BED LEVELING GUIDE

To ensure that your prints always stick to the glass build plate, the build surface must be properly leveled so that
the nozzle is at an equal set distance across the print surface. Use the Bed Leveling Wizard and follow the
on-screen instructions to assist you in leveling the print bed.
Initialize the Bed Leveling Wizard from the LCD menu on your Ditto
on-screen instructions to begin bed leveling. To level your bed, the wizard will move the extruder to
four points on the print bed and ask you to adjust the thumb screws to make the distance between
the nozzle tip and print bed equal across the print surface.
Turning Clockwise
This loosens the spring tension and
brings the print surface closer to the
nozzle.
With each of the three thumbscrews, adjust until the gap between the nozzle tip and print surface is
roughly the thickness of a piece of paper. If there is a large gap, you will need to turn the screw
clockwise to bring the bed closer to the nozzle. If there is no gap and the nozzle is scraping the print
tape, you will need to turn the thumbscrew counter-clockwise until you see a small gap.
STARTING A PRINT
Whenever you begin a print, always check that the rst layer of the print is properly stuck onto the blue painter's
tape. A properly leveled bed should have the extruded lament a bit squished and shouldn't pop off the bed easily.
While the printer is performing the skirt nozzle purge, observe the deposited lament and make micro-adjustments
with the thumbscrew if necessary.
TOO CLOSE
Pro 3D Printer and follow the
Turning Counter-Clockwise
This tightens the spring tension and
brings the print surface further away
from the nozzle.
LEVELED
PAGE 5
TOO FAR
