Aiphone IX-DF-2RA-FR( Installation Manual

Installation Manual
This manual includes Product Liability Precautions. Provide this manual to
end user after installation.
Introduction
• Read this manual before installation and connection.
Read the "Setting Manual" and "Operation Manual" included on the DVD-ROM that comes with the
Master Station (IX-MV).
• Configure the system settings according to the "Setting Manual" after completing the installation
and connection. The system will not function unless it has been properly configured.
• After installation, explain to the customer how to use the device, and be sure to provide the
accompanying DVD-ROM that came with the Master Station (IX-MV).
Important
• Perform the installation and connection only after fully understanding this device and the manual.
Illustrations used in this manual may be different from the actual ones.
Example of System Configuration
IX-MV PC
(third party)
IX Support Tool
(included with IX-MV)
PoE-enabled switch
(third party)
LAN
PoE-enabled switch PoE-enabled switch
(third party) (third party)
PoE-enabled switch PoE-enabled switch
(third party) (third party)
IX-DA IX-BA
IX-DF
IX-DF-HID
IX-DF-P
J Number of station registrations in address book
Product number Product name
IX-MV Master Station
IX-DA, IX-DF, IX-DF-RP10* 1 , IX-DF-HID* 1 , Video Door Station
IX-DF-2RA(FR) * 1 , IX-DF-PI* 2 , IX-DF-P* 2
IX-BA, IX-SS, IX-SS-2RA* 1 , Audio Only Door Station
IX-SS-RA(FR)* 1
* 1 North America only * 2 Except North America
* 3 Only Master Stations can be registered (Max. 20)
Indicators
Refer to the separate "IX-DA & IX-BA Operation Manual" for indicators other than those listed.
Name Status (Pattern)
Status Red Normal flashing
indicator flashing
0.75 sec 0.75 sec
Fast flashing
0.25 sec 0.25 sec
Long interval flashing
0.5 sec 4 sec
Long irregular flashing
1 sec 0.25 sec 0.25 sec 0.25 sec
Short irregular flashing
1 sec 0.25 sec 0.25 sec 0.25 sec
Red
light
Part Names and Accessories
IX-DF-2RA
(Video Door Station)
IX-DF-2RA-FR
CALL PLACED
CALL ANSWERED
APPEL
APPUYES SUR LE
BOUTON POUR APPELER
IX-DF-2RA-FR
Network Video
Network Camera
MAC address
Recorder (third party)
(beneath the panel)
(third party)
Precautions
Warning
PoE-enabled switch
(third party)
1. Voltage is applied to parts within the
IX-DF-2RA-FR
equipment. Do not touch any parts that are
not associated with the installation, wiring,
CALL PLACED
or connection. Electric shock could result.
CALL ANSWERED
2. Do not dismantle or alter the unit.
APPEL
Fire or electric shock could result.
BOUTON POUR APPELER APPUYES SUR LE
Dismantling
or
EMERGENCY
alteration
*1
3. Keep the unit away from water or any
IX-DF-2RA-FR IX-DF-2RA
*2
other liquid.
Fire or electric shock could result.
Number of station registrations
in address book
Caution
500 stations
20 stations* 3
20 stations* 3
1. Do not install or make any wire
terminations while power supply is
plugged in. It can cause electrical shock
or damage to the unit.
2. Before turning on power, make sure
wires are not crossed or shorted. If not,
fire or electric shock could result.
3. Do not install the unit in any of the
following locations. Fire, electric shock,
or unit trouble could result.
: Light ON : Light OFF
• Places under direct sunlight or places
near heating equipment that varies in
Explanation
temperature.
Booting • Places subject to dust, oil, chemicals,
hydrogen sulfide (hot spring).
• Places subject to moisture and
humidity extremes, such as
Device
bathrooms, cellars, greenhouses, etc.
• Places where the temperature is quite
error
low, such as inside a refrigerated area
or in front of an air conditioner.
Communication
• Places subject to steam or smoke (near
failure heating or cooking surfaces).
• Where noise generating devices
such as dimmer switches or inverter
Firmware
electrical appliances are close by.
version • Locations subject to extremely
0.25 sec 0.25 sec
powerful electric fields.
upgrading
Initializing
Standby
IX-DF-2RA-FR
(Video Door Station)
IX-SS-2RA
Side
(Audio Only Door Station)
Call indicator (orange)
Camera
Call indicator (orange) Call indicator (orange)
Microphone
Camera
Communication
Microphone Microphone
indicator (green)
Communication Communication
Speaker
indicator (green) indicator (green)
Status indicator (red)
LED for night illumination
Speaker Speaker
LED for night illumination Call button
Call button Call button
Status indicator (red) Status indicator (red)
Emergency call button
Drain holes (4) Drain holes (4)
Main unit Mounting box
Front panel
Panel
MAC address
(beneath the panel)
Negligence could result in death or serious injury.
4. The unit is not explosion-proof. Do not
install or use near gases or flammable
materials.
Fire or explosion could result.
5. Do not connect any terminal on the unit
to an AC power line.
Fire or electric shock could result.
6. Do not put any metal or flammable
material into the unit through the
openings.
Fire, electric shock, or unit trouble could
result.
Negligence could result in injury to people or damage to property.
4. When mounting the unit on a wall,
install the unit in a convenient location,
but not where it could be jarred or
bumped. Injury could result.
5. Do not place or install the unit in the
locations subject to frequent vibration or
impact. If the unit falls, injury to people
or damage to the unit could result.
6. Do not run wires between movable
objects (doors, windows, etc.). It may
cause malfunction.
7. Do not put anything on the unit or cover
the unit with cloth, etc. Fire or unit
trouble could result.
8. Be sure to perform a call test or check
the chime volume with the handset on
the hook. If you operate the hook switch
with the handset on your ear, a sudden
call etc. may arrive causing damage to
your ear.
Issue Date : November 2014 FK2122 A P1114 SQ 56142 Printed in Thailand
Back
Camera angle adjustment lever
Reset button*
Camera angle adjustment
lever (Video Door Station only)
CAT5e/6 cable
connections
Reset button*
Option connector input
CAT5e/6 cable
connections
Option connector input
* Press and hold the reset
Emergency call button
button for longer than 1
second, then release to
* Press and hold the reset
restart station.
button for longer than 1
MAC Address second, then release to
Main unit Mounting frame MAC address
restart station.
Notice
1. Aiphone assumes no responsibility for damages as a result of delayed or unusable services, which were
due to failures in network equipment, communication services by Internet and cellular phone companies, line
interruptions, communication failures, or inaccuracies or omissions in the transmission unit.
2. We will under no conditions be liable for damage that occurs due to the inability to communicate due to
malfunctions, problems, or operational errors in this product.
3. If personal information leaked by eavesdropping or unauthorized access in the communication paths over
the Internet, please be aware that Aiphone assumes no responsibility for the damages.
4. We will under no conditions be liable for any damages or losses resulting from this product's contents or
specifications.
5. This manual was created by Aiphone Co., Ltd., all rights reserved. Copying a part of or this entire manual
without prior permission from Aiphone Co., Ltd. is strictly forbidden.
6. Please note that this manual may be revised or changed without prior notice.
7. Please note that product specifications may be changed for the sake of improvement without prior notice.
8. Please be aware that it is the customer's responsibility to ensure that their computer is secure. We will under
no conditions be liable for security failures.
9. This system is not intended for life support or crime prevention. It is just a supplementary means of
conveying information. Aiphone will under no conditions be liable for loss of life or property which occurs
while the system is being operated.
10. Keep the unit more than 1m (3.3') away from radio or TV set.
11. Install the unit in an area that will be accessible for future inspections, repairs, and maintenance.
12. If the unit is down or does not operate properly, unplug the power supply or turn off the POWER switches.
13. If it is used close to a cellular phone, the unit may malfunction.
14. The unit can be damaged if dropped. Handle with care.
15. The unit turns inoperative during power failure.
16. In areas where broadcasting station antennas are close by, the intercom system may be affected by radio
frequency interference.
17. At a gate or porch illuminated by a fluorescent lamp, the picture may vary, but this is not a malfunction.
18. If stripes or fine patterns are reflected, outlines and colors shown may differ from actual people or
backgrounds, but this is not a malfunction.
19. Warm-color lighting shining on the video door station may change the tint of the picture on the monitor.
20. When using fluorescent lights to illuminate the screen its colors may periodically change (color rolling), but
this is not a malfunction.
21. The unit case may become a warm with use, but this is not a unit malfunction.
22. Warm air flowing from inside may interact with the temperature difference in the outside air to cause
condensation to occur on the camera unit. It is recommended that you block the points from which warm air
is flowing out, such as incoming line ports, in order to prevent condensation.
23. Keep the intercom wires more than 30cm (12'') away from AC 100-240V wiring. AC induced noise and/or
unit malfunction could result.
24. Door station is weather-resistant, but do not spray high-pressure water. Unit trouble could result.
25. Due to the nature of the camera built into the Video Door Station, external light and the surrounding
environment may affect the projection quality of the TV monitor, so please avoid installing in the following
locations.
Where the sky can be seen Where the background
in the background is white
White
Sky
wall
Accessories included
Installation Manual Chinese RoHS paper Special screwdriver
(this manual) x1 x1 x1
Option connector
x1
Special Screw
x4
Back Box
x1
Where direct sunlight
is present
