- Page 1 VARI 432HB BRUSHCUTTER INSTRUCTIONS FOR USE, MAINTENANCE AND SPARE PARTS (TRANSLATION OF THE ORIGINAL INSTRUCTIONS FOR USE) READ CAREFULLY THIS MANUAL BEFORE ANY USE WARNING: LOOK FOR THIS SYMBOL TO POINT OUT IMPORTANT SAFETY PRECAUTIONS. 2013...
-
Page 2: Security Rules
SECURITY RULES: or face shields and in order to protect Before starting your ears from high noises, use head plugs. Tight your hair as it is not This brushcutter is only made for reaching your shoulders. cutting grass, bush, arborescent shrub, and clumps. - Page 3 Security pictograms 6. Push the red button on the right handle for the starting. 1. Warning, Danger, Caution 7. Beware of the possible projection of 2. Read documentation and safety objects. instructions which are provided in this user manual. 8. Warning: people, animals, objects damageable can’t be in a diameter of 15 meters around the working zone.
- Page 4 11. Hot surface, risk of burn. 12. Danger, risk of fire or explosion. Security pieces description. A) Security helmet H) Heavy duty work suit B) Head-phones I) Anti-vibrating support C) Face shield against possible L) Accelerator handle with stop switch projections M) Engine with overheating protection D) Harness...
-
Page 5: Technical Characteristics
TECHNICAL CHARACTERISTICS MODEL AW-BC643 TRADE NAME VARI 432HB Dry weight (without cutting tools and fuel) 7.6 kg Engine type LH1E40F-5A Fuel tank capacity (litres) 0.95 l Blade diameter (mm) Blade thickness (mm) Number of teeth Fixation hole diameter (mm) 25.5 –1... - Page 6 -Adjust the position of the fixation on the Put on the sliding cover, screw on the nut tube of the machine, in order to obtain a and tighten it rightly. good balance between the rear and the Tightening torque: 30 Nm. front of the machine.
-
Page 7: Before Starting The Work
involve serious injury and damages to the spark plug, the piston, the muffler and persons and properties. in the cylinder as well as reducing manufacturer declines emission of exhaust gas. Lubrication will responsibility in case of faulty use of the be at best and it will give a longer life to machine. -
Page 8: Use Of The Brushcutter
adjust one with the others during the running-up period. It is at the end of the running-up period that the engine will reach its maximum power. After the two first hours of work, make a pause and check that all nuts and screws 2. - Page 9 Grass cutting respect those obligatory security Cut the grass, like if you were in a corridor standards. of 1.5 meters wide, move step by step Pay attention to the drawing below. balancing the machine right and left, and When you cut a small tree always use the 3-teeth blade in the <<A>>...
-
Page 10: Maintenance
MAINTENANCE For a correct adjustment, this operation must be done while the engine is hot. Carburettor adjustment Gearbox During a normal use, the carburettor may have some slight changes, especially, when Every 25 hours, grease the gearbox. there are some changes of working Unscrew the lateral tap of the gearbox and conditions and after many hours of work or put grease inside using a suitable tool. - Page 11 Guaranteed level of acoustic performance of the brushcutters L = 110 dB The VARI 432HB brushcutter is manufactured by Yongkang Linghang Machine Power Co., Ltd., China The importer and distributor is VARI, a.s., Opolanská 350, Libice nad Cidlinou 289 07, Czech Republic...
- Page 12 The manufacturer reserves the right to introduce technical modifications and innovations, which do not affect the function and safety of the machine. These modifications may not necessarily be specified in this user manual. Printing errors reserved. © VARI, a.s.
-
Page 13: List Of Spare Parts
LIST OF SPARE PARTS The spare part list is not a part of these instructions for use. The latest version of the catalogue can be downloaded from our internet site. If you have no access to the internet, ask your dealer to get it for you. -
Page 14: Ec Declaration Of Conformity
Engine displacement 43 cm The VARI 432HB (AW-BC643) brushcutter is intended for wide utilization in private gardens and in orchards. It is characterized by ease of control, simplicity and high power. This brushcutter is equipped with a 2-stroke engine with a power of 1,5 kW. Power transmission from the engine to the working part of the machine is made by a fixed shaft. - Page 15 Place of issue of the declaration of conformity: Libice n.C. Date: 31.10.2013 Name, surname and function of the person authorized to sign this EC declaration of conformity: Jiří BELINGER, Director General and Chairman of the Board of Directors, VARI, a.s. Signature: Stamp:...
-
Page 16: Letter Of Guarantee
Libice nad Cidlinou. The authorized seller of VARI, a.s. is obliged to make the purchaser familiar with the Instructions for use when the product is being handed over, demonstrate the product and duly fill in the Letter of guarantee. Following items have to be shown in the Letter of guarantee: identification data of the authorized seller of VARI, a.s., identification data of the... - Page 17 VARI were not used for repairs during the warranty period (for example blades, V-belts, etc.); the product was operated in combination with a product (accessories) from another producer; 14. Company VARI, a.s. does not answer for defects of the product resulting from current wear or from the product’s use for purposes other than specified.
- Page 18 RECORD OF WARRANTY AND POST-WARRANTY REPAIR CARRIED OUT (The warranty repair may only be carried out in an authorized service workshop of VARI, a.s.) Signature of the Date of technician and stamp Description of work carried out Replaced parts repair...
