Service Manual
Chapter 4. Removal and Replacement
a.Wireless WebScroll + NB Eye TX
Step
1. Turn over
To disassemble the mouse, you have
mouse
to turn over mouse.
2. Loose screws Using screwdriver to loose all
screws.
3. Take apart
After taking all screws off, you can
rear flat
take up the rear flat.
4. Take apart
You can take apart the PCB from the
PCB
upper cover directly.
The PCB is the most important part
of mouse.
Description
Version 1.0
Page 6
