Front Panel

1 12 or 24 RJ-45 10/100 Ports
You can use these ports to connect 10BASE-T or 100BASE-TX devices
(workstations and other equipment) to the Baseline Dual Speed Hub. As
the ports are autosensing, the speed of the ports is determined
automatically when you connect your equipment.
WARNING: RJ-45 Ports. These are shielded RJ-45 data sockets.
They cannot be used as standard traditional telephone sockets,
or to connect the unit to a traditional PBX or public telephone
network. Only connect RJ-45 data connectors, network tele-
phony systems, or network telephones to these sockets.
Either shielded or unshielded data cables with shielded or
unshielded jacks can be connected to these data sockets.
AVERTISSEMENT: Points d'accès RJ-45. Ceux-ci sont protégés
par des prises de données. Ils ne peuvent pas être utilisés comme
prises de téléphone conventionnelles standard, ni pour la con-
nection de l'unité à un réseau téléphonique central privé ou pub-
lic. Raccorder seulement connecteurs de données RJ-45,
systèmes de réseaux de téléphonie ou téléphones de réseaux à
ces prises.
Il est possible de raccorder des câbles protégés ou non protégés
avec des jacks protégés ou non protégés à ces prises de don-
nées.
WARNHINWEIS: RJ-45-Porte. Diese Porte sind geschützte Dat-
ensteckdosen. Sie dürfen weder wie normale traditionelle Tele-
fonsteckdosen noch für die Verbindung der Einheit mit einem
traditionellem privatem oder öffentlichem Telefonnetzwerk
gebraucht werden. Nur RJ-45-Datenanscluße, Telefonnetzsysteme
or Netztelefone an diese Steckdosen anschließen.
Entweder geschützte oder ungeschützte Buchsen dürfen an diese
Datensteckdosen angeschlossen werden.
Connect one end of the TP (twisted pair) cable to the RJ-45 port on the
Baseline Dual Speed Hub and the other end to the appropriate RJ-45 port
on the device. Use either shielded or unshielded data cables (with shielded
or unshielded jacks) to connect to the devices.
The equipment that is connected to the Baseline Dual Speed
Hub must not be set to operate in full duplex mode. It must be
set to operate in autonegotiate or half duplex mode.
10BASE-T
To connect 10BASE-T equipment, use 10BASE-T Category 3 or Category 5
unshielded or shielded (screened) 100 Ohm TP cable.
Category 5 cable should be used with this product in structured
wiring environments. This will ensure correct operation of all
ports at 10 Mbps or 100 Mbps.
Ethernet Network Configuration Rules
To remain within IEEE 802.3 10 Mbps Ethernet rules, the maximum length
of cable between the Baseline Dual Speed Hub and an attached device
must not exceed 100 m (328 ft). If you are connecting multiple hubs in
U B
SE THE
1
6x 7x
18x 19x
6 7
D
ASELINE UAL
2 3
Status
12x
yellow = 10Mbps link OK
green = 100Mbps, link OK flashing =
MDI
MDIX
1 2 3 4 5 6 7
13 14 15 16 17 18 19
24
series, ensure that there are no more than four 10 Mbps hubs between
any two devices on your network, as shown below.
100BASE-TX
To connect 100BASE-TX equipment, use 100BASE-TX Category 5
unshielded or shielded (screened) 100 Ohm TP cable.
Fast Ethernet Network Configuration Rules
To remain within IEEE 802.3 100 Mbps Fast Ethernet rules, the maximum
length of cable between the Baseline Dual Speed Hub and an attached
device must not exceed 100 m (328 ft). Ensure that there are no more
than two 100 Mbps hubs between any two devices on your network, and
that the total cable distance (A+B+C) between the two devices does not
exceed 205 m (672.4 ft), as shown below.
If you connect two Baseline Dual Speed Hubs together, the link
between them operates at 100 Mbps.
2 MDI Switch
This switch affects port 12 (3C16592B) or port 24 (3C16593B). Ports 1–11
(3C16592B) or 1–23 (3C16593B) are fixed as MDIX ports. Each can be
connected to a device with an MDI port (such as most workstations) using
a normal "straight through" TP cable. Port 12 or 24 is "switch selectable"
using the MDI switch:
MDIX
MDI
2
S
PEED
4
Baseline Dual Speed Hub
Segment
off = no link
off = no traffic
partition green = partition
yellow = collisions
100Mbps
8 9 10 11 12
20 21 22 23 24
Power
3C16593B SuperStack 3
10Mbps
5
Out In this position, port 12 or 24 is an MDIX port. It can be
connected to a device with an MDI port (such as most
workstations) using a normal "straight through" TP cable.
In In this position, port 12 or 24 is an MDI port.
It can be connected to an MDIX port on a device (such as
another hub) using a normal "straight through" TP cable.
Unit 1
Unit 2
Switch set to MDIX (out)
if port 24 used
H
UB
®
8
Set switch to
MDI (in)
