3 Channel Remote Start / Keyless Entry System
This Unit is Intended for Installation in Vehicles with 12 Volt Negative Ground
Electrical Systems, Gasoline or Diesel with True Tach Reference and Automatic
Transmissions Only.
(2) - 3 Button Anti Code Grabbing Transmitters
(2) - 30 Amp In-line Fuse Holders With Fuses

Installation Instructions

Kit Contents
AA-RS10CS Control Module
3 Channel Code Learning Receiver
External Superheterodyne Antenna/Receiver
(1) - Multi Pin Input/Output Harness
(1) - Six Pin Power Harness
(1) - Four Pin Auxiliary Harness
(1) - Two Pin I/O Harness
(1) - Accessory 2 Pin Connector
(1) - 2 Pin Door Lock Harness
(1) - Control Switch
(1) - Programming Switch
(1) - Ring Terminal
(4) - 1/2" Long Screws
(1) - Pin Switch
(1) - Remote Start Warning Label
(1) - Literature Package
Model AA-RS10CS
Installation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AA-RS10CS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Audiovox AA-RS10CS

  • Page 1: Installation Instructions

    (2) - 30 Amp In-line Fuse Holders With Fuses (1) - Remote Start Warning Label Model AA-RS10CS Installation Manual Kit Contents AA-RS10CS Control Module (1) - Six Pin Power Harness (1) - Two Pin I/O Harness (1) - Control Switch (1) - Programming Switch (1) - Ring Terminal (4) - 1/2"...
  • Page 2: Program Switch

    The AA-RS10CS Remote Start/Keyless Entry System is designed to be used with Automatic Transmission Vehicles Only! The unit provides a selectable ignition control that allows a 10 second output for glow plug pre-heat which may be required for certain diesel vehicles, (see selectable feature #9). If the diesel engine has a instant fire, (no glow plug pre-heat system), feature #9 should remain in the default Gasoline mode setting.
  • Page 3: Wiring The 6 Pin Main Power Harness

    WIRING THE 6 PIN MAIN POWER HARNESS: RED w/ WHITE Trace Wire: + 12 volt Battery 1 Source Connect this wire to a + 12 VDC constant source found at the vehicle's ignition switch using the 30 Amp fuse and holder provided.
  • Page 4 The Black w/ White tracer wire provides ON-OFF control of the Remote Starter. When the Black w/ White wire is switched to a full time ground, the AA-RS10CS Remote Start Module is operative. When the Black w/ White wire is at open circuit through the control switch, the remote starter is disabled.
  • Page 5 Brown w/ Black tracer wire. BROWN Wire: Positive Inhibit Input 1 Any time + 12 Volts is applied to the Brown wire, the Remote Starter will stop operating, even if the signal is received from the transmitter. If the vehicle has a factory installed hood pin switch, and that switch provides + 12 Volts to an under hood light, the Brown wire can be connected to the existing pin switch.
  • Page 6 (2) WHITE Wires: Parking Light Flasher These wires are the COMMON and NORMALLY OPEN contacts of the on-board parking lamp relay. If the vehicle's parking lights are a +12 volt switched system, connect (1) of the White wires to a fused (15A max.) +12 volt battery source, and connect the second White wire to the vehicle's parking light wire.
  • Page 7 5. Connect the previously selected resistor from terminal #87 to the second (#2) wire (as shown). NOTE: The above information and following diagram is for the GM VATS system only. For GM PASS LOCK System you will require the Audiovox AS-PASS II Module. DARK GREEN Wire: Tach Sensor Input This wire will continually monitor the engine tach rate while the unit is under power of the Remote Start module.
  • Page 8 In this application, the Red wire of the two pin harness provides a ground pulse during the arming sequence, or pulsed ground lock output. Connect the Red wire to the low current ground signal wire from the factory door lock switch to the factory door lock relay.
  • Page 9 Audiovox AS-9159 Door Lock Interface, (or equivalent 30 A automotive relays) must be used. Refer to the Audiovox Door Lock Wiring Supplement for proper wiring of these circuits. 4 Wire Polarity Reversal and 5 Wire Alternating 12 Volt Door Lock Control Circuits In these applications, the AS 9159 Door Lock Interface ( or equivalent 30 A automotive relays) must be used.
  • Page 10 The AA-RS10CS Remote Car Starter will learn the tach rate of most vehicle's single ignition coils, multiple coil packs, 1 Flash 2 Flashes 3.5 Second Door Locks...
  • Page 11 and or single injector. To learn tach; 1. Start with the programming switch in the OFF position. 2. Turn the ignition key to the ON position. 3. Flip the program switch ON - OFF - ON - OFF - ON - then OFF. 4.
  • Page 12: Testing Your Installation

    3. Raise the hood and confirm that the remote start unit shuts down. If the unit fails this test, recheck your pin switch connection to the Gray/Black wire of the Audiovox Remote Start Unit. DO NOT RELEASE THIS VEHICLE TO THE CONSUMER UNTIL YOU CONFIRM THE OPERATION OF THE HOOD PIN SAFETY SHUT DOWN FEATURE.
  • Page 13: Park / Neutral Ecm Input

    1. Locate the Orange / Black reference wire in the" C2" connector found at the ECM in GM B Body vehicles or, locate the equivalent reference wire in the vehicle you are installing the Audiovox Remote Start Unit in. 2. Connect the Cathode, (Striped) end, of a 4000 series diode to this reference wire.
  • Page 14: Key In Sensor Circuits

    E. Connect the cathode (striped) side of a 4002 series diode to this same wire, and connect the (non striped) side to the negative shut down safety wire (Gray / Black) of the Audiovox Remote Start Unit. F. Connect terminal 86 of the relay to a fused +12 volt constant battery source.
  • Page 15: Completing The Installation

    COMPLETING THE INSTALLATION: After you have confirmed the operation of the Audiovox Remote Start unit and tested all the safety features of the system: 1. If you have not done so already, place the red rubber handle cover over the handle of the control switch for ease of identification.
  • Page 16: Wiring Diagram

    WIRING DIAGRAM © 2000 Audiovox Electronics Corp., Hauppauge, NY 11788 128-5850...
