Freestanding Wood Fire
Installation Manual
www.regency-fire.com.au
MODEL:
F5102 - AUSTRALIA
F5102 Video
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
FPI - FIREPLACE PRODUCTS AUSTRALIA PTY LTD.
919-318a
04/07/15
1 CONQUEST WAY HALLAM VICTORIA 3803
Advertisement
Table of Contents
Related Manuals for Regency F5102
Summary of Contents for Regency F5102
- Page 1 Owners & Freestanding Wood Fire Installation Manual www.regency-fire.com.au MODEL: F5102 - AUSTRALIA F5102 Video Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. FPI - FIREPLACE PRODUCTS AUSTRALIA PTY LTD.
- Page 2 The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area.
-
Page 3: Table Of Contents
Bypass door gasket replacement .......21 Secondary air tube removal / installation.....22 Door catch Adjustment ..........22 Side baffle installation / removal ........23 Maintenance ..............24 F5102 Stove Main Assembly ........25 F5102 Stove Brick layout..........26 Door assembly ............27 Warranty ..............30 F5102 Regency Freestanding Wood Fire... -
Page 4: Data Badge
This is a copy of the data badge that accompanies each F5102 Freestanding Wood Fire. We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being improved. Check the data badge on the unit and if there is a difference, the label on the unit is the correct one. -
Page 5: Unit Dimensions
DIMENSIONS UNIT DIMENSIONS 16 " [792mm] 16 " [735mm] " 8 " [689mm] [181mm] 3" [76mm] 29" [737mm] F5102 Regency Freestanding Wood Fire... -
Page 6: Residential Installation
WARNING: ONLY USE SPECIFIED COMPONENTS. The following items are required when assembling your Regency Stove. F5102 unit - the Rear Heat Deflector is supplied with the stove, but if you choose not to use it you must use the Airmate instead. -
Page 7: Stove Assembly Prior To Installation
The F5102 unit requires the pedestal attached to corner of the wall. The rear heat deflector is installed on top of the base. The F5102 stove requires either the Air- pedestal cover the rear heat shield, as shown in Diagram 4. -
Page 8: Thru-Wall Installation
Horizontal Maximum of 900mm with 6.35mm rise per 0.3m. NOTE: Recommend using 2 - 45º instead of 90º to improve draft and performance (as per diagram). 6" [152mm] Min. 900 mm Min. 36" Vertical Rise Vertical Rise 5" 200mm [127mm] F5102 Regency Freestanding Wood Fire... -
Page 9: Minimum Clearance To Combustible Materials
Universal 7" (178mm) FLo-Met kit with 1 x 900mm decromesh (solid back) on top of appliance. an 8" (203mm) reducing to 7" (178mm) starting piece of spigot need to be fitted to kit (If not supplied). The flue pipe shall extend not less than 4.6 M above the top of the floor protector. F5102 Regency Freestanding Wood Fire... -
Page 10: Floor Protection
400mm (from Glass) From Back of Appliance: 0 mm (60mm from Rear of Pedestal Foot) (from glass) Floor protection must be minimum of 6mm thick - 1194 x 1143 in size with a thermal conductivity of 0.8W/mºK F5102 Regency Freestanding Wood Fire... -
Page 11: Step-By-Step Flue And Connector Installation
Secure the flashing to your roof with nails or screws. 5. Place the storm collar over the flashing, seal- 200 mm 5" ing the joints with a silicone caulking. [127mm] 6. Fasten the raincap to the top of your flue. Horizontal Installation F5102 Regency Freestanding Wood Fire... -
Page 12: Stainless Steel Smoke Deflector Installation
Incorrect Install: Return edge of smoke deflector seated under glass wash. Ensure defector is seated so bolts are situated at the top of the keyhole before tightening. Hand tighten bolts only. F5102 Regency Freestanding Wood Fire... -
Page 13: Brick Installation
51mm x 229mm 89mm x 114mm 44mm x 114mm 51mm x 178mm AD brick NOTE: The "AD" brick covers the Ash Dump hole that is used when the Ash Drawer Kit is installed. Final Install F5102 Regency Freestanding Wood Fire... -
Page 14: Fan Installation
Earth Neutral Green Manual/ Earth Live Ground Auto 240 AC 120V AC Switch Switch 50 Hz 60 Hz Fan Thermodisc (normally open) Black Black Black Earth Ground Wiring Diagram F5102 Regency Freestanding Wood Fire... -
Page 15: Operating Instructions
The F5102 unit has a secondary Regency Stove causing a draft down your flue. logs to your fire. Form a trench in the ash bed... -
Page 16: Fan Operation
Switching from "AUTO" to "MAN" or "HIGH" to 7. Your Regency stove can be very hot. You may be "LOW" may be done anytime. seriously burned if you touch the stove while it is operating, keep children, clothing and furniture HOT WHILE IN OPERATION. -
Page 17: Troubleshoot Guide
Burning coal will cause a sulfur-based compound to coat the catalyst. Revert to burning wood and fire the combustor to elevated temperatures for one hour. F5102 Regency Freestanding Wood Fire... -
Page 18: Maintenance
If the door gasket requires replacement 5/8" diameter When wood is burned slowly, it produces tar and material must be used. Regency uses a gasket rope other organic vapours combine with moisture to 5/8" Medium Density (Part #936-060). A proper high form creosote. -
Page 19: Catalytic Combustor
(by-pass open) through the combustor. F5102 Flamegaurd & Catalyst Mass = 4.649 pounds F5102 Regency Freestanding Wood Fire TOTAL AREA FOR AIR FLOW = 37.396 3RD ANGLE TOLER PROJECTION... - Page 20 NOTE: Replacement combustors can be retrieved from Applied Ceramics or Contact your local Regency Dealer for details. DO NOT OPERATE THE APPLIANCE IF COMBUSTOR BECOMES INACTIVE - DO NOT OPERATE WITHOUT COMBUSTOR.
-
Page 21: Bypass Door Gasket Replacement
5. Reverse steps to reinstall - ensure the pass rod is seated with the channel on the pass door. (Unit viewed as transparent to facilitate view) Channel Pass rod Loosen 3 rear bolts F5102 Damper Assembly Draft F5102 Regency Freestanding Wood Fire... -
Page 22: Secondary Air Tube Removal / Installation
Firmly grip center of air tube with vise grips, use hammer to tap vise grips from left to right until the tube bottoms out into the air channel on right. F5102 Airtube Replacement F5102 Regency Freestanding Wood Fire... -
Page 23: Side Baffle Installation / Removal
This edge to outside of firebox 3. Manoeuvre the side baffle underneath the upper corner filler, then let the baffle rest on the side of the combustor housing. 4. Repeat process on other side. Corner filler F5102 Regency Freestanding Wood Fire... -
Page 24: Maintenance
Use only high temperature anti seize lube. (ie. never seize) Check glass for cracks Replace if required. Clean blower motor Disconnect power supply. Remove and clean blower. *DO NOT LUBRICATE* Inspect and clean flue Annual professional flue cleaning recommended. F5102 Regency Freestanding Wood Fire... -
Page 25: F5102 Stove Main Assembly
Fan-Free Standing Stove 156-523 Door Hinge Assembly 910-155/P Replacement Motor 156-514 Door Catch assembly 910-138 Auto/Manual Switch 156-241 Removable Cast Handle 910-140 Hi/Off/Lo switch 051-006 L/R stainless steel firebox filler 910-142 Fan Thermodisc 919-318 Manual F5102 Regency Freestanding Wood Fire... -
Page 26: F5102 Stove Brick Layout
PARTS LIST F5102 STOVE BRICK LAYOUT 051-960 Brick Set Complete Fire bricks Size 114mm x 229mm 51mm x 229mm 89mm x 114mm 44mm x 114mm 51mm x 178mm AD Brick F5102 Regency Freestanding Wood Fire... -
Page 27: Door Assembly
SCREW 1/4-20 x 3/8 TUSS HD PHIL ZINC PD (ea) 940-384/P GLASS CERAMIC 904-146 SCREW #10 x 1/2 SELF TAP PAN HD PHILIPS (ea) 936-243 TAPE 7/8 WINDOW ADHESIVE 0904-513 HEX BOLT 1/4-20 x 3/4 LG. (ea) 051-057 SIDE GASKET BRACKET (ea) F5102 Regency Freestanding Wood Fire... - Page 28 NOTES F5102 Regency Freestanding Wood Fire...
- Page 29 NOTES F5102 Regency Freestanding Wood Fire...
-
Page 30: Warranty
It is the general practice of FPI to charge for larger, higher priced replacement parts and issue credit once the replaced component has been returned to FPI and evaluated for manufacturer defect. The authorised selling dealer is responsible for all in-field service work carried out on your Regency product. FPI will not be liable for results or costs of workmanship from unau- thorised service persons or dealers. - Page 31 Warranty (first six (6) years). Regency Fireplace Products will replace, at no charge to the consumer - 'one' only, VERSAGRID CATALYTIC CONVERTER that ceases to func- tion within three (3) years from the date of purchase by the original consumer, provided that the following conditions are met: (1) A copy of the original invoice that include place and date of purchase must be submitted with the warranty claim.
- Page 32 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ F5102 Video Regency is a trademark of FPI Fireplace Products International Ltd. © Copyright 2015, FPI Fireplace Products International Ltd. All rights reserved. Printed in Canada...
