Charging The Supplied LiPo Batteries

Locate the two USB style chargers and connect one to the larger 'Quad LiPo'
and one to the smaller 'Tx LiPo'. Note the orientation of the white two-pin
connector, then correctly align the slots to ensure correct polarity.
Tx LiPo
Plug the USB charger into a suitable USB port noting that the LED on the
charger will glow solid red when connected. A discharged battery will be charged
in approximately 70 minutes and can be seen to be fully charged when the red
LED light goes out. When this happens the battery is ready to use and can be
disconnected from the charge lead.

Preparation for Flight

1. Using the screwdriver supplied remove rear battery cover of the transmitter
and insert the smaller 'Tx LiPo'. Connect the white two pin plug to the
socket, making sure to align the slots for correct polarity, then replace the
battery cover and tighten the screw.
2. Open the rear battery cover of the quadcopter and insert the larger Quad
LiPo into the fuselage. Connect the LiPo's two pin plug to the socket of the
quadcopter making sure to align the slots for correct polarity. Tuck the lead
neatly behind the LiPo and close the battery cover.
Quad LiPo
11
