Introduction
First of all, many thanks for purchasing this Sweex 2 Port Serial ATA PCI Card. This card enables you to simply add two Serial ATA ports to your PC.
This card at the same time offers you the option of using these externally, internally or a combination of the two.
To ensure this product operates correctly, we advise you to carefully read this manual first. If despite this manual you still experience problems during
installation or operation of this product, go to www.sweex.com and look under the heading service & support.
Contents of the box
Prior to installation, check if all required parts are present. The following parts must be present in the box:
• 2 port serial ATA PCI card
• 1 x Serial ATA cable
• 1 x Serial ATA power to molex connection
• CD-ROM with manual and driver
If one of the above parts is missing, please contact the retail outlet.
Specifications
• Supports: Serial ATA 1.0 standard
• Dual independent DMA channels including 256 KB buffer
• PCI revision 2.2
• Supports: a maximum of 2 S-ATA hard disks, S-ATA 150 standard
• Maximum data speed S-ATA: 150 MB/s
• Supports: Windows 2000 and XP
PU100 Sweex 2 Port Serial ATA PCI Card
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SWEEX PU100
Summary of Contents for SWEEX PU100
-
Page 1: Specifications
Introduction First of all, many thanks for purchasing this Sweex 2 Port Serial ATA PCI Card. This card enables you to simply add two Serial ATA ports to your PC. This card at the same time offers you the option of using these externally, internally or a combination of the two. - Page 2 English version English version Hardware Take the following precautionary measures prior to installing the hardware: 1. Ensure the PC is switched off and disconnected from the mains. 2. Also, disconnect the printer and monitor cables (they have their own power supplies) to make absolutely sure the PC is not live. 3.
- Page 3 In the next screen, select “Install from a list or specific location” and click “Next”. Tick the second option: “Include this location”. Insert the Sweex CD-ROM in the CD-ROM player. Go to the Sweex CD-ROM via “Browse”, and select the folder “Drivers”. In this folder, select the relevant operating system; winxp or win2k. Then click “Next”.
- Page 4 Port settings The Sweex 2 Port Serial ATA RAID PCI Card contains 4 visual Serial ATA connectors. Two of these can be used at the same time. You can opt to connect Serial ATA devices externally, internally or a combination thereof.
