Back Panel

9
i F
tem unction
1 Alarm
VGA Output
2
USB/Mouse
3
NET
4
RS485
5
Power Switch
6
Power Supply
7
8 Audio Input
9 Video Input
10 BNC Output
11 Audio Output
Ground
12
PRODUCT OVERVIEW
10 8
1 1
D
eScription
4 alarm inputs; 1 alarm output
For connecting to VGA monitor
Use Lower USB port for mouse connection; Use Upper USB port for USB
flashdrive or backup
For connecting RJ45 ethernet cable to PC or router
For connecting PTZ cameras
Power On/Off
For connection to power cord +12V DC
For connecting audio signal from audio capable cameras or self powered
microphones (RCA jacks)
For connecting video signal from cameras (BNC)
For connecting to a BNC monitor
For connecting audio signal to amplified speakers (RCA jacks)
Ground Connection
Page 9
