Connecting and setting up your DVR+
1
Connect the antenna to the receiver.
2
Connect the receiver to the TV.
3
Connect the small end of the power cord to the receiver input and plug
the other end into an AC outlet. Turn on the TV and select the correct
input.
Power Input
Provides power
to DVR+
4
Remove plastic battery tab from remote control by pulling it out.
5
Follow the on-screen Setup Wizard instructions, using the remote control.
(See the following pages for more instructions on using your remote.)
RF IN
Connects over-the-air
(OTA) TV antenna
HDMI Output
®
Provides high-definition digital
audio and video to the TV
Note: Only use
a good-quality,
shielded HDMI
cable.
Firmly pull
straight out
Introduction ::
