Standalone DVR
SEC-DVR304
User's Manual
Default Account & Password for SEC-DVR304
User Account: [ aa ]
-
Password
: [11 ]
-

Advertisement

Table of Contents
loading

Related Manuals for Konig SEC-DVR304

Summary of Contents for Konig SEC-DVR304

  • Page 1 Standalone DVR SEC-DVR304 User’s Manual Default Account & Password for SEC-DVR304 User Account: [ aa ] Password : [11 ]...

  • Page 2: Table Of Contents

    Standalone DVR SEC-DVR304 User Manual 【 【 【 【 Table of Contents】 】 】 】 Package Content ....................4 Feature ........................5 Specification......................6 Hardware Introduction And Installation ............... 8 SEC-DVR304 Front view................8 SEC-DVR304 Back view ................10 Remote controller ..................11 Standalone DVR Utility Installation &...
  • Page 3 Standalone DVR SEC-DVR304 User Manual 7.6.10.2 FTP Setting ................59 7.10.3 Advance Network Setting ............60 System Shutdown (Administrator) ............... 61 PTZ Control......................62 Software Upgrade ....................68 Search & Playback..................69 10.1 Search By Time ................... 70 10.2 Search By Event / Log Display ..............71 10.3...

  • Page 4: Package Content

    Standalone DVR SEC-DVR304 User Manual Package Content 1-1. SEC-DVR304------------------------------ x1 1-2. Remote Controller ------------------------ x1 1-3. AAA Battery ------------------------------- x2 1-4. Screws ------------------------------------- x4 1-5. CD ------------------------------------------ x1 1-6. Quick Reference--------------------------- x1 1-7. User Manual on CD----------------------- x1 1-8. Power Adapter ---------------------------- x1 1-9.

  • Page 5: Feature

    Standalone DVR SEC-DVR304 User Manual Feature ■ H.264 Compression for better video quality & smaller record size ■ 4CH H.264 DVR with Sixplex operation (live, record, playback, backup, control, & remote access) ■ Support DDNS ■ Up to D1 resolution ■...

  • Page 6: Specification

    Standalone DVR SEC-DVR304 User Manual Specification Model SEC-DVR304_4ch System O.S. Embedded Linux 2.6 Multiplex Sixplex operation - simultaneous record, live, playback, backup, control, & remote access Processor Multiple Certification FCC, CE Video Format NTSC/ PAL Input 4-CH, BNC, 1Vp-p/75ohm Main monitor...
  • Page 7 Standalone DVR SEC-DVR304 User Manual E-mail Alarm notification to stationary or mobile devices Alarm video/audio file storage Video 1/4 split-window & SEQ mode for I.E. Audio Two way audio and Audio Broadcasting Protocol TCP/IP, HTTP, PPPoE, DHCP, DDNS, FTP, TSP...

  • Page 8: Hardware Introduction And Installation

    Standalone DVR SEC-DVR304 User Manual Hardware Introduction And Installation SEC-DVR304 Front view Name Description Alpha-numeric Buttons (1-4) Press these buttons for camera selection in most of the circumstances. These buttons can also be used to enter text and number in the way similar to most of the mobile phones.
  • Page 9 Standalone DVR SEC-DVR304 User Manual MENU / ESC Button Press this button to display the main menu or escape to the upper level display. PTZ Button In main screen display, press this button to enter/exit PTZ control if the focus camera is a PTZ camera.

  • Page 10: Sec-Dvr304 Back View

    Standalone DVR SEC-DVR304 User Manual SEC-DVR304 Back view Name Description Video Input Connectors (1-4) Connect system cameras to these BNC connectors. The internal 75 termination is always ON. Call Monitor Output Connector Connect TV monitor to this BNC connector for call monitor (CALL OUT) display.

  • Page 11: Remote Controller

    Standalone DVR SEC-DVR304 User Manual (ALARM IN 1-4) sensors or door switches. Alarm Output Connectors Connect NC connectors (left) to Normally Closed (NC) (ALARM OUT NC(1)/NO(2)) alarm output, or NO connectors (right) to Normally Open (NO) alarm output. Please note that only one of the NC or NO connectors can be connected only.
  • Page 12 Standalone DVR SEC-DVR304 User Manual Function Click to add an audio recording feature. Click to switch between GPS (POS: option) Display and to reconfigure the display setting. (Please refer to Chapter 7.6.9 RS-232 / 422 / 485NOTE 2 for detail setup)

  • Page 13: Standalone Dvr Utility Installation & Manual

    Standalone DVR SEC-DVR304 User Manual Standalone DVR Utility Installation & Manual 4.4.1 Utility Installation Insert the Installation CD into the CD-ROM. Execute ‘’Autorun.exe’’. Next Click on ‘’Utility’’ button. * AVI Converter can convert the backup file from Standalone into AVI file.
  • Page 14 Standalone DVR SEC-DVR304 User Manual 4.4.2 Manual Click on ’’Manual’’ button. Click on ‘’English Version‘’ button to view English Manual.

  • Page 15: Basic Connections

    Standalone DVR SEC-DVR304 User Manual Basic Connections Please refer to the following diagram for the connections. Please make sure to set the NTSC/PAL Selector Switch on the main board according to the local TV system for the system to work correctly.
  • Page 16 Standalone DVR SEC-DVR304 User Manual Hard disk drive Make sure to install at least one SATA hard disk drive inside the DVR. The steps are as below: 1. Power off the machine, and then use a screwdriver to uncover it 2.

  • Page 17: Optional Connections

    Standalone DVR SEC-DVR304 User Manual Power Connect DC 12V power source to DC 12V Input. I/R remote controller The user may use I/R remote controller to control the digital video/audio recorder. Optional Connections Ethernet Connect the Ethernet connector to a standard twisted-pair Ethernet cable for remote access via LAN or internet.
  • Page 18 Standalone DVR SEC-DVR304 User Manual PTZ Cameras Connect the RS-232 connector or the RS-485 connector to PTZ camera(s) via the appropriate cable. The system supports a variety of different PTZ cameras, including Pelco D protocol Dome, SamSung SCC-641P, Kalatel Cyber Dome, Bosch AutoDome, etc. But different PTZ cameras can coexist in a system only if they support the same protocol.

  • Page 19: Basic Operation

    Standalone DVR SEC-DVR304 User Manual Basic Operation Text Input Press ▲▼◄► to highlight the text to be edited then press Enter to call up the alpha-numeric text pad. Name Description Press to enter the available number. Press to enter the available number and letter shown on the screen.

  • Page 20: Basic Operations

    Standalone DVR SEC-DVR304 User Manual Basic Operations The basic user’s operations after he/she has logged into the system are described below: Numeric (Mouse: Press these buttons to switch to the full-window display for the camera. If the camera already exists in the other window, the focus window will exchange with that window for cameras.
  • Page 21 Standalone DVR SEC-DVR304 User Manual MENU (Mouse: In split-window display, press this button to display the versatile menu. (Mouse: In split-window display, press this button to enter PTZ control mode if the focus camera is a PTZ camera. (Mouse: In full screen display, press this button to enter Digital Zoom mode. Please refer to Chapter 5.3 Digital Zoom for the detailed operations in Digital Zoom mode.

  • Page 22: Digital Zoom

    Standalone DVR SEC-DVR304 User Manual Digital Zoom The system supports X2/X4 Digital Zoom function. To use this function, press X2 button (Mouse: in full screen display to enter Digital Zoom mode. There will be a zoom window shown in the video window as shown. The zoom window (a) will always be shown at zoom factor X1, (b) can be shown or hidden at zoom factor X2, and (c) will never be shown at zoom factor X4.

  • Page 23: Main Screen

    Standalone DVR SEC-DVR304 User Manual Main Screen Name Description Video Screen Display live/playback video. Camera ID Shows ID number of the camera. Time / Date Shows the current recording time and date. Audio When audio is turned on, audio icon will be displayed on the screen.

  • Page 24: Menu

    Standalone DVR SEC-DVR304 User Manual Menu Press menu (Mouse: ring up a list of function setting menu. to b There are a variety of displays under Menu display. Please refer to chart as below: (Please refer to Chapter 7.1 Login / Logout for Login/Logout display. ) ▲▼◄►...

  • Page 25: Login / Logout

    Standalone DVR SEC-DVR304 User Manual Press this button to escape from Menu display, and return to split-window display. Login / Logout In Menu display, press ▲▼ to change the highlighted option to Login / Logout, and then press ENTER (Mouse: Click in the menu item) to call up Login / Logout display as shown below.

  • Page 26: Status

    Standalone DVR SEC-DVR304 User Manual 7.2 Status In Menu display, press ▲▼ to change the highlighted option to Status, and then press ENTER to call up Status display as shown below. This page will display the status of the system in terms of alarm and normal record size, camera status, hardware and software version.

  • Page 27: Video Adjustment

    Standalone DVR SEC-DVR304 User Manual NOTE: If you forget Login Account and Password of SEC-DVR304, please mail the data of framed area 5,6,7 ( ) to Nedis Serial Number, Hardware & Software version Video Adjustment In Menu display, press ▲▼ to change the highlighted option to Video Adjustment, and then press ENTER to call up Video Adjustment display as shown below.

  • Page 28: Vga Display

    Standalone DVR SEC-DVR304 User Manual 7.4 VGA Display In Menu display, press ▲▼ to change the highlighted option to VGA Display, and then press ENTER to call up VGA Display dialog as shown below. This section explains how to adjust the Resolution, Brightness, Contrast, Hue and Saturation of VGA display quality.

  • Page 29: Backup Device

    Standalone DVR SEC-DVR304 User Manual 7.5 Backup Device In Menu display, press ▲▼ to change the highlighted option to Backup Device, and then press ENTER to call up Backup Device display as shown below. This window allows user to view the connection status of the backup device and to initiate data backup.

  • Page 30: Backup Setting

    Standalone DVR SEC-DVR304 User Manual 7.5.1 Backup Setting Click on CALL / COPY to access the Backup setting. ▲▼◄► Press these buttons to select the items. Name Description Backup Device The backup device connected to the system. Press ENTER on the left button to call up Backup Device dialog if there’s no backup device connected.
  • Page 31 Standalone DVR SEC-DVR304 User Manual End Time (Year, Month, Date, Hour, Minute) for the recorded video/audio for the backup without playback of Search By Time. The files will be backup from the start time to the end time when the user press the COPY button to start copying.
  • Page 32 Standalone DVR SEC-DVR304 User Manual USB 2.0 Storage Devices (Pen Drive)–USB-Storage Enclosures 5.25” – Macpower’s Alumni Prefect USB 2.0 - PF-U2MS. USB-Disk Storage – Transcend’s JetFlash 150/V60 Series, JetFlash V33 8GB Apacer’s Handy Steno AH220 Pretec’s i-Disk Wave 512M-Black Kingston’s DataTraveler USB Flash Driver(DTI/512FE) Kingston’s DataTraveler DT100 8GB...

  • Page 33: Setup

    Standalone DVR SEC-DVR304 User Manual Note : For each camera and each backup, a batch file will be generated as well as the backup files. A directory “/SelfPlayer” will also be generated if it’s not existing in the backup storage device. The user can use the batch file to self-playback the corresponding backup files in a PC.
  • Page 34 Standalone DVR SEC-DVR304 User Manual In Menu display, press ▲▼ to change the highlighted option to Setup, and then press ENTER (Mouse: Left click) to call up Setup display as shown below. (To enter Setup Menu display of the system, please login as Administrator first.) ▲▼...

  • Page 35: Pre-Camera

    Standalone DVR SEC-DVR304 User Manual Password System RS-232 / 422 / 485 Network Factory Default If the user wants to reset all the settings to factory default values, he/she may press ▲▼◄► to change the highlighted option to Factory Defaults, and then press ENTER.

  • Page 36: Camera

    Standalone DVR SEC-DVR304 User Manual Press this button to escape from this screen, and return to previous display. Name Description REC Resolution Press to adjust the recording resolution to 360x240, 720x480 or 720x240. Watermark to record with digital watermark or not. If yes, all the recorded images for all the cameras will have digital watermark embedded.
  • Page 37 Standalone DVR SEC-DVR304 User Manual (Mouse: Left click) ▲▼◄► Press these buttons to select the items. Numeric (Mouse: Press these buttons to select the camera. COPY Press this button to copy all the settings - excluding detailed Motion settings, Video Loss settings, Title/Audio - of the focus camera to all the following cameras.

  • Page 38: Video Loss Setting

    Standalone DVR SEC-DVR304 User Manual Call By Event This feature will cause a specified channel to display upon a (Call Monitor) specific event trigger. Dwell Time User may adjust the value to determine the display time of the call monitor.

  • Page 39: Motion Setting

    Standalone DVR SEC-DVR304 User Manual display. Name Description Duration Press to adjust the length of warning period upon video loss trigger. Camera to go the camera to go to the preset position in next field after video loss is detected for this camera. “Camera to go” camera must be a PTZ camera.
  • Page 40 Standalone DVR SEC-DVR304 User Manual (Mouse: Left click) ▲▼ Press these buttons to select the items. Numeric (Mouse: Press these buttons to select the camera. COPY Press this button to copy the Video Loss settings of the focus camera to all the following cameras.
  • Page 41 Standalone DVR SEC-DVR304 User Manual Post-record Press to adjust the transition period before initiating the recording after motion detection. Alarm Out Press to select the motion triggered alarm output. Detection This setting allows user to define the area for motion to be (Settings..)

  • Page 42: Alarm

    Standalone DVR SEC-DVR304 User Manual Name Description 1 【 】 Click to resize the motion detection area. Enter Press to set/reset the changes made. Press to exit the setting. MODE Press to set/reset the whole area as the motion detection zone.
  • Page 43 Standalone DVR SEC-DVR304 User Manual (Mouse: Left click) ▲▼◄► Press these buttons to select the items. Numeric (Mouse: Press these buttons to select the camera. COPY Press this button to copy the Video Loss settings of the focus camera to all the following cameras.

  • Page 44: Seq Display Setup

    Standalone DVR SEC-DVR304 User Manual recording after an event trigger. Alarm out Click to select the alarm output triggered by a specific event. Buzzer Press Enter or to check( ) / uncheck (-) this item. To activate the buzzer warning due to an alarm trigger.

  • Page 45: Scheduled Record

    Standalone DVR SEC-DVR304 User Manual Name Description Total Pages Press to set the total of display channels for each screen. Dwell Time Press to set the display time (3~60 seconds) of each camera for each sequential rotation. Page setting - Use the numeric buttons...

  • Page 46: Hdd

    Standalone DVR SEC-DVR304 User Manual Name Description Start Time Press to set the recording start time. NOTE: User can set up to a maximum of 16 different schedule segments. The beginning of the new schedule segment represents the end of the previous schedule segment.
  • Page 47 Standalone DVR SEC-DVR304 User Manual (Mouse: Left click) ▲▼◄► Press these buttons to select the items. Press this button to escape from this screen, and return to previous display. If the Save dialog will be shown to ask the user to save the changes, press ENTER to exit and save, ESC to exit without saving.
  • Page 48 Standalone DVR SEC-DVR304 User Manual Alarm Out Click to select the alarm output triggered due to HDD capacity shortage. Buzzer Click Enter or to check( ) or uncheck (-) this item. To activate the buzzer warning that is triggered due to HDD capacity shortage.
  • Page 49 Standalone DVR SEC-DVR304 User Manual ▲▼◄► Press these buttons to select the items. Press this button to escape from this screen, and return to HDD Setup display. If the Save dialog is shown, press ENTER to exit and save, ESC to exit without saving.
  • Page 50 Standalone DVR SEC-DVR304 User Manual Click to clear the HDD. Note: If the HDD has not been formatted yet, it will be formatted and partitioned with default record size, 30% for Alarm record and 70% for Normal record. If it has been...
  • Page 51 Standalone DVR SEC-DVR304 User Manual ▲▼ Press these buttons to select the items. Press this button to escape from this screen, and return to HDD Setup display. If the Save dialog is shown, press ENTER to exit and save, ESC to exit without saving.

  • Page 52: Password

    Standalone DVR SEC-DVR304 User Manual 7.6.7 Password In Setup display, press ▲▼ to change the highlighted option to Password, and then press ENTER to call up Password Setup display as shown below. ▲▼◄► Press these buttons to select the items.

  • Page 53: System Setup

    Standalone DVR SEC-DVR304 User Manual login name/password will be the default one each time the login dialog is shown, so the user doesn’t bother to enter the text to login the system. Note: it’s recommended with first use, to change the password and login for the 7.6.8 System Setup...

  • Page 54: 422 / 485

    Standalone DVR SEC-DVR304 User Manual time according to the time zone selected. System Time Synchronization Click to synchronize the system time with the TSP server time. Time TSP Server Type in the TSP server address. Date Press to adjust the date.
  • Page 55 Standalone DVR SEC-DVR304 User Manual Press to select the appropriate device. Please note that PTZ can only be selected for either RS-232 or RS-422/485, but not both. Model Press to select the appropriate model for the device. (Please refer to NOTE 1.)

  • Page 56: Network

    Standalone DVR SEC-DVR304 User Manual 7.6.10 Network In Setup display, press ▲▼ to change the highlighted option to Network , and then press ENTER to call up Network Setup as shown. The Network Setup allows the administrator to setup all Ethernet network related parameters.
  • Page 57 Standalone DVR SEC-DVR304 User Manual Service Provider). (Please refer to Chapter 5.1 Text Input for text/numeric entry) Net Mask Press Enter to edit the net mask. (Please refer to Chapter 5.1 Text Input for text/numeric entry) Gateway Press Enter to edit the gateway IP. (Please refer to Chapter 5.1 Text Input for text/numeric entry)

  • Page 58: Email Setting

    Standalone DVR SEC-DVR304 User Manual 7.6.10.1 Email Setting In Network Setup, press ENTER to call up E-mail Setup as shown when the highlighted option is E-mail. The E-mail Setup allows the administrator to set e-mail related parameters. When an event occurs and E-mail is enabled for the corresponding action, an e-mail will be sent based on the parameters set here.

  • Page 59: Ftp Setting

    Standalone DVR SEC-DVR304 User Manual 7.6.10.2 FTP setting In Network Setup, press ▲▼ to change the highlighted option to FTP, and then press ENTER to call up FTP Setup as shown. The FTP Setup allows the administrator to set FTP related parameters.

  • Page 60: Advance Network Setting

    Standalone DVR SEC-DVR304 User Manual 7.6.10.3 Advanced Network Setting In Network Setup, press ENTER to call up Advanced Network Setup as shown when the highlighted option is Adv.. The Advanced Network Setup allows the administrator to set advanced network parameters. If the user is not familiar with network administration, please DO NOT modify the items in this dialog.

  • Page 61: System Shutdown (Administrator)

    Standalone DVR SEC-DVR304 User Manual DVR. Please follow the Text Input method described in chapter 5.1 Text Input to modify this item. CMS Server URL The URL (Uniform Resource Locators) for the CMS #1-2 Server #1 and #2. The DVR will connect with up to two CMS servers automatically once it’s running.

  • Page 62: Ptz Control

    Standalone DVR SEC-DVR304 User Manual PTZ Control Step 1. Connect DVR and PTZ Camera as below diagram. Connect the RS-485 connector to PTZ camera(s) via the appropriate cable. (Please refer to Section 4.6 Option Connections_PTZ Cameras)
  • Page 63 Standalone DVR SEC-DVR304 User Manual Step 2. Adjust the DIP SWITCH on the bottom of the Speed Dome PART User can select the control protocol / baud rate and address of the speed dome by adjusting DIP SWITCH on the bottom of the Speed Dome PART.
  • Page 64 Standalone DVR SEC-DVR304 User Manual Step 3. DVR Settings of PELCO-D Test PTZ Camera already connected sucessfully. Access to Setup operation of DVR standalone system then choose Pre-Camera Setup. Once PTZ Camera hardware is connectted successful then it will show the number of PTZ Camera that you connected.
  • Page 65 Standalone DVR SEC-DVR304 User Manual Press (on DVR remote controller) to set the Baud Rate to be 2400. (That’s the key point to let standalone DVR & Speed Dome communicate each other.) Step 4. Press the PTZ button DVR remote controller to confirm (Mouse: PTZ function.
  • Page 66 Standalone DVR SEC-DVR304 User Manual (Mouse: Left-click in the left/right area of the video window) ◄► Press these buttons to pan the camera left/right. ZOOM ( ) +/- (Mouse: Press these buttons to zoom in/out the camera. GOTO (Mouse: keypad hint Press this button to move the camera to the preset position.
  • Page 67 Standalone DVR SEC-DVR304 User Manual Miscellaneous function specific operations: Active function Operations Descriptions Focus focus far/near (Mouse: ENTER auto focus (Mouse: Iris Iris increase/decrease (Mouse: Auto Pan (3) Auto pan speed is shown in ENTER parenthesis (Mouse: increase/decrease speed start/stop Auto Pan...

  • Page 68: Software Upgrade

    Standalone DVR SEC-DVR304 User Manual Software Upgrade In Menu display, press ▲▼ to change the highlighted option to Software Upgrade, and then press ENTER to call up Software Upgrade display as shown below. User can upgrade the software from the upgrading files stored inside the external storage media such as DVD, SD card or USB flash drive.

  • Page 69: Search & Playback

    Standalone DVR SEC-DVR304 User Manual 10 Search & Playback There are five ways to search the recorded video/audio for playback: (a) Search by time, (b) Search by event, (c) Smart search, (d) Search archived files In split-window display, press SEARCH button to call up Search Menu display as shown.

  • Page 70: Search By Time

    Standalone DVR SEC-DVR304 User Manual 10.1 Search By Time This section explains how user can search for specific data by defining the date and time as the search criteria. ▲▼◄► Press these buttons to select the items. Press this button to escape from this screen, and return to Menu display.

  • Page 71: Search By Event / Log Display

    Standalone DVR SEC-DVR304 User Manual be shown. Please note that this kind of backup is performed in the background, and the user can still do almost all the operations. Recorded from 'Recorded from’ time based on the selected Video/Audio before searching - alarm partition if any of Alarm, Motion, or Video Loss, is checked, and normal partition if Normal is checked.

  • Page 72: Smart Search

    Standalone DVR SEC-DVR304 User Manual Please refer to Section 10.7 Playback For Search By Event for the detailed operations for event playback. Event Type Set the search criteria by selecting the types of event such as alarm trigger, motion trigger, video loss trigger and system event. The Event Type “System”...
  • Page 73 Standalone DVR SEC-DVR304 User Manual Name Description Target Camera Click to select the data source camera as the search criteria. Click Enter to access the target area setting and to define the motion Area trigger area criteria. The system allows the creation of multiple point motion detection zones.

  • Page 74: Search Archived Files

    Standalone DVR SEC-DVR304 User Manual 10.4 Search Archived Files This section explains how user can search for archived files stored in the external device. ▲▼◄► Press these buttons to select the items. Press this button to escape from this screen, and return to Menu display.

  • Page 75: Playback/Archive For Search By Time

    Standalone DVR SEC-DVR304 User Manual 10.5 Playback/Archive For Search By Time In split-window display, press MODE button to change circularly the live/playback mode for the focus window and the other windows that form a rectangle on the screen. The video windows for the windows in playback mode are grayed, while those in live mode display live video.
  • Page 76 Standalone DVR SEC-DVR304 User Manual Following is a brief description for the operations in Backup display: ▲▼◄► Press these buttons to select the items. Copy Button ( Press this button to start backup (copy) or apply the revised settings if it’s copying, and return to the previous display.
  • Page 77 Standalone DVR SEC-DVR304 User Manual Backup Speed 1-9, with 1 the lowest speed, 9 the highest speed. Press buttons to select the value. the directory in the backup device to store the archived files. Directory Please follow the Text Input method described in chapter 5.1 Text...

  • Page 78: Playback/Archive For Search By Event

    Standalone DVR SEC-DVR304 User Manual 10.6 Playback/Archive For Search By Event In Log display, press ENTER to enter Event Playback display of the selected event log, / II or press Play Buttons ( ) to playback it directly. This display is the same as full screen display of the main display, and the playback buttons are effective.

  • Page 79: Playback For Archived Files

    Standalone DVR SEC-DVR304 User Manual 10.8 Playback For Archived Files In Search Archived Files display, press ENTER to enter Archived File Playback display / II of the selected file, or press Play Buttons ( ) to playback it directly. This display is the same as full screen display of the main display, and the playback buttons are effective.

  • Page 80: Remote Access

    Standalone DVR SEC-DVR304 User Manual 11 Remote Access 11.1 Remote Access via Internet Explorer (IE) For remote access from another location it's important to know the IP address of the router of the location where the DVR is installed and connected to. To know your own IP address, please go to website: www.whatismyip.org or www.whatsmyip.org.
  • Page 81 Standalone DVR SEC-DVR304 User Manual Step3. Click on “Install”. Step4. Click on “Yes”. Step5. Click on “Install”.
  • Page 82 Standalone DVR SEC-DVR304 User Manual Step6. Type in the login name, password, control port and data port information to access the system. - The default login name: aa Password:11 Note: for establishing remote access it could be necessary to open port 67,68 and 80 in your router.

  • Page 83: Main Screen

    Standalone DVR SEC-DVR304 User Manual 11.1.1 Main Screen Name Description Camera ID Displays the ID of the camera. Video Screen This is to display both live and playback video. Date/Time This is to show the actual recording time and date of the video.
  • Page 84 Standalone DVR SEC-DVR304 User Manual This feature enables user to search for POS recorded POS Search: data according to the specified date and time. Click to upgrade the system. Software Upgrade: GPS Configuration enables user to customize the GPS Configuration: GPS setting.

  • Page 85: Search & Playback

    Standalone DVR SEC-DVR304 User Manual 11.1.2 Search & Playback 11.1.2.1 Search By Time This feature enables user to search for a video data playback according to specific date, time and event type search criteria. Name Description Event Type Check the type of video as the search criteria.
  • Page 86 Standalone DVR SEC-DVR304 User Manual Search By Event 11.1.2.2 This feature enables user to search for a video data playback according to the device, event type and camera source. Name Description Event List Window The window lists out all the events searched according to the criteria set.

  • Page 87: Ptz Control

    Standalone DVR SEC-DVR304 User Manual PTZ Control 11.1.3 Name Description PTZ control Click to control the pan / tilt / zoom of the PTZ speed dome. Focus Click to adjust the focus of the camera. Iris Click to adjust the camera iris.

  • Page 88: Server Configuration

    Standalone DVR SEC-DVR304 User Manual Server Configuration 11.1.4 This is for user to add new DVR, edit existing DVR and to delete DVR as well as configure the property of each DVR. Setup configuration of the specific DVR can be modified and uploaded to the respective DVR remotely.
  • Page 89 Standalone DVR SEC-DVR304 User Manual 11.1.4.2 Modify Server Press to modify the server information. STEP1: Delete all the information that is to be modified. STEP2: Then enter new information into their respective columns. STEP3: Then click OK to save changes.
  • Page 90 Standalone DVR SEC-DVR304 User Manual 11.1.4.4 Configure Server Property Press to enter the server configuration page. 11.1.4.4.1 Pre-camera Name Description Best REC Select to adjust the recording resolution. Resolution Watermark Click to watermark the video. Max ID Click to set the maximum number of camera available on a specific DVR.
  • Page 91 Standalone DVR SEC-DVR304 User Manual 11.1.4.4.2 Camera Name Description Title Assign a title to each camera for easy identification. Motion Detection Click to activate the motion detection feature for the specific camera. Covert Click to activate the covert feature for the specific camera.
  • Page 92 Standalone DVR SEC-DVR304 User Manual 11.1.4.4.3 Motion Name Description Camera ID Select the camera as a motion trigger. Duration Set the notification duration during motion detection. Goto Preset Set which camera preset location to be displayed upon a motion Pre-record Set the pre-recording time.
  • Page 93 Standalone DVR SEC-DVR304 User Manual 11.1.4.4.4 Video Loss Name Description Camera ID Select the camera as a video loss trigger. Duration Set the notification duration during video loss. Pre-record Set the pre-recording time. Alarm Output Select the alarm output notification during video loss.
  • Page 94 Standalone DVR SEC-DVR304 User Manual 11.1.4.4.5 Alarm Name Description Normal State Choose to turn on/off the alarm condition during normal state. Focus Camera Choose the focus camera upon an alarm trigger. Duration Set the alarm duration once it is triggered.
  • Page 95 Standalone DVR SEC-DVR304 User Manual 11.1.4.4.6 SEQ Display This configuration allows user to setup the order of the surveillance sequence of each DVR. Name Description Sequence Page Device Type Select the appropriate monitor for the surveillance Setting sequence. Window Type Select the number of display channel for each surveillance page.
  • Page 96 Standalone DVR SEC-DVR304 User Manual 11.1.4.4.7 Schedule Name Description T(x) This represents the number of schedule segment. ※ ※ ※ ※ User can set up to a maximum of 16 different schedule segments. The beginning of the new schedule segment represents the end of the previous schedule segment.
  • Page 97 Standalone DVR SEC-DVR304 User Manual 11.1.4.4.8 Name Description Alarm Record Auto Overwrite Select this will enable the overwritten of old data when the disk capacity is achieved. HDD Full Action Select this will enable full usage of HDD capacity. Duration User may set the duration of warning period.
  • Page 98 Standalone DVR SEC-DVR304 User Manual 11.1.4.4.9 Password This configuration allows administrator to assign login name and password to other users. Name Description User Information Administrator can create user accounts for other users by assigning login name, password and user level.
  • Page 99 Standalone DVR SEC-DVR304 User Manual 11.1.4.4.10 System Name Description Time zone Select the suitable time zone from the drop down menu. System time User can manually set the time of the system or set the system to synchronize its time with a specific standard time server.
  • Page 100 Standalone DVR SEC-DVR304 User Manual 11.1.4.4.11 RS232/422/485 Name Description RS-232 Select the appropriate device that uses the RS-232 signal, device model, camera ID, baud rate, data bit, stop bit and parity from the drop down menus. RS-422/485 Select the appropriate device that uses the RS-422/485 signal, device model, camera ID, baud rate, data bit, stop bit and parity from the drop down menus.
  • Page 101 Standalone DVR SEC-DVR304 User Manual 11.1.4.4.12 Network Name Description Net Type Choose the appropriate net type to configure. There are 3 types of net: Static IP, PPPoE and DHCP Static IP Type in the correct IP address, net mask, gateway and DNS.
  • Page 102 Standalone DVR SEC-DVR304 User Manual 11.1.4.4.13 Email Name Description SMTP Type in the server URL, username and password. Mail From Enter the email address of the sender. Mail To Enter the email address of the recipient. Attachment User can select the type of image to be attached to the mail.
  • Page 103 Standalone DVR SEC-DVR304 User Manual 11.1.4.4.14 FTP Name Description File Transfer Protocol Fill in the FTP server address, username and password. User may also choose to assign a prefix for each file to enable easy differentiation. Download This function enables user to download the original configuration from the host system should any accidental modification occur.

  • Page 104: Remote Access Via Pda

    This is an example using Nokia N73 Step 1 : Connect to internet by clicking on Web. Step 2 : Type in the IP address of the SEC-DVR304 system(refer to 7.7.10 Network) to access the connection page. http://(IP address of the SEC-DVR304)/wap.htm ex.
  • Page 105 Standalone DVR SEC-DVR304 User Manual Step 5 : Click on the camera number to view image of the camera. Finish your setting then click OK to view image of the camera. Figure 1 Key Descreption Display format: Display Channel 1/2/3/4 or 4 channel at a time.
  • Page 106 Standalone DVR SEC-DVR304 User Manual Step 1 Step 2 Step 3 Step 4 Step 5...

  • Page 107: Ie Remote Access Via Vista

    Standalone DVR SEC-DVR304 User Manual 11.3 IE Remote Access via Vista . Open IE browser. Click on “Tools” and go to “Internet Options”. Step1 Step2. (a) Click on “Security” tab (b) Click on “Trusted sites”. (c) Click on “Sites”...
  • Page 108 Standalone DVR SEC-DVR304 User Manual Step3. Enter the IP address of Standalone DVR. And untick the option on “Require server verification (https:) for all sites in this zone”. Then click on “Add”. The IP address is now save in Trusted sites. Click on “Close”.

  • Page 109: Appendix A -Time Zone

    Standalone DVR SEC-DVR304 User Manual Appendix A –Time Zone Time Zone Offset Start Samoa GMT – 11:00 Hawaii GMT – 10:00 Alaska GMT – 09:00 ˇ Mar, 2nd Sun, 2:00 Nov, 1st Sun, 2:00 Pacific Time (US & Canada) GMT – 08:00 ˇ...
  • Page 110 Standalone DVR SEC-DVR304 User Manual Tehran GMT + 03:30 ˇ Mar, 4th Tue, 2:00 Sep, 4th Thu, 2:00 Abu Dhabi, Muscat GMT + 04:00 Baku, Tbilisi, Yerevan GMT + 04:00 ˇ Mar, last Sun, 2:00 Oct, last Sun, 3:00 Kabul...

  • Page 111: Appendix B - Recording Table Reference (Pal)

    Standalone DVR SEC-DVR304 User Manual Appendix B – Recording Table Reference (PAL) PAL Recording Time (in Hour) - For Reference Only System Storage (GB): 200 Average Recording Rate (IPS) Resolution Quality Picture Size (KB)* 100 50 12.5 36.0 720x576 (Full D1) 32.0...

  • Page 112: Appendix C -Standalone Dvr Access Via Router Setting

    Standalone DVR SEC-DVR304 User Manual Appendix C –Standalone DVR access via router setting Access DVR Video Server from Internet Network device connection: The diagram below shows the connection architecture of a local network to the Internet / WAN: This example illustrates the connection of an ADSL Router to the ADSL Modem (ATU-R).
  • Page 113 Standalone DVR SEC-DVR304 User Manual Router Configuration In the Router, the user has to set the port mapping for Video Server. In this case, the port is set as 8080 and the video server local IP address is 192.168.0.22. So the user must set the port mapping 8080 to 192.168.0.22...
  • Page 114 Standalone DVR SEC-DVR304 User Manual Network configuration(Stream Video by Remote Client Software) User can also install the Remote Client Software and use the Remote Client Software to access the Video Server from remote sites. Router Configuration DVR Video Server uses ports 67, 68 to communicate with the Remote Client Software system.

  • Page 115: Appendix D - Backup Video File

    Standalone DVR SEC-DVR304 User Manual Appendix D – Backup Video File Backup video file from Standalone to USB flash drive / external DVD rewriter Using USB flash drive: Before using USB flash drive, please format it to FAT32 file system by MS-Windows;...
  • Page 116 Standalone DVR SEC-DVR304 User Manual The picture below will show when USB flash drive is connecting successfully to Standalone DVR. 4. a. Press “ESC” button on remote control to exit the menu. b. Press “Search” button on remote control. c. Select “Search By Time” option.
  • Page 117 Standalone DVR SEC-DVR304 User Manual 5. b. Press “Copy” button 6. a. Setup the backup video finishing time. 6. b. Press “Copy” button to start backup video. 7. Backup icon will be shown on button right of Monitor Display. 8. The status of backup will be shown at button of Monitor Display.
  • Page 118 Standalone DVR SEC-DVR304 User Manual 9. When Backup icon disappear meant the backup process is completed. *Note: If you wish to stop the video backup while the backup process is not finish. Press “Copy” button Press “Stop” button 10. Remove the USB flash drive from “Backup Device” before you unplug the USB flash drive.
  • Page 119 Standalone DVR SEC-DVR304 User Manual Now the USB flash drive is disconnected and safe to plug off from Standalone DVR. Using external DVD rewriter: 1. Please use DVD +R/-R/ RW disc for video backup. Standalone DVR would only detect DVD disc.
  • Page 120 Standalone DVR SEC-DVR304 User Manual 5. a. Setup the backup video starting time. Press “-” or “+” button to change the number. 5. b. Press “Copy” button 6. a. Setup the backup video finishing time. 6. b. Press “Copy” button to start backup video.
  • Page 121 Standalone DVR SEC-DVR304 User Manual 10. Remove the USB DVD from “Backup Device” before you unplug the USB DVD. Press on “Enter” button to disconnect USB DVD. Playback video file from USB flash drive / external DVD rewriter on Standalone DVR.
  • Page 122 Standalone DVR SEC-DVR304 User Manual Select Video folder then press “Enter” button. Select a video file then press “Enter” button to playback the video. *Note: File name explanation.
  • Page 123 Standalone DVR SEC-DVR304 User Manual Playback video file from USB flash drive / external DVD rewriter on PC / Laptop (Window XP). 1. Insert USB flash drive / DVD disc onto PC/ Laptop. 2. Select video folder. 3. Click on...
  • Page 124 Standalone DVR SEC-DVR304 User Manual 4. A video player will popup. *Note: Functions explanation...

  • Page 125: Appendix E -Frequently Asked Questions & Trouble Shooting

    Standalone DVR SEC-DVR304 User Manual Appendix E –Frequently Asked Questions & Trouble Shooting Question Reply Features How many users can remote access Up to 6 users can logon to DVR simultaneously. simultaneously? Install Standalone HDD fail message appear (HDD 1...
  • Page 126 Standalone DVR SEC-DVR304 User Manual How “covert setting” does works? For user who login as “Supervisor” or “Operator” will not seeing the covert videos. Where do I change control port / 1. Go to “Network Setup”. data port / HTTP port? 2.

  • Page 127: Appendix F - Application Steps: Ddns & Domain Name

    Standalone DVR SEC-DVR304 User Manual Appendix F - Application Steps: DDNS & Domain Name Fast network setting for Standalone DVR users Remote view Standalone DVR videos using IE browser within Local Area Network region or over Internet 1.1 Network connection diagram: Chapter 1.1 gives an idea of simplify network connection architecture of a...
  • Page 128 Standalone DVR SEC-DVR304 User Manual 1.2.1. Network setting in Standalone DVR Standalone DVR communication ports are 67, 68, and 80 (Default setting) For advance user who may not wish to use these ports but want to change these ports to the others. Please go to Menu→Setup→Network→Adv (Advanced Network Setup) in Standalone DVR.
  • Page 129 Standalone DVR SEC-DVR304 User Manual 1.3 View by IE browser (version 6.0 or above) Please note that remote view can only be work on the Internet Explorer. Browsers such as Safari, Google Chrome and Firefox would not be able to view the video.
  • Page 130 Standalone DVR SEC-DVR304 User Manual Remark 1: User who may use Internet Explorer browser version 7.0 or above please follow the steps below to connect to Standalone DVR. Step.1 Open IE browser. Click on “Tools” and go to “Internet Options”.
  • Page 131 Standalone DVR SEC-DVR304 User Manual → The IP address is now save in Trusted sites. Click on “Close”.
  • Page 132 Standalone DVR SEC-DVR304 User Manual 3. Enter Standalone IP address in IE browser. 4. Click on “Install ActiveX Control” option. 5. Click on “Install”...
  • Page 133 Standalone DVR SEC-DVR304 User Manual 6. Click on “Yes” 7. Click on “Install” 8. Enter “User name” and password. Then click on “OK”.
  • Page 134 Standalone DVR SEC-DVR304 User Manual 9. Now you should see the Standalone DVR remote viewing with IE browser. Remark 2: Apply DDNS hostname Note: Before we get a DDNS hostname user must get a DDNS account first. Here we suggest a DDNS Company www.dyndns.org.
  • Page 135 Standalone DVR SEC-DVR304 User Manual (3). Click on “Create Account” option (4). Fill the application agreement and necessary information. (5). Check your e-mail mailbox. There will be an e-mail with a title “Your DynDNS Account Information“. Click the hyperlink address to confirm the DDNS service that you just applied.
  • Page 136 Standalone DVR SEC-DVR304 User Manual PART B: Create a hostname (1). Go to the web page http://www.dyndns.org/ again. Input your DDNS username and password that you just applied to login. (2). After you login please click on “Add Host Services”.
  • Page 137 Standalone DVR SEC-DVR304 User Manual d. Click on “Add To Cart” button (4). Click on “Next” button.
  • Page 138 Standalone DVR SEC-DVR304 User Manual (5). Click on “Activate Service” button (6). Now your DDNS hostname is been created. The DDNS hostname is use to connect to your device such as Standalone DVR and IP cam etc. Once you got a DDNS hostname please see Remark 3 for working example to give you idea how to input the DDNS hostname into Standalone DVR network setup.
  • Page 139 Standalone DVR SEC-DVR304 User Manual Example 1: Actual Static Public IP Address with DDNS hostname setting In this working example we have Standalone DVR connecting to ADSL modem straight forward. Our ISP provider (Hinet LTD Company in Taiwan) provides us a static public IP address (this public IP address will never be change).
  • Page 140 Standalone DVR SEC-DVR304 User Manual static public IP address in the DDNS hostname by hand. Example 2: Actual Dynamic Public IP Address with DDNS hostname setting In this working example we have Standalone DVR connecting to ADSL modem straight forward.
  • Page 141 Standalone DVR SEC-DVR304 User Manual Once the details been filled in Standalone DVR and saved you may visit the DDNS supplier’s website to check public IP address is now become your static public IP address. If your static public IP address is not been renew or update you may enter your...

Table of Contents
