4 Button Remote Start Security System With
Plug-In Shock Sensor & Starter Disable
IMPORTANT ! In order to provide you with the highest level of security to your
vehicle, this system is equipped with selectable manual override circuitry. It is
possible that you will need to override you security system if the transmitter
becomes lost, or inoperative due to battery failure. Reading the sections on
"Manually Overriding Your System" is necessary to fully understand the procedure
required to enable your vehicle in such situations. In addition, the chart on the last
page of this manual has a section for the particular features and options installed
in your vehicle as well as the override method selected. Although the default
mode is "Valet Switch" operation, the system can be configured for "Custom
Code" operation for enhanced security. Confirm the override mode selected on
the last page of this manual, and familiarize yourself with the section on it's opera-
tion.
FEATURES :
! 1 Two Way 5 Button Remote Control And 1 One Way 4 Button Remote Control
! Six Channel Code Learning Programmable Receiver
! External Superheterodyne Transceiver Antenna
! Single Or Two User Programmable W/Separate Control Outputs
! Single Button Lock/Unlock or Separate Button Lock/Unlock or Both
! Remote Keyless Entry With Optional Access Guard (must have power door
locks)
! Selectable Manual Override Mode
! New Enhanced Panic Feature (Any button other than unlock stops siren, no
change to the units state)
! Smart Disarm (If triggered, elect to shut off siren, or disarm entire unit )
! Adjustable Shock Sensor Via The Transmitter (Pre-Detect Off, Pre & Full Detect
Off, City Mode)
! Safe Start Output Controlled From Channel 3 (Option Channel 3 For Trunk, Or
For R/S)
! 24 Hour Time Start Mode
! Cold Temperature Start Mode
! 2 or 4 Hour Automatic Start Mode
! Parking Meter Count Down Timer On LCD Remote
! Additional Count Down Timer Mode
! Remote Panic In All Modes (Press & Hold Lock /Unlock Button For 3 Seconds
To Engage)
! Improved Custom Code Override, User Selectable and Programmable
Model PRO-9800
Owner's Manual
128-6527
1 of 20
Advertisement
Table of Contents
Related Manuals for Audiovox Pursuit PRO-9800
Summary of Contents for Audiovox Pursuit PRO-9800
- Page 1 ! Additional Count Down Timer Mode ! Remote Panic In All Modes (Press & Hold Lock /Unlock Button For 3 Seconds To Engage) ! Improved Custom Code Override, User Selectable and Programmable Model PRO-9800 Owner’s Manual 128-6527 1 of 20...
-
Page 2: Your "Code Hopping" Transmitters
! Protected Push Button Valet/Override Switch ! 7-Function LED-Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming ! Intrusion Alert With Memory ! Instant Siren Activation ! Starter Disable Output ! Additional Engine Immobilizer Output, (Optional Relay Required) ! True Last Door Arming (Hardwire Only) ! Defective Zone By-Pass ! Defective Zone Chirp Confirmation (Unit Chirps To Report Zone Cleared) -
Page 3: Arming The System - Active
known as a code grabber, which will receive and store the signal from your keychain transmitter and re-transmit at a later time to disarm your system. Your Keeloq Code Hopping transmitters will change their signal every time the button is pressed, so when a thief grabs then re-transmits your signal, the alarm system will not respond. -
Page 4: Arming The System - Passive (Automatic)
" Parking Lights flash one time. " Siren will not sound. If the siren "chirped" three times, sometime after arming, the exclusive delayed dome light learn circuit has been programmed and the sys- tem detected a open entry point after the learned delay expired. Clos- ing the hood, trunk, or doors will correct the problem and you do not need to disarm the system to make the correction. -
Page 5: Disarming The System
" Any mild impact to the vehicle’s glass will cause the alarm to sound a short series of warning tones. " Any strong impact to the vehicle’s glass will cause the alarm to trigger for the full 30 second alarm cycle. NOTE: If the optional interior illumination circuit was installed, the interior light will flash as well for the full 30 second alarm cycle. -
Page 6: While The System Is Sounding
" Parking Lights flash two times. If the parking lights flashed three times, then the alarm was triggered in your absence. Before turning the key on, examine the LED to identify which zone was triggered. " Siren will not sound. If the siren sounds 4 chirps, then the alarm was triggered in your absence. -
Page 7: Manually Overriding Your System
1. Enter the vehicle and turn the ignition key to the on position. 2. Press and hold the valet pushbutton switch until the dash mounted LED turns on solid. The system will remain in the valet mode. 3. To return to normal operation, press and release the pushbutton switch any time the ignition is on. - Page 8 NOTE: If 15 seconds of inactivity expire or if the ignition switch is turned off for more then 5 seconds during any of the above steps, the unit will revert back to the last successfully stored code. Custom Code Programming Example: To Change the code from the factory pre-assigned code of 11 to “52”...
-
Page 9: Eliminating The Normal Arm / Disarm Chirps
ELIMINATING THE NORMAL ARM / DISARM CHIRPS As explained earlier in the manual, you can eliminate the chirps selectively any time you arm or disarm the system simply by holding the ARM or DISARM button for two seconds. If you find the normal arming and disarming chirps annoying, they can be turned off permanently, eliminating the need to hold the ARM / DIS- ARM button for 2 seconds. -
Page 10: Remote Starting The Vehicle
2. Stage 1 (Omit pre-detect) In this mode, the warn away chirps created by the lesser vibration will be deleted. If strong vibration occurs, the siren will sound. 3. Stage 2 (Omit pre & full detect) In this mode, both the pre-detect stage and the full trigger stage of the sensor are defeated. -
Page 11: Operating On Automatic Start Up Timer Mode
1. The Vehicle Hood Is Opened. 2. The Gear Selector Is In Any Gear Other Then Park. 3. The Brake Is Depressed. 4. The Safety Control Switch Is In The Off Position. WARNING! Be certain that the vehicle is outdoors before using this or any remote vehicle starting device. - Page 12 The vehicle, on a 2 or 4 hour interval basis, will automatically start, run for the pre-programmed time (5,10,15 or 20 minutes), and then shut off. will continue for 48 hours. NOTE: The automatic start up timer can also be initiated from the keychain transmitter.
- Page 13 ADDITIONAL REMOTE FUNCTION ( CHANNEL 4 ) Controlled By: # Trunk/Key Button # Option Button # Lock + Unlock Buttons # Lock + Trunk/Key Buttons # Lock & Option Buttons # Unlock + Trunk/Key Buttons # Unlock & Option Buttons # Trunk/Key & Option Buttons Other Transmitter button configurations are also available.
-
Page 14: Telematic Upgrade
ADDITIONAL REMOTE FUNCTION ( CHANNEL 7 ) Channel 7 is an alternate output that can be controlled by the unlock button of the transmitter or by and independent button or combination of buttons. For your vehicle this output is: Controlled By: # Trunk/Key Button # Option Button # Lock + Unlock Buttons # Lock + Trunk/Key Buttons # Lock &... - Page 15 TRANSCEIVER ICONS AND THEIR INDICATIONS When Disarmed, Press the Arm/Lock button to Lock and Arm the System. The Lock Icon is displayed on the LCD panel & the parking lights flash once. When Armed, Press the Disarm/Unlock button to Unlock and Disarm the System. The Unlock Icon is displayed on the LCD panel &...
- Page 16 The following trigger patterns will be displayed. Triggered and the entry attempt was made to one of the vehicle doors. Triggered and entry attempt was made to the vehicles hood or trunk. Triggered and entry attempt was made to the vehicles glass, or the vehicle has been hit or bumped hard enough to cause a response from the vibration detec- tor.
- Page 17 ADDITIONAL REMOTE FEATURES: The two way remote control unit allows you to access status information from the vehicle, check temperature, light the display, toggle the transmitter from beep tones to vibrate mode, initiate daily start timer, and tempera- ture start. Selection of these and other features are shown below: NOTE: Transmitter must be within operating range of the vehicle, approximately 1000 ft.
- Page 18 If you require more frequent starting please refer to auto start up timer mode shown earlier in this guide. NOTE: To insure accurate 24 Hour Start up, it is advisable to reset the start time periodically as time may drift slightly each day. Page Call Out: From within the vehicle, if the valet push button is pressed for three seconds, the alarm unit in the vehicle will transmit to the LCD remote and a beep tone...
- Page 19 Page 19 128-6527 19 of 20...
- Page 20 4 CHIRPS * These chirps are optional, and can be de - activated. PARKING LAMP INDICATORS 1 FLASH 2 FLASHES 3 FLASHES © 2003 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, NY 11788 PRO-9800 PASSIVE ARMING/ACTIVE ARMED DISARMED VALET MODE...
