ATTENTION!
Read all safety rules carefully
before attempting to operate.
Retain for future reference.
ATTENTION!
Lisez attentivement les in-
structions sur la sécurité
avant d'utiliser cet appareil.
Conservez cette Notice pour
vous y reporter ultérieurement.
¡ ATENCIÓN!
Lea cuidadosamente todas
las normas de seguridad
antes de utilizar la aspira-
dora. Conserve esta man-
ual para consultas futuras.
DANGER!
Never operate this unit when
flammable
materials
vapors are present because
electrical devices produce
arcs or sparks that can cause
a fire or explosion.
NEVER OPERATE
UNATTENDED!
DANGER !
N'utilisez jamais cet aspira-
teur en présence de vapeurs
ou de matières inflammables.
Les appa-reils électriques
produisent des arcs ou des
étincelles qui peuvent causer
un incendie ou une explosion.
NE jAMAIS fAIRE
fONCTIONNER SANS
SURVEILLANCE!
¡ PELIGRO!
Nunca opere esta unidad ante
la presencia de materiales o
vapores inflamables dado que
los artefactos eléctricos pro-
ducen arcos o chispas que
pueden causar un incendio o
una explosión.
¡
NO DEjE LA ASPI-
RADORA fUNCIO-
NANDO SIN VIGI-
LANCIA!
User manual
Please review before
operating vac.
Wet/Dry Vacuum
Household and Workshop Use
Aspirateur pour Déchets Secs et Humides
Pour Utilisation Domestique ou dans les Entrepôts
Aspiradora para Líquidos/Sólidos
Para Uso Doméstico y Comercial
IMPORTANT SAfETY INSTRUCTIONS
or
When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL
INSTRUCTIONS BEfORE USING THIS APPLIANCE.
WARNING
1. Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing. Connect to a properly grounded
outlet only. See Grounding Instructions.
2. Do not expose to rain – store indoors.
3. Do not allow to be used as a toy. Close attention is necessary when used by or near children.
4. Use only as described in this manual. Use only Manufacturer's recommended attachments.
5. Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors or
dropped into water, contact Shop-Vac Corporation for assistance.
6. Do Not: pull or carry by cord, use cord as a handle, close a door on cord or pull cord around sharp edges or corners. Do not run
appliance over cord. Keep cord away from heated surfaces.
7. Do not unplug by pulling on cord. To unplug, grasp the plug; not the cord.
8. Do not handle plug or appliance with wet hands.
9. Do not put any object into openings. Do not use with any openings blocked; keep free of dust, lint, hair and anything that may reduce
air flow.
10. Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts.
11. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
12. Do not use without dust bag and/or filters in place.
13. Turn off all controls before unplugging.
14. Use extra care when cleaning on stairs.
15. Do not use to pick up flammable or combustible liquids such as gasoline or use in areas where they may be present.
16. Do not use your cleaner as a sprayer of flammable liquids such as oil base paints, lacquers, household cleaners, etc.
17. Do not vacuum toxic, carcinogenic, combustible or other hazardous materials such as asbestos, arsenic, barium, beryllium, lead,
pesticides or other health endangering materials. Specially designed units are available for these purposes.
18. Do not pick up wood or coal ash; soot, cement, plaster or drywall dust without collection filter bag in place. These are very fine
particles that may pass through the foam and affect the performance of the motor or be exhausted back into the air. Additional
collection filter bags are available.
19. Do not leave the cord lying on the floor once you have finished the cleaning job. It can become a tripping hazard.
20. Use special care when emptying heavily loaded tanks.
21. To avoid spontaneous combustion, empty tank after each use.
22. The operation of a utility vac can result in foreign objects being blown into eyes, which can result in eye damage. Always wear safety
goggles when operating vacuum.
23. STAY ALERT. Watch what you are doing and use common sense. Do not use vacuum cleaner when you are tired, distracted or
under the influence of drugs, alcohol or medication causing diminished control.
24. WARNING! Do NOT use this vacuum cleaner to vacuum lead paint debris because this may disperse fine lead particles into the
air. This vacuum cleaner is not intended for use under EPA Regulation 40 CFR Part 745 for lead paint material cleanup.
WARNING
OR OPERATING. UNPLUG UNIT WHEN NOT IN USE.
Manuel d'utilisation
Veuillez lire avant d'utiliser
l'aspirateur.
– TO REDUCE THE RISk Of fIRE, ELECTRIC SHOCk OR INjURY:
SAVE THESE INSTRUCTIONS
– DO NOT LEAVE VACUUM UNATTENDED WHEN IT IS PLUGGED IN AND/
Manual del usuario
Por favor lea esta manual antes
de usar la aspiradora.
BRAND/MARQUE/MARCA
Series MAC, MAZ
Series MAC, MAZ
Series MAC, MAZ

Advertisement

Table of Contents
loading

Summary of Contents for Shop-Vac MAC SERIES

  • Page 1 4. Use only as described in this manual. Use only Manufacturer’s recommended attachments. 5. Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors or dropped into water, contact Shop-Vac Corporation for assistance. DANGER ! 6.
  • Page 2: Filter Bag

    ® Drywall Household 1.5 U.S. Gal (5.6L) 90667/ the combined weight of the vacuum with a full tank of debris and accessories. 90585/ R FOAM FILTER SLEEVE fits most Shop-Vac ® 2.5 U.S. Gal (9.4L) 90668/ Wet/Dry Vacuums. WARNING – INADEQUATE MOUNTING COULD ALLOW THE UNIT TO fALL, CAUSING INjURY AND/OR DAMAGE TO THE UNIT.
  • Page 3: Wet Pick Up Operation

    It is normal for this to be a tight fit. Caution should be used when ou qu’il ait été laissé à l’extérieur. S’adresser à Shop-Vac Corporation pour obtenir de l’aide. using as a blower due to the powerful force of air when using certain 6.
  • Page 4: Instructions Concernant La Mise À La Terre

    Cet aspirateur doit être mis à la terre. Si l’aspirateur venait à mal fonctionner ou tombait en panne, AUPRÈS DU MARChAND LoCAL oU EN VISITANT LE SITE WEb DE ShoP-VAC la mise à la terre offrirait une résistance moindre au courant électrique afin de réduire les risques MONTAGE DE SUPPORT MURAL d’électrocution.
  • Page 5 S'il est utilisé à des fins de location ou commerciales, il est couvert par une garantie limitée de 90 jours. Shop-Vac Le filtre en mousse doit être également périodiquement nettoyé, comme il est indiqué ci-dessous: Corporation garantit, pendant la période de la garantie, de remettre gratuitement en bon état de...
  • Page 6: Instrucciones De Conexión A Tierra

    6. Enchufe el cable al tomacorriente de pared. Su aspiradora está lista para usarse. I = ENCENDIDO O = APAGADO A TIERRA NOTA: SU DISRIbUIDoR LoCAL o EN EL SITIo WEb DE ShoP-VAC ® PoDRÁ ENCoNTRAR MUChAS MÁS hERRAMIENTAS úTILES.
  • Page 7: Apagado Automático

    Estándar 90137/ T DE MONTAJE se adaptan a la mayoría de las TAMAÑO Muro de mampostería Uso doméstico aspiradoras para líquidos y sólidos Shop-Vac ® 1,5 gal. U.S.(5,6L) 90667/ A 90585/ R MANGA DE FILTRO DE HULE-ESUMPA se adapta 2,5 gal. U.S.(9,4L) 90668/ B a la mayoría de las aspiradoras de...
  • Page 8 Si este producto se utilizara para fines comercia- les o de alquiler, se aplicará una garantía limitada de 90 días. Shop-Vac Corporation garantiza la puesta de esta aspiradora en condiciones operativas correctas, ya sea mediante su reparación o el reemplazo de sus piezas, durante el período de garantía, y sin cargo alguno.
  • Page 9 Shop-Vac® Corporation Print Specifications Part #: 87549-48 Description: Instruction Manual for 2030100, 2030127, 2036004 Printed Sides: Double-sided #Pages: 8 Finish Style: Multiple page Paper Stock: 50lb White Offset Finished Size: 8.5” x 11” Ink Color: 100% Black Released to SVC: 12-26-2013 Revision Date(s): Notes/Special Instructions: Prints double-sided on 8.5”...
