Summary of Contents for Denver MPG-2018CPLL
-
Page 2: Declaration
This is a new generation media player, supporting MP3, WMA, WAV files. The perfect music quality, extremely high reliability and delicate appearance work together to make it a master piece in every way. We sincerely hope that it will bring you the best enjoyment that this digital era can offer. -
Page 3: Table Of Contents
Contents Overview ……………….………………………………………………………………………………………2 Declaration …………….………………………………………………………………………………………2 Know your player……….……………………………………………………………………………………..4 Display……………………………………………………………………………………………………………….4 Battery Level ……………………………………………………………………………………………………..4 Basic Functions………………………………………………………………………………………………4 List of Menu…………………………………………………………………………………………………………5 Keys Processing………………………………………………………………………………………………7 Keys function definition…………………………………………………………………………………………….7 Music mode………………………………………………………………………………………………………7 Movie mode……………………………………………………………………………………………………8 Record Mode………………………………………………………………………………….……………………..8 Voice mode………………..……………………………………………………………..…………………………...9 Using FM radio……………………….……………………………………………………………………………10 Photo……………………….………………………………………………………………………..………………11 Setup……………………………….……………………………………………….…………………………;…………12 E-book…………………….…………………………………………………………………………..………………..14 Game…………………………………………………………………………………………………………………….15 Using USB Disk………………………………………………………………………………………………….15 Upgrade your Player……………….…………………………………………………………………………….17 Other settings………………………………………………………………………………………………………18 Secret Space………………………………………………………………………………………………………….19... -
Page 4: Display
Display Equalizer Mode Current music info. Play mode lyric Volume level Music bit rate Power indicate Tempo rate Total songs’ no. Total play time Current song’s no. Play status Background cartoon Music format Current play time Battery Level Battery is full on 3.7 V. As time goes on, capacity indication will monish. Indicator shows blank when battery almost ran out. - Page 5 Record mode Voice mode FM radio mode Photo mode Setup mode Page 4...
-
Page 6: Keys Processing
E-book mode Game mode ： Connect PC into USB mode ： Key Processing Key Function Definition 1 ． ： Power On/Off, Play, Stop, Pause 2 ． M ： Select , enter, exit 3 ． ON/OFF: Power switch 4 ． ： Next, fast forward 5 ．... -
Page 7: Music Mode
7 ． ： Volume down, fast volume down 8 ． REC ： Enter record, or A-B repeat 9 ． USB ： USB jack 。 10. Earphone jack: standard 3.5mm earphone jack. Music mode Simple actions Put earphone plug into earphone jack; Switch the player on, then entry into main menu, select Music and press M to enter, then short press play. -
Page 8: Movie Mode
”to select ， short press M to confirm 3. Short“ Synchronous Lyric Display The player supports lyric files with *.LRC suffix, and displays synchronously. How to use lyric files? Please make sure the lyric has the same name to the music For example: Music file: My heart will go on.mp3 Lyric file: My heart will go on.lrc... - Page 9 2. Short press to start and pause record, long press M to save record file. Voice will be recorded in Voice folder. If displayed “Memory full”, it means mo space to save new record files, please delete other files to release memory space.
-
Page 10: Voice Mode
Record type wav file，fine quality Fine REC wav file，middle quality Long REC Fine VOR wav file with automatic pause when mute，fine quality wav file with automatic pause when mute，middle quality Long VOR 5. Press to start recording. Voice mode Play recorded files Enter into main menu Press to select Voice mode... -
Page 11: Photo
Short press M enter into FM submenu, select FM record, it will skip to record interface, press start recording. Short press o stop. Long press M to save record file, and return to FM mode. 5. Adjusting Press : backward 100KHz Press : forward 100KHz 6. -
Page 12: Setup
Play set: Manual play and Auto play Auto play: Can set auto turn page time from 1-10 seconds. Long press M, return to main menu. Setup 1. Enter into main menu 2. Press to select Setup 3.Short press M enter into Options introduction: (Date&... - Page 13 to increase （ to decrease ） Press Short press switch to month setup 5. After adjust, press M to confirm and exit. ○ LCD Setting “Black screen” means: black screen setting. Press to select from 0-30 seconds, then press M to confirm.
-
Page 14: E-Book
○Firmware upgrade Use for upgrade player’s firmware. Note: After short press M to set the option, short press to exit from the menu. E-book 1. Under main menu, press to select file and press M to entry corresponding submenu: Short press M to enter Main menu interface, press select the menu of the file you want to read,short press M key to exit to last menu. -
Page 15: Using Usb Disk
Speed up Pause / Begin 2 、 Move box Move to left Move to right Move to up side Move to down side M Exit Using as USB Disk The player is also a standard USB disk. Supported Windows 2000 or above (no need for drivers). The player supports USB power supply. -
Page 16: Upgrade Your Player
Upgrade your player You can use Pc software to maintain or upgrade player’s firmware. Connect player to PC Running upgrade tools MP3 Player Update Tool (supplied with installation CD), then click ’Select new firmware file’ to choose the upgrade file. 3. -
Page 17: Other Settings
5. While upgrade successful, the player will display like this: Firmware upgrade is to improve player’s performance; you can still use it normally without doing upgrade process Player may not work by incorrect process! Please read this manual carefully before doing upgrade process. The upgrade software cannot work for other player and vice verse. - Page 18 3. Press M to entry folder choosing interface 4. Press to choose a folder 5. Press M to entry the selected folder Please note: You can set folders independently in Music / Recorder / Play mode Delete file (Stop submenu) You delete correspond files/channels in each Music/Play/FM modes.
- Page 19 Please safely removed player and unplug USB cable after delete files on PC, otherwise some files will not be removed. Play mode (Play submenu) You can choose different play mode (i.e. repeat, shuffle) when playing music or recorded files ○ REPEAT Playing music files in sequence until the end of folder (Normal) Repeat single music file...
-
Page 20: Secret Space
Symbol ”A-B” fixed and starting repeat between A-B. Under this mode, press REC to reset A point (the playback time is referred to the A-B repetition) ○ Karaoke Mode (No such Function in Playing mode) 1. Under A-B repeating 2.Short press to enter this mode When repeat icon change to Karaoke icon... - Page 21 Click ‘Partition and Encrypt’ card, Allocate appropriate space and set username and password, and then click Start. After restart you will find two disks (only one disk can be seen on Windows 2K SP4or prior), click the encrypted disk (the second one) as follow: Page 20...
-
Page 22: Convert Video Format Files Into Amv
5.Running executable file ‘RdiskDecrypt.exe’ and input username and password. If all are correct, disk will be opened, and files can be copied into. 6.You must enter username and password each time access encrypted disk. Warning: Divide one disk into parts will remove all data and so does combine process. Warning: Please remember username and password. - Page 23 2. Select unprocessed AMV/AVI files, then click , the icon will be highlighted into and a dialog box will show. Choosing the setting of the AMV/AVI file you want to obtain, then click OK to confirm. (Note: Only pixels in “160 * 120 can be supported for this player at AMV format, pls refer below) to start converting 。...
-
Page 24: Troubleshooting
4. After convert, the AMV files will be played automatically. Troubleshooting No Power Check if battery have no power Make sure you have switched the player on No Sound Make sure volume is not on 0 position and the connection to earphone is valid Please make sure the earphone is clean Damaged MP3 files may have noise and even cannot be... -
Page 25: Technical Specifications
Technical Specifications Screen Matrix (128*160), 65536 colours Connecting to PC High Speed USB2.0 Full Speed Memory 2GB Flash Power Supply Maximum 5 hours in music play mode or 2 hours for video. Voice Recorder Sample rate 8KHz Format WAV (32K bps) Time 35hours (512M Flash) MP3、WMA...
