Version 1.00 | 11/11/2014

User Manual

Full HD PoE Day/Night Network Camera
DCS-2210L/UPA

Advertisement

Table of Contents
loading

Summary of Contents for D-Link DCS-2210L/UPA

  • Page 1: User Manual

    Version 1.00 | 11/11/2014 User Manual Full HD PoE Day/Night Network Camera DCS-2210L/UPA...
  • Page 2: Manual Revisions

    Preface D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Information in this document may become obsolete as our services and websites develop and change.
  • Page 3: Table Of Contents

    Using the Configuration Interface ........20 Live Video ................21 DI/DO Specifications ............62 Setup ..................23 Setup Wizard ..............23 Technical Specifications ..........63 Network Setup ..............29 Safety Statements ............66 Dynamic DNS ..............32 Image Setup ..............33 Audio and Video ..............35 Preset ...................37 D-Link DCS-2210L/UPA User Manual...
  • Page 4: Product Overview

    Section 1: Product Overview Product Overview Package Contents DCS-2210L Full HD PoE Day/Night Network Camera CAT5 Ethernet cable Quick Installation Guide If any of the above items are missing, please contact your reseller. D-Link DCS-2210L/UPA User Manual...
  • Page 5: System Requirements

    • Firefox 12 or higher • Safari 6.0 or higher (with Java installed and enabled) • Chrome 20 or higher Windows Users: Make sure you have the latest version of ® Java installed. Visit www.java.com to download the latest version. D-Link DCS-2210L/UPA User Manual...
  • Page 6: Introduction

    The DCS-2210L can be accessed remotely, and controlled from any PC over your local network or through the Internet via a web browser. It also comes with the D-Link D-ViewCam™ software bundle that allows you to manage multiple network cameras using remote monitoring, scheduling, recording, motion detection, and notifications for a complete and cost-effective home security solution.
  • Page 7: Features

    With today’s high-speed Internet services, the DCS-2210L can provide the ideal solution for delivering live video images over the Intranet and Internet for remote monitoring. The DCS-2210L allows remote access using a web browser for live image viewing, and allows the administrator to manage and control the DCS-2210L anytime, anywhere in the world. D-Link DCS-2210L/UPA User Manual...
  • Page 8: Hardware Overview

    Records video of the surrounding area The light sensor helps switch the camera between day and night modes. Night Light Sensor mode activates the IR LED and toggles the IR-Cut-Removable filter. Microphone Records audio from the surrounding area D-Link DCS-2210L/UPA User Manual...
  • Page 9: Rear View

    Press and hold this button for 10 seconds to reset the camera Power Connector Connects to the DC 5 V power adapter (not included in package) DI/DO Connector I/O connectors for external devices Adjustment Ring Tighten or loosen the adjustment ring to adjust the camera's position D-Link DCS-2210L/UPA User Manual...
  • Page 10: Side View

    Section 1: Product Overview Side View microSD Card Slot Insert a microSD card for Local storage for storing recorded image and video D-Link DCS-2210L/UPA User Manual...
  • Page 11: Installation

    Zero Configuration Setup If you have a D-Link Cloud Router, you can take advantage of Zero Configuration Setup. Zero Configuration automatically configures your camera's settings for you, and adds it to your mydlink account automatically. This type of setup allows you to set up your camera by simply plugging it in and connecting it to your router.
  • Page 12 Click on the device name to continue. A summary and confirmation notification will appear with the automatically configured details. Make a note of the details and click OK to add the camera to your account. D-Link DCS-2210L/UPA User Manual...
  • Page 13 Your camera is now set up, and you can skip to mydlink on page 19 to learn more about the mydlink features of this camera, or to Configuration on page 20 for advanced configuration of your camera. D-Link DCS-2210L/UPA User Manual...
  • Page 14: Camera Setup Wizard

    Note: If the autorun program does not open, go to My Computer, browse to your CD drive, and double-click on the autorun.exe file. D-Link DCS-2210L/UPA User Manual...
  • Page 15: Mac Users

    SetupWizard file. Within 20-30 seconds, the Setup Wizard will open, which will guide you step-by-step through the installation process from connecting your hardware to configuring your camera and registering it with your mydlink account. D-Link DCS-2210L/UPA User Manual...
  • Page 16 Your camera is now set up, and you can skip to mydlink on page 19 to learn more about the mydlink features of this camera, or go to Configuration on page 20 for advanced configuration of your camera. D-Link DCS-2210L/UPA User Manual...
  • Page 17: Manual Hardware Installation

    Attach the External Power Supply (optional) Attach the external power supply to the DC Power receptor located on the rear panel of the DCS-2210L and connect it to your wall outlet or power strip. D-Link DCS-2210L/UPA User Manual...
  • Page 18: Mount The Camera

    4. Place the base cover on the base and screw the camera stem clockwise into the mounting base. 5. Adjust the angle of the camera as desired, then tighten the collar on the camera stem to lock it in place. D-Link DCS-2210L/UPA User Manual...
  • Page 19: Mydlink

    For more details on using your camera with mydlink, go to the Support section of the mydlink website and check the User Manual section for your product to find the latest instruction guide for your camera's mydlink features. D-Link DCS-2210L/UPA User Manual...
  • Page 20: Configuration

    Mozilla Firefox. To log in, use the username admin and the password you created in the Installation Wizard. If you did not create a password, the default password is blank. After entering your password, click OK. D-Link DCS-2210L/UPA User Manual...
  • Page 21: Live Video

    FOV. Stop Stops automatic panning. Preset Path Starts the camera's motion along the predefined path. ePTZ Speed: You may select a value between 0 and 64. 0 is the slowest and 64 is the fastest. D-Link DCS-2210L/UPA User Manual...
  • Page 22 Listen/Stop Audio In (from microphone) Full screen mode Start/Stop Audio Out (to speaker) Taking a Snapshot Start/Stop Digital Output Go To: If any presets have been defined, selecting a preset from this list will (Preset List) display it. D-Link DCS-2210L/UPA User Manual...
  • Page 23: Setup

    To quickly configure your DCS-2210L’s motion detection settings, click Motion Detection Setup Wizard. If you want to enter your settings without running the wizard, click Manual Motion Detection Setup and skip to Motion Detection on page 39. D-Link DCS-2210L/UPA User Manual...
  • Page 24: Internet Connection Setup Wizard

    Section 4: Configuration Internet Connection Setup Wizard This wizard will guide you through a step-by-step process to configure your new D-Link Camera and connect the camera to the Internet. Click Next to continue. Note: Select DHCP if you are unsure of which settings to choose.
  • Page 25 If you have a Dynamic DNS account and would like the camera to update your IP address automatically, Select Enable DDNS and enter your host information. Click Next to continue. Enter a name for your camera and click Next to continue. D-Link DCS-2210L/UPA User Manual...
  • Page 26 If you have selected DHCP, you will see a summary of your settings, including the camera's IP address. Please write down all of this information as you will need it in order to access your camera. Click Apply to save your settings. D-Link DCS-2210L/UPA User Manual...
  • Page 27: Motion Detection Setup Wizard

    Step 2 This step allows you to enable motion detection based on a customized schedule. Specify the day and hours. You may also choose to always record whenever motion is detected. D-Link DCS-2210L/UPA User Manual...
  • Page 28 Click Next to continue. Step 4 You have completed the Motion Detection Wizard. Please verify your settings and click Apply to save them. Please wait a few moments while the camera saves your settings and restarts. D-Link DCS-2210L/UPA User Manual...
  • Page 29: Network Setup

    Invalid gateway settings may cause the failure of transmissions to a different subnet. Primary DNS: The primary domain name server translates names to IP addresses. Secondary DNS: The secondary DNS acts as a backup to the primary DNS. D-Link DCS-2210L/UPA User Manual...
  • Page 30 PDAs. The default port number is 554. You may specify the address of a particular stream. For instance, live1.sdp can be accessed at rtsp://x.x.x.x/video1.sdp where the x.x.x.x represents the IP address of your camera. D-Link DCS-2210L/UPA User Manual...
  • Page 31 Enable Bonjour: Enable Bonjour to broadcast to network devices (such as iPhones) using this protocol. You can enter a custom Bonjour Name for the router in the text box for identification. D-Link DCS-2210L/UPA User Manual...
  • Page 32: Dynamic Dns

    DDNS account. Password: Enter the password used to connect to your DDNS server account. Timeout: Enter the DNS timeout values you wish to use. Status: Indicates the connection status, which is automatically determined by the system. D-Link DCS-2210L/UPA User Manual...
  • Page 33: Image Setup

    Select the frequency used by your power lines to avoid interference or distortion. White Balance: Use the drop-down box to change white balance settings to help balance colors for different environments. You can choose from Auto, Outdoor, Indoor, Fluorescent, and Push Hold. D-Link DCS-2210L/UPA User Manual...
  • Page 34 This setting controls the amount of coloration, from grayscale to fully saturated. Sharpness: Specify a value from 0 to 8 to specify how much sharpening to apply to the image. Reset Default: Click this button to reset the image to factory default settings. D-Link DCS-2210L/UPA User Manual...
  • Page 35: Audio And Video

    Maximum frame rate: A higher frame rate provides smoother motion for videos, and requires more bandwidth. Lower frame rates will result in stuttering motion, and requires less bandwidth. D-Link DCS-2210L/UPA User Manual...
  • Page 36 This setting controls the amount of gain applied to incoming audio to increase its volume. Audio out off: Selecting this checkbox will mute outgoing audio. Audio out volume level: This setting controls the amount of gain applied to outgoing audio to increase its volume. D-Link DCS-2210L/UPA User Manual...
  • Page 37: Preset

    Clicking the Remove button will delete the currently selected preset. Preset Sequence: This section allows you to create a preset sequence, which automatically moves the camera's view between a set of preset views. D-Link DCS-2210L/UPA User Manual...
  • Page 38: D-Link Dcs-2210L/Upa User Manual

    Clicking the trash can button will remove the currently selected preset from the sequence. If you want to change the dwell time for a preset, select it from the list, enter a new dwell time, then click the Update button. D-Link DCS-2210L/UPA User Manual...
  • Page 39: Motion Detection

    Right clicking on the camera image brings up the following menu options: Select All: Draws a motion detection area over the entire screen. Clear All: Clears any motion detection areas that have been drawn. Restore: Restores the previously specified motion detection areas. D-Link DCS-2210L/UPA User Manual...
  • Page 40: Time And Date

    Set the Date and Time Manually: This option allows you to set the time and date manually. Copy Your Computer's Time This will synchronize the time information from your PC. Settings: D-Link DCS-2210L/UPA User Manual...
  • Page 41: Event Setup

    Snapshot, Video Clips E-mail, FTP To start plotting an event, it is suggested to configure server and media columns first so that the DCS-2210L will know what action shall be performed when a trigger is activated. D-Link DCS-2210L/UPA User Manual...
  • Page 42 1. To add a new item - "event, server or media," click Add. A screen will appear and allow you to update the fields accordingly. 2. To delete the selected item from the pull-down menu of event, server or media, click Delete. 3. Click on the item name to pop up a window for modifying. D-Link DCS-2210L/UPA User Manual...
  • Page 43: Add Server

    Enter the configuration for the target e-mail server account. FTP: Enter the configuration for the target FTP server account. Network Storage: Specify a network storage device. Only one network storage device is supported. SD Card: Use the camera's onboard SD card storage. D-Link DCS-2210L/UPA User Manual...
  • Page 44: Add Media

    You can set up to 7 post-event images to be taken. File name prefix: The prefix name will be added on the file name. Add date and time suffix to file Check it to add timing information as file name suffix. name: D-Link DCS-2210L/UPA User Manual...
  • Page 45 This is the prefix that will be added to the filename of saved video clips. System log: Select this option to set the media type to system logs. This will save the event to the camera system log, but will not record any snapshots or video. D-Link DCS-2210L/UPA User Manual...
  • Page 46: Add Event

    Passive Infrared Sensor: Triggers an event when the PIR sensor is activated by moving infrared objects even in dark environment. Select Always or enter the time interval. Time: Select the days and times when events will be detected. D-Link DCS-2210L/UPA User Manual...
  • Page 47 Section 4: Configuration Trigger D/O: Select to trigger the digital output for a specific number of seconds when an event occurs. Server: Specify the location where the event information should be saved to. D-Link DCS-2210L/UPA User Manual...
  • Page 48: Add Recording

    Please note that if the free HDD space is not enough, the recording will stop. Before you set up this option please make sure your HDD has enough space, and it is better to not save other files in the same folder as recording files. D-Link DCS-2210L/UPA User Manual...
  • Page 49 Time of each file for recording: If this is selected, files will be separated based on the maximum length you specify. File Name Prefix: The prefix name will be added on the file name of the recording file(s). D-Link DCS-2210L/UPA User Manual...
  • Page 50: Sd Card

    Playback Recorded Video: If video files are stored on the SD card, click on the video folder and choose the video file you would like to view. Refresh: Reloads the file and folder information from the SD card. D-Link DCS-2210L/UPA User Manual...
  • Page 51: Advanced

    Therefore events are triggered when the device status changes to "Open." N.O. stands for Normally Open. This means that the normal state of the circuit is open. Therefore events are triggered when the device status changes to "Closed." D-Link DCS-2210L/UPA User Manual...
  • Page 52: Icr And Ir

    The IR light will always be on. Sync: The IR light will turn on when the ICR sensor is on. Schedule: The IR light will turn on or off according to the schedule that you specify below. D-Link DCS-2210L/UPA User Manual...
  • Page 53: Https

    CSR Property and Certificate Property to view details of the certificates. Note: The certificate cannot be removed while the HTTPS is still enabled. To remove the certificate, you must first uncheck Enable HTTPS secure connection. D-Link DCS-2210L/UPA User Manual...
  • Page 54: Access List

    When the range of the Allowed List is set from 1.1.1.0 to 192.255.255.255 and the range of the Denied List is set from 1.1.1.0 to 170.255.255.255. Only users with IPs Denied Alowed located between 171.0.0.0 and 192.255.255.255 can List List access the DCS-2210L. D-Link DCS-2210L/UPA User Manual...
  • Page 55: Snmp

    Select the authentication protocol used for SNMP exchanges between this user and the local SNMP engine. SHA and MD5 protocols are supported. Authentication/Encryption Enter the authentication and encryption passwords for Password: your read/write and read only SNMP accounts in these boxes. D-Link DCS-2210L/UPA User Manual...
  • Page 56: Maintenance

    Select this option to enable the time-stamp display on the video screen. Click Save when you are done. LED: You may specify whether or not to illuminate the status LED on the camera. Click Save when you are done. D-Link DCS-2210L/UPA User Manual...
  • Page 57: System

    Restore Factory Defaults. Reboot Device: This will restart your camera. Enable Schedule Reboot: Check to enable this feature and select the days and times your DCS-2210L will automatically reboot. Click Save for it to take effect. D-Link DCS-2210L/UPA User Manual...
  • Page 58: Firmware Upgrade

    Section 4: Configuration Firmware Upgrade The camera's current firmware version will be displayed on this screen. You may visit the D-Link Support Website to check for the latest available firmware version. To upgrade the firmware on your DCS-2210L, please download and save the latest firmware version from the D-Link Support Page to your local hard drive.
  • Page 59: Status

    Section 4: Configuration Status Device Info This page displays detailed information about your device and network connection. D-Link DCS-2210L/UPA User Manual...
  • Page 60: Logs

    Section 4: Configuration Logs This page displays the log information of your camera. You may download the information by clicking Download. You may also click Clear to delete the saved log information. D-Link DCS-2210L/UPA User Manual...
  • Page 61: Help

    Section 4: Configuration Help This page provides helpful information regarding camera operation. D-Link DCS-2210L/UPA User Manual...
  • Page 62: Di/Do Specifications

    DC 5 V Output / Max. 100 mA Internal 5V Power External 3~12V Power DC Power 5V DC Power 5V DC Power 3V~12V N.C / N.O N.C / N.O Reed switch Reed switch Diode Diode 100 mA 100 mA ALARM ALARM D-Link DCS-2210L/UPA User Manual...
  • Page 63: Technical Specifications

    RTP / RTSP/ RTCP NTP client (D-Link) IP filtering DNS client DDNS client (D-Link) SMTP client Multicast FTP client IGMP Bonjour ONVIF compliant ƒ Administrator and user group protection Security ƒ HTTP and RTSP digest encryption ƒ Password authentication D-Link DCS-2210L/UPA User Manual...
  • Page 64 Power Consumption Max. 3.5 W Temperature Operating: 0 to 40 °C (32 to 104 °F) Storage: -20 to 70 °C (-4 to 158 °F) Humidity Operating: 20% to 80% non-condensing Storage: 5% to 95% non-condensing Certifications CE LVD C-Tick D-Link DCS-2210L/UPA User Manual...
  • Page 65 Appendix B: Technical Specifications Dimensions • D-Link DCS-2210L/UPA User Manual...
  • Page 66: Safety Statements

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. D-Link DCS-2210L/UPA User Manual...
  • Page 67 The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to match the intended destination. The firmware setting is not accessible by the end user. For detailed warranty information applicable to products purchased outside the United States, please contact the corresponding local D-Link office.
