Specifications

Note
Specification and design are subject to change without
notice
Video
Signal system: PAL / NTSC
Composite video output: 1 Vpp ~ 75 ohm
Component video output: 0.7 Vpp ~ 75 ohm
Audio
Analog stereo output
Signal to noise ratio (1 kHz): > 95 dB
(A-weighted)
Dynamic Range (1 kHz): > 80 dB (A-weighted)
Crosstalk (1 kHz): > 80 dB
Distortion/noise: (1 kHz): > 75 dB
MPEG MP3: MPEG Audio L3
Digital output
Coaxial
Main unit
Dimensions (w x h x d): 360 x 39 x 209 (mm)
Net Weight: approximately 1.43 kg
Power
Power supply rating: AC 110 - 240V~, 50/60HZ
Power consumption: 10 W
Power consumption in standby mode: < 1 W
Accessories supplied
Remote control and batteries
Audio/Video cables
AC power cord
User Manual
Laser specification
Type: Semiconductor laser InGaAIP (DVD),
AIGaAs (CD)
Wave length: 655 nm (DVD), 790 nm (CD)
Output Power: 7.0 mW (DVD), 10.0 mW
(VCD/CD)
Beam divergence: 60 degrees

9 Troubleshooting

Warning
Risk of electric shock. Never remove the casing of the
product.
To keep the warranty valid, never try to repair the
product yourself.
If you have problems using this product, check the
following points before you request service. If you
still have a problem, register your product and get
support at www.philips.com/welcome.
If you contact Philips, you will be asked for the model
and serial number of your product. The model
number and serial number are on the back of your
product. Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Main unit
The buttons on this unit do not work.
Disconnect this product from the power
outlet for a few minutes, then connect again.
No reaction to the remote control.
Connect this product to the power outlet.
Point the remote control at the IR sensor
located on the front panel of this product.
Insert the batteries correctly.
Insert new batteries in the remote control.
No picture.
See the TVs user manual on how to select
the correct input on the TV. Change the TV
channel until you see the Philips screen.
If you have turned on the progressive scan
setting or change the TV system setting,
switch back to default mode: 1) Press to
open the disc compartment. 2) Press the
Numeric button '1' (for progressive scan) or
the Numeric button'3' (for TV system).
EN
17
