SAFETY PRECAUTIONS
Read all the instructions carefully before using the unit and keep them for future reference.
-
Check that the voltage marked on the rating label matches your mains voltage.
-
Location of Unit
The unit must be placed on a flat stable surface and should not be subjected to vibrations.
-
Do not place the unit on sloped or unstable surfaces as the unit may fall off or tip over.
-
The mains socket must be located near the unit and should be easily accessible.
-
-
Avoid extreme degrees of temperature, either hot or cold Place the unit well away from heat sources
such as radiators or gas/electric fires. Avoid exposure to direct sunlight and other sources of heat.
Never place any type of candle or naked flame on the top of or near the unit.
-
-
To reduce the risk of fire, electric shock or product damage, do not expose this unit to rain, moisture,
dripping or splashing. No objects filled with liquids, such as vases, should be placed on the unit.
If you spill any liquid into the unit, it can cause serious damage. Switch it off at the mains
-
immediately. Withdraw the mains plug and consult your dealer.
To prevent the risk of electric shock or fire hazard due to overheating, ensure that curtains and other
-
materials do not obstruct the ventilation vents.
-
Do not install or place this unit in a bookcase, built-in cabinet or in another confined space, ensure
that a minimum of 10cm should be kept around the apparatus for ventilation.
Safety
Always disconnect the unit from the mains supply before connecting/disconnecting other devices or
-
moving the unit.
Unplug the unit from the mains socket during a lightning storm.
-
This unit will become warm when used for a long period of time. This is normal and does not
-
indicate a problem with the unit.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOLTAGE
Conductor dangerous voltage, that may be of sufficient magnitude to constitute a risk of electric
shock to persons is present within this product's enclosure.
ATTENTION
The owner's manual contains important operating and maintenance instructions, for your
safety, it is necessary to refer to the manual.
Mains Cable
Make sure the unit is not resting on top of the mains cable, as the weight of the unit may damage the
-
mains cable and create a safety hazard.
If the mains cable is damaged it must be replaced by the manufacturer, its service agent, or similarly
-
DENVER IR-100
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ENG-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IR-100 and is the answer not in the manual?

Questions and answers

Related Manuals for Denver IR-100

Summary of Contents for Denver IR-100

  • Page 1 DENVER IR-100 SAFETY PRECAUTIONS Read all the instructions carefully before using the unit and keep them for future reference. Check that the voltage marked on the rating label matches your mains voltage. Location of Unit The unit must be placed on a flat stable surface and should not be subjected to vibrations.
  • Page 2 qualified persons in order to avoid a hazard. Interference The normal function of the product may be disturbed by Strong Electro Magnetic Interference. If so, simply reset the product to resume normal operation by following the instruction manual. In case the function could not resume, please use the product in other location.

  • Page 3: Features And Controls

    FEATURES AND CONTROLS SPEAKER MEMORY BUTTON 14. HEADPHONE JACK MODE BUTTON 15. AUX IN JACK BUTTON LCD DISPLAY INFO BUTTON 16. USB DEVICE IN PORT SCROLL CONTROL/ 10. BACK BUTTON 17. NETWORK SOCKET SELECT BUTTON 11. MENU BUTTON 18. DC CORD SOCKET VOLUME+ BUTTON 12.

  • Page 4: Battery Precautions

    PUTTING THE BATTERY INTO THE REMOTE CONTROL Press the battery compartment gently according to the direction indicated in the illustration. Slide to open the battery compartment. Insert the supplied CR2032 battery into the compartment according to the polarity markings ("+" and "-") inside the compartment and on the battery.
  • Page 5 toggles between alarms in standby. When playing, standby after a set time. SLEEP/SNOOZE When alarm is sounding, snooze for a set time. Press for the Preset recall/Save menu, Scroll up/down to select the preset MEMORY number then press Select to confirm. On unit, Turn to scroll through a menu or station list.

  • Page 6: Setup And Connection

    SET UP & CONNECTION Mains Connection Connect the AC power cord to the unit via the AC socket at the back. Plug the AC power cord to the AC mains outlet. Network Connection Wired network Check first of all whether the control lamps (LINK/ACT) of your LAN connection or your router light Use an Ethernet cable with RJ45 connector to connect the NETWORK socket of the radio with the LAN port of your router.
  • Page 7 Auto update The auto update works with data sent over DAB, FM or the Internet. The clock is only updated when in a corresponding mode, so it is recommended to select a mode that you use regularly. Select auto update from DAB, FM or Network. Select the appropriate time zone if the auto update is done by the Internet.
  • Page 8 Standard encrypted network To enter the network key (password), rotate the SELECT control to move the cursor through the characters to be selected and press on it to confirm. The key that is entered will be displayed in the upper part of the display. WPS-encrypted network WPS-encrypted networks are identified by their network names as soon as the unit starts searching for available network connection.
  • Page 9 Factory reset Perform a factory reset returns the unit to factory settings. All manual settings such as time, date, network configuration and presets are deleted. The radio's current software version is not affected and remains as it was registered in the Internet-Radio- Portal.
  • Page 10 Internet Radio This radio can play thousands of radio stations and podcasts from all over the world via a broadband internet connection. When the Internet Radio mode is selected, the radio connects with the Frontier Silicon Internet radio portal to download a list of stations. Once a station is selected, the radio will connect directly to that station.
  • Page 11 selecting "Station list>My added stations>[Station]" Presets Presets are stored in the radio and cannot be accessed from other radios. To store an Internet radio preset, press and hold the MEMORY button until the display shows the "Save to Preset" screen. Select one of the 10 presets to store the current station. To select a preset, press the MEMORY button once, then select one of the listed preset stations.
  • Page 12 Music Player The Music Player mode plays audio files such as MP3s, AACs, WMAs or FLACs from a computer on the local network. In order for the radio to play music files from a computer, the computer must be set up to share files or media.
  • Page 13 album, composer and rating. Once you have located a track you want to play, press on the SELECT control, USB Playback Insert the USB into the port at the rear. The display will show: "USB disk attached-open folder? (Yes or No) Select "Yes".
  • Page 14 Prune servers From time to time it may be necessary to remove servers displaying question marks in front of the server name from the server list. To perform this function, go to the "Prune servers" section and select YES. Repeat/Shuffle You can repeat tracks or play them in random order by selecting "Repeat play"...
  • Page 15 and their associated frequencies. When your desired frequency appears in the display, press on the SELECT control to confirm. DRC (Dynamic range compression) If you are listening to music with high dynamic range in a noisy environment, you may wish to compress the audio dynamic range.
  • Page 16 Selecting stations To search for a station, press on the SELECT control once, the radio will start to scan up the frequency band, and it will stop automatically once a station has been found. Alternatively, you can also press and hold the button to scan up or down the frequency band.

  • Page 17: Alarms And Sleep

    ALARMS AND SLEEP Alarms There are two wake-up alarms with snooze function and one sleep function to turn the radio off after a set period. Each alarm can be set to start in a particular mode. To set or change an alarm: Select either Alarm 1 or 2 in the main menu or press the ALARM button on the remote control.

  • Page 18: Headphone Jack

    Sleep To activate the sleep function, either select it in the main menu by the use of the SELECT control or repeatedly pressing on the SLEEP button. The display will show the sleep time and you can choose from: Sleep Off, 15, 30, 45, 60, 75, 90 minutes. Once the sleep time has been set, it will return to the main menu.
  • Page 19 ALL RIGHTS RESERVED, COPYRIGHT DENVER ELECTRONICS A/S Electric and electronic equipment and included batteries contains materials, components and substances that can be hazardous to your health and the environment, if the waste material (discarded electric and electronic equipment and batteries) is not handled correctly.
