di
mdwin
mdwin0
vi
vadp
<product dependent>
valevel
valevel0
inter
0,<positive integer> 6/6
0,<positive integer> 6/6
0,<positive integer> 6/6
0,<positive integer> 6/6
0,<positive integer> 6/6
0,1 6/6
0,1 6/6
1~999 6/6
Indicate the source id of di trigger.
This field is required when trigger condition is
"di".
One bit represents one digital input. The LSB
indicates DI 0.
Indicate the source window id of motion
detection.
This field is required when trigger condition is
"md".
One bit represents one window.
st
The LSB indicates the 1
For example, to detect the 1
set mdwin as 5.
Similar to mdwin. The parameter takes effect
when profile 1 of motion detection is enabled.
Indicate the source id of vi trigger.
This field is required when trigger condition is
"vi".
One bit represents one digital input. The LSB
indicates VI 0.
Indicate the source id of vadp event notification.
Each bit corresponds to one vadp source, and
the LSB indicates source id 0.
For example, to detect event from any one of
source id 0, 1 and 3, set vadp to 11.
* Only available when vadp is listed in
"capability_supporttriggertypes"
Select audio detection event.
0: not select
1: select
Select audio detection profile event.
0: not select
1: select
Interval of snapshots in minutes.
This field is used when trigger condition is "seq".
VIVOTEK
window.
st rd
and 3 windows,
