Ares™ Ethos QX 75 Nano-Micro RTF Quadcopter – QUICK TIPS
500D CX 100 RTF Heli
PLEASE NOTE:
These QUICK TIPS are NOT intended to replace the content included in the instruction manual.
Although these tips cover some of the most important details you need to know before making
your first flight we strongly recommend reading through the manual completely before flying.
Charging the LiPo Flight Battery
The AA batteries included to power the transmitter are not intended to be used to power the
included charger (to charge the LiPo flight battery) through the built‐in USB port on the
transmitter. If you'd like to power the included charger through the USB port on the transmitter we
recommend replacing the AA batteries with Energizer® MAX brand or equivalent capacity
(~2800mAh per cell) alkaline/rechargeable AA batteries. These AA batteries can deliver enough
power to charge a fully discharged (not over‐discharged) LiPo flight battery up to 5‐7 times before
they need to be replaced. Also, as the voltage of the AA batteries drops it will take more time to
charge the LiPo flight battery. Additional options include connecting the charger to a suitable 5V
USB port on a computer or other device, or use the optional 5005PS 100‐240V AC to 5V DC USB,
0.5‐Amp Power Supply (AZSC5005PS).
Transmitter Dual Rates
The M4LPQ transmitter is equipped with a 'dual rate' feature. This feature allows you to toggle
between the 'High' (HI/FULL) and 'Low' (LO/HALF) control rates available for the aileron and
elevator channels. You can toggle between the high and low rates by pressing the dual rate button
(the right side of the rocker switch) located on the top left 'corner' of the transmitter. You should
feel a 'click' and also hear an audible beep/tone that indicates which control rate mode you are in.
Two (2) beeps/tones means you've selected high/'FULL' rate mode and one (1) beep/tone means
you've selected low/'HALF' rate mode. Also, the selected rate mode will be displayed as 'FULL' for
high rate and 'HALF' for low rate on the LCD screen. The low rate mode is typically preferred by
(and recommended best for) first‐time, low‐time and other pilots interested most in a reduced
amount of control authority that allows for even smoother and more easily controlled hovering
and flying.
Elevator Trim
The elevator trim can be used to help keep the quadcopter from drifting forward or backward
when hovering and with no right‐hand stick input. For example, if the quadcopter drifts forward
when hovering add backward (up) elevator trim by pressing the right‐hand elevator trim button
(the right side of the rocker switch) located on the top right 'corner' of the transmitter until the
quadcopter hovers as level as possible with no forward drifting. NOTE: The unique position of the
elevator trim buttons is due to the ergonomic design of the transmitter. The functions of these
buttons are clearly noted on the corresponding label and it will not typically be necessary to adjust
the elevator trim position after it's been set correctly.
OVER
