- Page 1 300 Series Turret HD Analog Surveillance Camera Installation & Operation Manual...
-
Page 2: Installation
Luma 300 Series Turret Camera Installation Before you start, ensure that the device is in good condition and all the assembly parts are included. Make sure that all equipment is powered off during installation. Ensure the wall is strong enough to hold three times the weight of the camera and the mount. - Page 3 Luma 300 Series Turret Camera Wiring Advisory We recommend installing with RG-59 or RG-6 cabling with two-wire power (either regular or siamese). This provides better performance over distance than using traditional category cable with baluns. For more details on the cameras or cables, see the...
-
Page 4: Box Contents
Luma 300 Series Turret Camera Box Contents Camera Mounting bracket Self-adhesive mounting template 3 x wall anchors with screws 3mm hex wrench Other Required Equipment Aside from the contents of this box, you will need Phillips screwdriver Power source: 12V DC... - Page 5 Luma 300 Series Turret Camera Overview Before installing, familiarize yourself with the parts of your camera. Camera Body...
- Page 6 Luma 300 Series Turret Camera Camera Base Cables The black BNC cable: 960H video connection. The gray BNC cable: HD-TVI connection. Standard gray cable: power. The thin, twin wires (black and white) are used to select CVBS or HD-TVI signal.
-
Page 7: Prepare For Installation
Luma 300 Series Turret Camera Prepare for Installation 1. Drill a cable hole and pilot holes for your screws in the ceiling, using the supplied template shown. 2. Select which BNC cable you are going to use. Wrap the unused BNC head in electrical tape to... - Page 8 Luma 300 Series Turret Camera 3. If using CVBS, cross-connect the two thin wires to activate the CVBS signal. Otherwise, wrap the wires separately to avoid cross-connection. 4. Loosen the locking hex screw on the base and remove it from the camera housing.
-
Page 9: Install The Camera
Luma 300 Series Turret Camera Install the Camera 5. Attach the base of the camera to the ceiling and secure it with screws. 6. Route the cables through the cable hole. Note that the base provides extra space between the... - Page 10 Luma 300 Series Turret Camera 7. Insert the camera into base, making sure open area of the housing is pointed in the direction you want the camera aim. Tighten locking screw to secure the camera in place. 8. Connect the power and video cables.
-
Page 11: Adjust The Camera
Luma 300 Series Turret Camera Adjust the Camera 1. Manually adjust the camera to get an optimum angle, being careful not to touch the lens. The camera is free-floating for perfect pan and tilt control. 2. Adjust the camera’s zoom and focus using the... - Page 12 (RA) number. Contact technical support for an RA number. Copyright ©2015 by SnapAV. All rights reserved. SnapAV, Luma Surveillance, and all related marks and images are trademarks or registered trademarks of SnapAV. Version 150910-0843...
