Setting up the Motor Run Cycle

To set up your motor run cycle, use the PAGE button to move to page "1 of 1" in the
motor function mode. Here you will find two settings.
Motor Volts
Select the desired motor voltage here.
Run Time Minutes
Select the run time in minutes here.
Using the GFX with a Commutator Lathe
The T35-GFX is useful as the power source for a Commutator lathe, which is used to
reshape the commutator contacts on the armature of your motor, to maximize conduction,
and therefore power to the wheels.
Adjusting Motor Voltage While Running
On T35-GFX units with firmware version 1.60 and above, the user can vary the motor
voltage "on the fly", that is, while the motor is running. Older firmware revisions that
lack this feature may be upgradeable; visit our website,
http://www.competitionelectronics.com/
...or call CEI for details.

Data Mode

The "dat mode" mode does not contain any cycles. Instead it is a collection of useful
measured and calculated parameters, as well as the place where you access the stored
graphs for the last charge and discharge cycles run on the T35-GFX. Many of the data
mode parameters have already been mentioned in the descriptions of the charge,
discharge and cycle sections; here are the descriptions of the remainder of the
information it contains.
