Installing the dust cover (Cover it VC-S is an optional accessory)
The holes for lid hinges are pre-drilled on the back side of the unit. Each hinge is attached with 2 screws
(supplied with the lid).
Fit the lid carefully over the hinge prongs and adjust the screws until the lid stays open at the angle of your
preference without being too stiff to open or close.

Technical specifications Vinyl Cleaner VC-S

Nominal speed
Power consumption
Dimensions (W x D x H)
Weight
Fuse 230V/120V

Potential incorrect use and fault conditions

Pro-Ject products are manufactured to the highest standards and undergo strict quality controls before
leaving the factory. Faults that may possibly occur are not necessarily due to material or production faults but
can sometimes be caused by incorrect use. Some of these faults are as follows:
The platter doesn't turn although the unit is switched on:
The power cord is not connected to the unit.
The power cord is not plugged in to the AC wall outlet.
Broken fuse in the main switch.
Overheating protection is active.
Top clamp plate is not tightened properly.
How to adjust the height of VC-S' record clamp
The VC-S is pre-adjusted to spec for normal standard 80 g records. The vacuum arm works best when it is
parallel to the record when operating and the adhesive strips is pressed gently on the surface of record. If the
vacuum suction arm is not in the correct distance from the record it may not be able to completely vacuum the
cleaning fluid. In this case it may be necessary to adjust the height of the clamp. Especially 180 g pressing need
a different set up of the distance. You will need a Phillips screwdriver (to unscrew the set screw of the clamp
base part) and a 2.5mm hexagon key (to loosen motor spindle):
1. Disassemble the clamp (2) by unscrewing the set screw (3) from the motor flange spindle (11)
2. Insert the 2.5mm hexagon key into the hole on the side of motor flange (11)
3. Loosen the hexagon screw, until the flange can be moved up or down
4. When the correct height position is found, fasten the hexagon screw and mount the clamp (2)
You do not need to fully disassemble the flange from the motor!
6
© Pro-Ject Audio Systems · VC-S (starting with S/N
30 r.p.m.
230V/800W, 120V/650W
435 x 335 x 280 mm (fully assembled)
10,5kg (netto)
T5A/T6A
16F0003587
) · Revision 2016.09.06
