- Page 1 All manuals and user guides at all-guides.com Service Manual Bluetooth Traveler...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com Service Manual Table of Contents Bluetooth Traveler........................0 Chapter 1. INTRODUCTION......................2 a. Hardware ..........................2 b. Software ..........................2 Chapter 2. Testing Procedures ......................3 a. Testing flow chart for TX ......................3 b. Check X1..........................4 d. Check VDD..........................5 e. -
Page 3: Bluetooth Traveler
All manuals and user guides at all-guides.com Service Manual Chapter 1. INTRODUCTION a. Hardware ♦ PC586 above ♦ Connection port : USB b. Software ♦ Win98 above ♦ Bluetooth Traveler USB Driver Version 1.0 Page 2... -
Page 4: Chapter 2. Testing Procedures
All manuals and user guides at all-guides.com Service Manual Chapter 2. Testing Procedures a. Testing flow chart for TX START Check X1 REPLACE X1 Check VDD REPLACE U6 Check BT RX REPLACE U1 Check BT TX REPLACE U1 Version 1.0 Page 3... -
Page 5: Check X1
All manuals and user guides at all-guides.com Service Manual b. Check X1 Version 1.0 Page 4... -
Page 6: Check Vdd
All manuals and user guides at all-guides.com Service Manual d. Check VDD U6 pin3 Version 1.0 Page 5... -
Page 7: Check Bt Rx
All manuals and user guides at all-guides.com Service Manual e. Check BT RX Version 1.0 Page 6... -
Page 8: Check Bt Tx
All manuals and user guides at all-guides.com Service Manual f. Check BT TX Version 1.0 Page 7... -
Page 9: Chapter 3. Troubleshooting Guide
All manuals and user guides at all-guides.com Service Manual Chapter 3. Troubleshooting Guide Problems Condition Probable Reasons Solutions 1. Mouse couldn’t 1. Pointer couldn’t work 1. TX PCB defect Change all the parts work below 1. Y1 2. U1 3. U3 4. -
Page 10: Chapter 4. Removal And Replacement
All manuals and user guides at all-guides.com Service Manual Chapter 4. Removal and Replacement Step Description Picture 1. Turn over To disassemble the mouse, you have mouse to turn over mouse. 2. Loose screws Using screwdriver to loose all screws. 3. -
Page 11: Chapter 5. Parts List
All manuals and user guides at all-guides.com Service Manual Chapter 5. Parts list Description Parts number Description Parts number 11300227000 MICRO SW ZIPPY 10900043000 11300001100 10800009000 10810010000 Sensor 10300119000 PCBA, BT 20000011101 PCBA, BT, DOWN 20000012101 Assy, RX 25000026101 Chapter 6. Tools 1.
