F S
E R I E S
F B - 1 0 0
S
U B W O O F E R
THE TOA FB-100 SUBWOOFER
ideal solution for adding powerful low frequency
enhancement to commercial,residential or retail
sound systems.
The FB-100 features a high-performance
tuned, ported enclosure with an acoustic
bandpass filter design to eliminate the need
for an external crossover. An omni-directional
coverage pattern allows flexible placement
— floor, wall, corner or ceiling.
The FB-100 has a heavy-duty 10" woofer for
high power handling and extended low
frequency response.The solidly constructed,
paintable enclosure has a removable terminal
block for loop-through terminations and six
rigging points for suspended mounting.
Options include a matching transformer for
connection of the FB-100 to distributed
speaker systems and a 900 Series Low Pass
Filter Module for convenient system
equalization.The FB-100 also carries a five
year warranty.
H
is the
I G H L I G H T S
Low Frequency Enhancement
for a wide variety of speaker
system applications including
hotels, houses of worship,
museums, offices, residential
spaces, restaurants, and retail
stores.
Tuned, Ported Enclosure
for deep bass and low distortion.
Acoustic Bandpass Filter Design
eliminates need for external
crossover.
Floor, Wall, Corner or Ceiling-Mount:
omni-directional coverage allows
flexible placement.
High Power Handling:
450 W (Continuous Program)
Extended Low Frequency Response:
35 - 160 Hz (-10 dB, 1/2 space)
O
P T I O N A L
E-07S
900 Series Low Pass Filter Module for convenient system
equalization
MT-S0601
Matching Transformer (60 W max.) for 70.7 V/100 V distributed
speaker systems, mountable inside enclosure
High Sensitivity:
94 dB SPL (1 W / 1 m, 1/2 space)
Heavy-Duty Loudspeaker Component:
10" woofer with ferrite magnet
and 2" aluminum voice coil for
efficient heat dissipation.
Solid, Vibration-Free Construction,
top-loaded for simplified
maintenance.
Paintable Black Finish
Removable Terminal Block with
Loop-Through Terminations
for convenient connection of
parallel speakers.
Six Rigging Points
for suspended mounting.
Five Year Warranty
A
C C E S S O R I E S
