4. Commissioning

4.1 Network Environment

The Octopus Net can be used in network environments with LAN, WLAN and PowerLan. For
trouble-free operation we recommend explicitly the following connection speeds:
LAN 100 Mbit/s network, recommended 1000 Mbit/s (GigaBit) environment
Wi-Fi 54 Mbit/s network, recommended 300 Mbit/s network environment
PowerLan 54 Mbit/s network, recommended 300 Mbit/s network environment
The five ports of the integrated Gigabit switch should preferably be used for terminal devices
with SAT > IP Client, since they already have the ideal Quality of Service (QoS) configuration
for the operation of SAT> IP as a factory setting.

4.2 Input signal

One asset of our Octopus NET is the modular design and expandability for more tuner
modules. Depending on the model, the DuoFlex S2 (DVB-S2) and DuoFlex C/C2/T/T2 (DVB-C /
DVB-C2 / DVB-T / DVB-T2) series of Digital Devices can be used as a tuner.
Technical specifications of different tuner modules and the Common Interface:

4.2.1 DVB-S/S2

Satellite features (DuoFlex S2):
Twin Tuner
• Symbol rate: up to 45Msps DVB-S2
• LNB Power: +14 VDC or +18 VDC or without
power supply (up to 500mA)
• L-band: 950 MHz to 2150 MHz DVB FEC:
(Auto Spectral Detection)
• Modulation QPSK/8PASK
• Full support of DiSEqC 2.X
Standard connections:
• 20 pin connector for ribbon cable
• L-band F-connectors (IEC 60169-24)
(Supports power supply to the LNB)
12
Unicable compliant:
• SCR / CENELEC EN 50494 (unicable ®)
Security:
• Produced and Designed compliant to
European Standards DIN EN ISO 9001:2000
Environmental standards:
• RoHS Konformität
• WEEE DE 99353762
