Owner's Manual
3 Channel Remote Start / Keyless Entry System
This Unit is Intended for Installation in Vehicles with
12 Volt Negative Ground Electrical Systems,
Gasoline or Diesel with True Tach Reference
(2) - 3 Button Anti Code Grabbing Transmitters
External Superheterodyne Antenna/Receiver
(2) - 30 Amp In-line Fuse Holders With Fuses
Installation Instructions
and Automatic Transmissions Only.
Kit Contents
AARS-30CS Control Module
3 Channel Code Learning Receiver
(1) - Multi Pin Input/Output Harness
(1) - Six Pin Power Harness
(1) - Four Pin Auxiliary Harness
(1) - Two Pin I/O Harness
(1) - Accessory 2 Pin Connector
(1) - 2 Pin Door Lock Harness
(1) - Control Switch
(1) - Programming Switch
(1) - Ring Terminal
(4) - 1/2" Long Screws
(1) - Pin Switch
(1) - Remote Start Warning Label
(1) - Literature Package
Model AA-RS30CS
Installation Manual
Advertisement
Table of Contents
Related Manuals for Audiovox AA-RS30CS
Summary of Contents for Audiovox AA-RS30CS
-
Page 1: Installation Instructions
(1) - Accessory 2 Pin Connector (1) - 2 Pin Door Lock Harness (2) - 30 Amp In-line Fuse Holders With Fuses (1) - Remote Start Warning Label Model AA-RS30CS Installation Manual Kit Contents AARS-30CS Control Module (1) - Six Pin Power Harness... - Page 2 The AA-RS30CS is Remote Start/Keyless Entry System is designed to be used with Automatic Transmission Vehicles Only! The unit provides a selectable ignition control that allows a 10 second output for glow plug pre-heat which may be required for certain diesel vehicles, (see selectable feature #9). If the diesel engine has a instant fire, (no glow plug pre-heat system), feature #9 should remain in the default Gasoline mode setting.
-
Page 3: Wiring The 6 Pin Main Power Harness
Place the RED rubber boot, included in the kit, over the switch handle to differentiate this switch from the program switch. The AA-RS30CS is to be used in vehicles with AUTOMATIC TRANSMISSIONS only! Although this combination Keyless Entry/Remote Start unit is a sophisticated system with many advanced features, IT MUST NOT be installed into a vehicle with a manually operated transmission. - Page 4 SEE NEUTRAL START SAFETY TEST FOR FURTHER DETAILS. BLUE Wire: Ignition 1 Output Connect this wire to the ignition 1 wire from the ignition switch. This wire will show +12 volts when the ignition key is turned to the to the "ON" or "RUN" and the "START" or CRANK" positions, and will have 0 volts when the key is turned to the "OFF"...
- Page 5 The Black w/White tracer wire provides ON-OFF control of the Remote Starter. When the Black w/White wire is switched to a full time ground, the AA-RS30CS Remote Start Module is operative. When the Black w/White wire is at open circuit through the control switch, the remote starter is disabled.
- Page 6 connect the Brown w/Black trace wire to the output of the brake light switch. If the brake light switch in the vehicle switches ground, do not use the Brown w/Black wire; see Grey w/Black tracer wire. YELLOW w/BLACK Tracer Wire: + 12 Volt Alarm By - Pass Output NOTE: YOU MUST DISCONNECT THE IGNITION INPUT OF THE ALARM FROM ANY OTHER WIRE THAT IT IS PRESENTLY CONNECTED TO IN THE VEHICLE.
- Page 7 5. Connect the previously selected resistor from terminal #87 to the second (#2) wire (as shown). NOTE: The above information and following diagram is for the GM VATS system only. For GM PASS LOCK System you will require the Audiovox AS-PASS II Module. General Motors VATS By-Pass Diagram...
- Page 8 DARK GREEN/ORANGE Wire: Tach Sensor Input This wire will continually monitor the engine tach rate while the unit is under power of the Remote Start module. This wire will be routed to the vehicle ECM tach input or through the firewall into the engine compartment and connect to the negative side of the ignition coil.
-
Page 9: Wiring The 4 Pin Auxiliary Output Harness
Note: For connection to Four Wire Polarity Reversal, 5 Wire Alternating 12 Volts, And All Other Door Lock Circuits the Audiovox AS-9159 Door Lock Interface, (or equivalent 30 A automotive relays) must be used. Refer to the Audiovox Door Lock Wiring Supplement for proper wiring of these circuits. - Page 10 AA-RS30CS is used to unlock the doors. Black w/Light Green Trace Wire: Pulsed Ground Output After Start The Black w/Light Green Trace wire will provide a 1 second 300ma pulsed ground output after the vehicle is started under control of the remote start unit.
- Page 11 Green w/Black Trace Wire: 300mA Latched Channel 3 Output The Green w/Black Trace wire supplies a 300mA switched output whenever channel three of the receiver is ac- cessed. Pressing the pre-programmed transmitter button(s) will access channel three and will remain active, for up to 8 seconds, as long as the transmitter button(s) is held.
- Page 12 NOTE: 1. When selecting Diesel operation, (Feature Nine), over gasoline, the only change is to the ignition circuits. When Diesel is selected, the ignition circuits will power up 10 seconds before the start circuit. The intent of this feature is to allow the glow plug warming required by some diesel engines.
- Page 13 3. Connect the Yellow wire to a +12 volt ignition 1 source. This wire will have +12 volts with the ignition in the on and start position and have 0 volts with the ignition in the off position. 4. Connect the Green wire to the (Green) or (Orange/Green) tach input of the Audiovox remote start unit.
-
Page 14: Testing Your Installation
3. Raise the hood and confirm that the remote start unit shuts down. If the unit fails this test, recheck your pin switch connection to the Gray/Black wire of the Audiovox Remote Start Unit. DO NOT RELEASE THIS VEHICLE TO THE CONSUMER UNTIL YOU CONFIRM THE OPERATION OF THE HOOD PIN SAFETY SHUT DOWN FEATURE. - Page 15 1. Locate the Orange / Black reference wire in the "C2" connector found at the ECM in GM B Body vehicles or, locate the equivalent reference wire in the vehicle you are installing the Audiovox Remote Start Unit in. 2. Connect the Cathode, (Striped) end, of a 4000 series diode to this reference wire.
- Page 16 E. Connect the cathode (striped) side of a 4002 series diode to this same wire, and connect the (non striped) side to the negative shut down safety wire (Gray / Black) of the Audiovox Remote Start Unit. F. Connect terminal 86 of the relay to a fused +12 volt constant battery source.
- Page 17 If the hood pin switch is also used for an alarm trigger input, be certain to use the dual diode assembly packaged with the Audiovox Remote Start Unit as shown earlier in this installation guide.
-
Page 18: Completing The Installation
COMPLETING THE INSTALLATION: After you have confirmed the operation of the Audiovox Remote Start unit and tested all the safety features of the system: 1. If not done so already, place the red rubber handle cover over the handle of the control switch for ease of identification. -
Page 19: Wiring Diagram
WIRING DIAGRAM... - Page 20 © 2000 Audiovox Electronics Corp. , Hauppauge N.Y. 11788 128-5818...
