MAINTENANCE AND SERVICING
||
Pos Function
Control module - auto-
matic transmission
A/C compressor (not 4-
cyl. engines)
Relay-coils A/C, relay coils
in engine compartment
cold zone for Start/Stop
A
Starter motor relay
Engine control module (4-
cyl. engines)
Ignition coils (5 cyl.
engines)
Engine Control Module (4-
cyl. engines)
Engine Control Module (5-
cyl. engines)
4-cyl. engines: mass air
meter, thermostat, EVAP
valve
5-cyl. engines: Injection
system, engine control
module
354
A Pos Function
15 A/C compressor (5-cyl.
engines), engine valves, oil
level sensor (5-cyl. only)
15
Engine valves/oil pump/
center heated oxygen
5
sensor (4-cyl. engines)
Front/rear heated oxygen
sensors (4-cyl. engines),
30
EVAP valve (5-cyl.
engines), heated oxygen
20
sensors (5-cyl. engines)
Oil pump/crankcase venti-
lation heater/coolant
pump (5-cyl. engines)
20
Ignition coils (4-cyl.
engines)
10
Fuel leakage detection (5-
cyl. engines), control mod-
10
ule for radiator shutter (5-
cyl. engines)
Fuel leakage detection,
15
A/C solenoid (4-cyl.
engines)
Coolant pump (4-cyl.
engines)
A Pos Function
10 Cooling fan
15
Power steering
15
A This position is not used on vehicles with the optional Start/
Stop function, refer to the table "Engine compartment cold
zone" in Fuses – engine compartment cold zone (Start/Stop
only) (p. 359).
