4.2.2 DVB-C/C2 and DVB-T/T2

Features of terrestrial tuners(DuoFlex
C/C2/T/T2):
Twin Tuner DVB-C features:
• Frequency range: 51-858 MHz
• Every modulation and code type compliant
to DVB-C specification
• Symbol rates from 0.87 to 6.9 Mbaud
• Sensitivity: 47dbμV (64QAM), 47dbμV
(256QAM)
• Master / slave mode Both tuners are being
supplied by an antenna cable
Standard connections:
• IEC socket (input), IEC connector (output)
• 20 pin Connector for ribbon cable

4.2.3 Mixed configuration

The modular design of the Octopus NET also enables a combination of DVB-S2, DVB-C/C2 and
DVB-T/T2 tuners in the same device. Since the DuoFlex extension is a twin tuner, 2 DVB-S2 and
2 DVB-C/C2/T/T2 tuner are configurable.

4.2.4 Common Interface (CI)

Standard connections:
• 20-pin connector for ribbon cable
• Power supply via a 4-pin floppy standard
connector
Twin tuner DVB-T/T2 features:
• Frequency range: 49-861MHz, 2k & 8k
OFDM
• All types of modulation compliant to DVB-T
and DVB-T2 specification
• Sensitivity: -82.6 dBm at 16 - QAM & 3/4
Security:
• Produced and Designed compliant to
European Standards DIN EN ISO 9001:2000
Environmental standards:
• RoHS Konformität
• WEEE DE 99353762
Security:
• Produced and Designed compliant to
European Standards DIN EN ISO 9001:2000
Environmental standards:
• RoHS Compliance
• WEEE DE 99353762
13
