Summary of Contents for Denver MPM-4034

  • Page 2: Table Of Contents

    Content Main function -------------------------------------------------------------------------------------------1 Attention---------------------------------------------------------------------------------------------------2 Know the player------------------------------------------------------------------------------------------2 Touch key function -------------------------------------------------------------------------------------2 Remote control introduction ------------------------------------------------------------------------3 Movie --------------------------------------------------------------------------------------------------------5 Music --------------------------------------------------------------------------------------------------------6 Photo---------------------------------------------------------------------------------------------------------7 Ebook--------------------------------------------------------------------------------------------------------7 Calendar--- ---------------------------------------------------------------------------------- -------------------------10 Record------------------------------------------------------------------------------------------------------11 Setting -- --------------------------------------------------------------------------------- ------------------------------13 Music (s) ---------------------------------------------------------------------------------------------------14 Video output ----------------------------------------------------------------------------------------------14 Read USB and charge ---------------------------------------------------------------------------------15 Use TF card -----------------------------------------------------------------------------------------------16 Trouble shooting ----------------------------------------------------------------------------------------17 Technical specification --------------------------------------------------------------------------------18...

  • Page 3: Attention

    Support multitask function, can read E-book while listening music Support AV out High-speed USB2.0 transmission Support windows XP, Vista, win7 Attention： This manual include the important safety measure and using products information, please read this manual before using it. 1. Don’t use the player in the environment of special hot, cold, more dust and humidity. 2.

  • Page 4: Touch Key Function

    1. Power key: Long press POWER for about 3 seconds to turn on/off unit : Earphone jack 3. AV-OUT 4. USB slot 5. Hold key : Lock/unlock touch key or screen. 6. IR : For remote control 7. MIC 8. TF : TF slot Touch screen key function Under the main menu, you can touch to select the function, and enter the submenu.
  • Page 5 1. Don’t touch too heavy, otherwise will cause the touch function is not sensitive or display broken. 2. When find touch is not sensitive, you can adjust the screen under Setting menu 3. When the unit is dead due operate is not correctly, press power key to ON position for 5-10 seconds to power off.

  • Page 6: Remote Control Introduction

    enter. Under main interface, click to open or hide the shortcut menu. Click to display the clock. Click to enter music playing interface Volume: Click to enter volume adjusting interface Brightness: Click to enter brightness adjust interface Remote control introduction: ．...
  • Page 7 Under main interface, click to enter, select the disk to enter play list, select the file you want to play ,and click to pop up the menu, you can copy, paste, delete files. Key instruction 　　 Click to select the previous file, click to select the next file.
  • Page 8 Slide progress bar to adjust the playing point. Video Zoom: Under movie playing interface, click to switch among picture adjustment modes. Settings: Click to select the related settings, include last menu, track, brightness, zoom, play mode, sound channel, subtitle size and color. Click to return to last menu Click...
  • Page 9 MKV/WMV/AVI/MP4/MOV/VOB/DAT/RM/RMVB/FLV AVI format video support resolution within 1280×720 with CODEC Coder Decode: XviD, H.264, DivX RMVB format video support resolution within 1280×720 with CODEC Coder Decode: RV40 FLV format video support resolution within 1280×720 with CODEC Coder Decode: H.263 DAT format video support resolution within 1280×720 with CODEC Coder Decode: MPEG1 MPG format video support resolution within 528×288 with CODEC Coder Decode: MPEG1...
  • Page 10 2.Click “Add”, will show the dialog box as below: 3. Select the original file you need to convert and output place for the converted video file. Then select and set the Parameter you want and click “Save”. As follow: 4. Click “Convert Now” after saved the file, as follow:...

  • Page 11: Music

    5. After finished the conversion, will show as below： 6. The files that converted can be direct played in the player. 2. Music Under main interface, click and select disk to enter the play list, select the file and click to play.
  • Page 12 Medialib Click to order songs as per artist， click to order songs as per album， click to order songs as per genre, click to order songs as per star. Click order songs as per year， click to check all songs in the list. 　...
  • Page 13 Fast forward or Fast backward: Slide to adjust the playing point. EQ Setting：Under playing status, click at the right corner to switch the sound effect among nature, DBB, pop, rock, classic, jazz, vocal, dance, and soft. to enter setting menu, include last menu, playing mode, EQ, Lyric Settings：Click display, brightness, stars and Lyric colors.

  • Page 14: Photo

    Synchronous Lyric Display The player supports lyric files with *.LRC suffix, and displays synchronously. How to use lyric files? Please make sure the lyric has the same name to the music For example: Music file: My heart will go on.mp3 Lyric file: My heart will go on.
  • Page 15 When browsing the photos, click the left side of screen to select the previous photo, click right side to select the next photo. Click the middle of screen to pop up the setting menu. Click to last menu ,when browsing the photo, you can click to slide to adjust the volume (only for the background music status).
  • Page 16 Click to Play/pause Click to zoom in, zoom out ,rotate. Click “+”to zoom in, click “-”to zoom out, click the direction arrow to move the photos, click to rotate by clockwise or counter- clockwise, and click “X” to exit. Click to open the thumbnail photos Click to play music...

  • Page 17: Ebook

    Note: JPEG pixel max support among 6000*6000; BMP max support among 1000*1000. 4. Ebook Under main menu, click and select the disk to enter list, and select the file (TXT) you want to read, click will pop up the menu, you can copy, paste, delete the file. Key instruction: When reading ,click the top side of screen to previous page, click the down side of screen to next page, click the middle of screen to pop up the setting menu.
  • Page 18 (Only for the background music status), click return to main menu.. Setting: click the middle of screen to pop up the setting menu Click to return to last menu. Click to play/ pause Click to enter rotate mode. Click to save mark. Click to load mark.
  • Page 19 5. FM Radio Under main menu, select FM radio and pres to enter as the following picture. Key instruction: 　　 to adjust frequency; click Under FM interface, click auto search. to return to last menu ; Under to slide 2) Click FM interface, click adjust the volume.

  • Page 20: Calendar

    1)Click to return to last menu. 2)Click to open the saved channel list and listening to the radio what you want 3)Click to auto search, a fter finished search, it will auto save the channels. 4)Click to save channel what you want. 5)Click to adjust the brightness.

  • Page 21: Record

    Click to preview / next year or month. Click to set the year, month, day, hour, minute and second. Click to last menu. Click to slide to adjust the volume (only for background music status) Settings：click to enter the setting menu Click return to last menu Click...
  • Page 22 　　 Under the record interface，click to start or pause the record, click to save record. click to return to the previous file, click to return to the main interface directly. Record quality setting： Under record interface，click to pop up record quality setting: Good quality, Normal quality, Poor quality.

  • Page 23: Setting

    8. Setting Under main menu, click to enter System set： a) Output: There are LCD, PAL, NTSC for option. Notes: PAL, NTSC modes, need connect the unit to an external screen through the audio/video cable. b) Language: There are: English, Simplified Chinese and Traditional Chinese for option. c) Autooff: There are 5 minutes, 10 minutes, 30 minutes, 1 hour, always on for option.

  • Page 24: Music

    for option g) Disk Info You can see the information for this player: local disk memory and TF card memory. Power You can check the battery status. Adjust Click five “+” to finish the touch calibration and exit only calibrate ok. System info You can see the information for this player: Software version, size etc.
  • Page 25 11.Games ． 1 Tetris Click on main screen display into as follow: Tetris Menu instruction： Next: Show the shape of next tetris Score: Show the score Grade: Show the grade; optional use. Time: Show the using time Operation instruction:...
  • Page 26 : Quick Drop : Rotate : Move Left : Move Right :Down :Return to main menu. ． Sobkoban Click on main screen display into Sobkoban as below Menu instruction: Undo button-- to undo the last move Puzzle button-- to select a puzzle from a choice of 20 puzzles Restart button—to redisplay the Sobkoban puzzle in its current state.

  • Page 27: Video Output

    12. Video output Connect the unit with the assorted AV (RCA) cable to TV, and set the TV as the current AV IN output status. Under main interface, click to enter setting mode. select output and select PAL/NTSC, it will show on TV. At that time, the screen will be black, you need operate by the remote control.

  • Page 28: Troubleshooting

    Read the TF card After insert the TF card, select "TF card" under main interface. Note: don’t remove the memory card during writing operations (ex. File copy) otherwise all the data contained can be corrupted irreparably. 14. USB and charge USB display mode This product is blessed with high-speed USB2.0 (full speed) interface, the standard mobile disk functions.

  • Page 29: Technical Specification

    Make sure volume is not on 0 position and the connection to earphone is correct. ● Noise Please check if the earphone head is clean. Please check if the music file is destroyed , try to play other music to confirm. Damaged MP3 files may have noise and even cannot be played ●...
  • Page 30 Additional information is available at the technical department of your city. ALL RIGHTS RESERVED DENVER ELECTRONICS A/S WWW . DENVER - ELECTRONICS . COM Imported by: Inter Sales A/S Stavneagervej 22 DK-8250 Egaa...
