintenance are all tasks which should be carried out by qualified and authorised personnel. ...
PELLET STOVES Chapter 1 INSTALLATION AND USE MANUAL page the supply cable before doing anything to the unit. Before carrying out any cleaning or maintenance operation, make sure in advance that the stove is disconnected from the mains electricity supply, by turning off the main switch located on the back of the stove, or by unplugging the supply cable.
PELLET STOVES Chapter 1 INSTALLATION AND USE MANUAL page INFORMATION For any problems, please contact your dealer or company qualified and authorised personnel and always request original spare parts for repairs. Only use the fuel recommended by the company (for ITALY only 6mm diameter pellets whereas for the other European countries, pellets with a diameter of 6-8 mm) and only supplied by the automatic feed system.
PELLET STOVES Chapter 1 INSTALLATION AND USE MANUAL page manufacturing defects. 1.4.1. Limitations The above guarantee does not cover components relating to electrical and electronic parts, or fans, on which the guarantee period is 1 year from the purchase of the product, documented as specified above. The guarantee does not cover parts subject to normal wear such as gaskets, glass, and any parts with can be removed from the firebox.
PELLET STOVES Chapter 2 INSTALLATION AND USE MANUAL page 2. Theoretical notions for installation Pellets 2.1. Wood pellets are manufactured by hot-extruding compressed sawdust which is produced during the working of natural dried wood. The compactness of the material comes from the lignin which is contained in the wood itself, and allows the production of pellets without the use of glues or binders.
PELLET STOVES Chapter 2 INSTALLATION AND USE MANUAL page The company strongly recommends the use of certified fuel for its stoves (DINplus and Ö-Norm M7135). The use of fuel of inferior quality or not conforming to the specification given above compromises the running of your stove and can therefore lead to the termination guarantee...
PELLET STOVES Chapter 2 INSTALLATION AND USE MANUAL page OPERATING AREA 2.3. If installing together with other heating equipment, provide suitable air intakes for each (according the indications of each product). It is not permissible to install the stove in bedrooms, bathrooms, or in a room where another heating appliance is installed (fireplace, stove etc.) which does not have its own independent air intake.
PELLET STOVES Chapter 2 INSTALLATION AND USE MANUAL page CONNECTION TO THE COMBURENT AIR INLET 2.4. PIPE (1) Pipes and unions with suitable gaskets must always be used, to guarantee a hermetic seal. Products built with Oyster technology, thanks to a perfectly sealed frame, do not consume oxygen by taking all the air from the environment outside so therefore can be placed inside every home properly insulated and within passive houses.
Page 14
PELLET STOVES Chapter 2 INSTALLATION AND USE MANUAL page Pipes and unions with suitable gaskets must always be used, to guarantee a hermetic seal (class P1, reference standard EN 1856-2). All sections of the smoke duct must be inspectable and removable to enable periodic internal cleaning.
PELLET STOVES Chapter 2 INSTALLATION AND USE MANUAL page CONNECTION TO THE FLUE PIPE 2.6. The flue pipe must have internal dimensions not larger than 20 x 20 cm, or diameter 20 cm. In the event of larger dimensions, or of the flue pipe being in poor condition (for example cracks, poor insulation, etc.), it is advisable to fit a stainless steel pipe of suitable diameter inside the flue pipe throughout its length, right up to the top.
PELLET STOVES Chapter 2 INSTALLATION AND USE MANUAL page OPERATING PROBLEMS CAUSED BY DRAUGHT 2.9. DEFECTS IN THE FLUE E.g. Downdraft at 45° of 8m/sec. Overpressure of 17 Of all the weather and geographical conditions which affect the operation of a flue pipe (rain, fog, snow, altitude a.s.l., exposure to E.g.
PELLET STOVES Chapter 3 INSTALLATION AND USE MANUAL page 3. INSTALLATION AND ASSEMBLY DRAWINGS AND TECHNICAL CHARACTERISTICS 3.1. 3.1.1. DALIA OYSTER 113 176 166 Installation and assembly Technical service - Rights reserved - Reproduction prohibited...
PELLET STOVES Chapter 3 INSTALLATION AND USE MANUAL page 3.1.2. Technical characteristics Technical characteristics DALIA OYSTER Overall thermal power Max. 5,4 kw / 4644 kcal/h Overall thermal power Min. 2.3 kw / 1978 kcal/h Yield at maximum 93,4 % Yield at minimum...
INSTALLATION AND USE MANUAL page PREPARATION AND UNPACK ING 3.2. The DALIA OYSTER stove is delivered in one sole package formed Structure packaging Side and top packaging (Fig.1) Open the packaging, remove the four screws that secure the base of...
Page 20
PELLET STOVES Chapter 3 INSTALLATION AND USE MANUAL page If the smoke outlet of the stove is forced or used improperly to lift it or position it, the operation of the stove can be damaged irreparably. 1. Turn the feet clockwise to lower the stove 2.
PELLET STOVES Chapter 3 INSTALLATION AND USE MANUAL page LATERAL CLADDING ASSEMBLY 3.3. Installation of steel sides (DALIA) Take the side “C” (make sure the underside slots into pin “D”) and secure it to the top sheet of the stove using the two screws “E and F” provided.
PELLET STOVES Chapter 4 INSTALLATION AND USE MANUAL page 4. OPERATION PRE-LIGHTING WARNINGS 4.1. Do not touch the stove during the first lighting, as it is during this phase that the paint sets. If you touch the paint, you may expose the steel surface. If necessary, touch up the paint with the aerosol spray in the original colour (see the section "Accessories for pellet stoves").
PELLET STOVES Chapter 4 INSTALLATION AND USE MANUAL page PRE-LIGHTING CHECK 4.2. Check that all the safety conditions described above have been met. Make sure you have read and completely understood the contents of this instruction booklet. Remove any components which might burn from the firebox and from the glass (various instructions and adhesive labels).
The 5 leds over key E (0/-1/-2/+1/+2) also light up to signal alarms. In the event of an alarm, LED 1 will flash red, an acoustic signal will be emitted and the type of alarm will be displayed by the corresponding LEDs.
Page 25
PELLET STOVES Chapter 4 INSTALLATION AND USE MANUAL page A. Ventilation regulation knob E. Pellet load key B. Temperature regulation knob Led 1. Multi-colour on/off led C. Flame regulation knob Led -2/-1/0/+1/+2 Pellet load level or alarm signal. D. Ignition and shutdown button (ON/OFF) Operation Technical service - Rights reserved - Reproduction prohibited...
PELLET STOVES Chapter 4 INSTALLATION AND USE MANUAL page STOVE POWER SUPPLY 4.5. Once the power cord is connected to the rear part of the stove, place the switch, also on the rear, to position (I). The lighted button of the switch will come on. The switch located to the rear of the stove powers the system.
PELLET STOVES Chapter 4 INSTALLATION AND USE MANUAL page 4.7.3. Setting the hot air fan speed (Knob A) Using command A the hot air fan speed can be regulated. The fan starts to work when the stove has reached a default (factory setting) temperature value.
PELLET STOVES Chapter 4 INSTALLATION AND USE MANUAL page CHOOSING THE TYPE OF PELLET LOAD (Key E) 4.9. This operation allows the user to set the stove in the best way based on the type of pellet available. This prevents fuel waste, ensures expected heating ability and protects the condition of the product.
PELLET STOVES Chapter 4 INSTALLATION AND USE MANUAL page 4.11. VIEWING THE FLAME In order to obtain good operation from the stove, you need to know how to "read" the flame. The characteristics that the user needs to pay attention to are the basically: ...
PELLET STOVES Chapter 4 INSTALLATION AND USE MANUAL page 4.12. Connection to a room thermostat The room thermostat is not included with the stove and it must be installed by a specialised technician. WARNING! The electrical wires must not be in contact with the hot parts of the stove.
PELLET STOVES Chapter 4 INSTALLATION AND USE MANUAL page To make the stove work according to the temperature set on the external thermostat it is necessary to bring knob (B) to the minimum position (15°C). Please remember that once the temperature is reached, the stove does not switch off but automatically modulates the flame and room fan to minimum power.
Connection programmable timed 4.15. thermostat (optional RED accessory) The room timer is not included with the stove. The user is responsible for fitting this part. Refer to the instructions given in the optional programmable timed thermostat for information on how to install it.
PELLET STOVES Chapter 4 INSTALLATION AND USE MANUAL page 4.16. SAFETY DEVICES The stove is fitted with the following safety devices: MAIN STOVE POWER SUPPLY SAFETY The stove is protected by a fuse which is near to the switch (I). ...
The 5 leds over keyE (0/-1/-2/+1/+2) also light up to signal alarms. In the event of alarm, Led 1 will flash red, there will be warning tone and the type of alarm is identified by one of the five corresponding Leds.
PELLET STOVES Chapter 4 INSTALLATION AND USE MANUAL page TYPE OF PROBLEM SOLUTION SIGNALLING Led -2 Stove door open Close the door Led -1 Draught difficulties or clogging of grate. Led -1 Check whether the grate is clogged by incrustation and Pressure gauge clean as required.
PELLET STOVES Chapter 5 INSTALLATION AND USE MANUAL page 5. MAINTENANCE AND CLEANING ATTENTION! All cleaning of all parts must be carried out with the stove completely cold and unplugged. The stove does not need much maintenance if used with certified quality pellets.
It is good practice to provide plenty of ventilation in the room when cleaning the stove. CLEANING THE DALIA OYSTER STOVE EXCHANGER: While the stove is cold, open the door, remove the plate “M”, remove the brazier “N” with the pellet deflector; raise the back panel “H”...
Page 38
PELLET STOVES Chapter 5 INSTALLATION AND USE MANUAL page "T"JOINT CLEANING OF SMOKE DUCT AND GENERAL CHECKS: Clean the smoke discharge system, especially in the area of the tee connectors, curves and any horizontal stretches of pipe. For information on cleaning the flue pipe, contact a professional chimney sweep.
PELLET STOVES Chapter 5 INSTALLATION AND USE MANUAL page 5.2.2. Shutting the stove down (end of season) At the end of season, before shutting down the stove, we recommend completely removing pellets from the hopper with the use of a vacuum cleaner with an extension.
PELLET STOVES Chapter 6 INSTALLATION AND USE MANUAL page 6. PROBLEMS / CAUSES / SOLUTIONS WARNING: GUIDE FOR THE EXCLUSIVE USE OF THE SPECIALISED TECHNICIAN. WARNING: All repairs must be carried out exclusively by a specialised technician, with the stove completely cold and the electric plug pulled out.
Page 41
PELLET STOVES Chapter 6 INSTALLATION AND USE MANUAL page PROBLEM POSSIBLE CAUSES Solutions: stove Pellet load too high Wait for the stove to cool, signalling pellet re-ignite it and decrease the hopper temperature Led 0. pellet load following the over the safety limit instructions in section 4.10 ...
Page 42
PELLET STOVES Chapter 6 INSTALLATION AND USE MANUAL page PROBLEM POSSIBLE CAUSES Solutions: pellets Pellet load too high Increase pellet load accumulate in the following the instructions in grate section 4.10 Insufficient combustion area. Make sure that combustive air inlet in the back of the stove is free...
INSTALLATION AND USE MANUAL page 7. ELECTRICAL DIAGRAMS MOTHERBOARD WIRING KEY 1. Control panel 8. Gear motor 2. Room probe 9. Contact thermostat 3. Smoke probe red + blue - 10. Air fan 4. Fuse 11. Smoke ejector revolution control white/red/black or blue 5.
Page 44
Via La Croce n°8 33074 Vigonovo di Fontanafredda (PN) – ITALY Telephone: 0434/599599 r.a. Fax: 0434/599598 e-mail: info.red@mcz.it 8901168900 Rev 0 12/2011...
