  • Page 2 Warning Before Installation Power off the Network Camera as soon as smoke or unusual odors are detected. Contact your distributor in the event of occurrence. Do not place the Network Camera around heat sources, such as a television or oven. Keep the Network Camera away from direct sunlight.
  • Page 3 Do not place the Network Camera on unsteady surfaces. Do not disassemble the Network Camera. Do not insert sharp or tiny objects into the Network Camera. Do not touch the Network Camera during a lightning storm. Do not drop the Network Camera. EN - 2...

  • Page 4: Package Contents

    Package Contents FD8161 Software CD A/V Cable Screwdriver Power Adapter Alignment Sticker Quick Installation Guide / Warranty Card Screws and I/O Connector EN - 3...

  • Page 5: Physical Description

    Keep a note of the MAC address before installing the camera. Network Camera RoHS Model No: FD8161 MAC:0002D107258A This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 6: Installation Tips

    Hardware Installation First, use the supplied screwdriver to detach the dome cover from the camera base. Then, follow the steps below to install the camera to either the ceiling or the wall. Installation Tips Before installing the camera, look for a shooting area that best suits your needs. The built-in PIR (Passive Infrared) sensor will be triggered when a person enters its detec- tion range.

  • Page 7: Network Deployment

    Network Deployment General Connection (without PoE) 1. If you have external devices such as sensors and alarms, connect them to the general I/O terminal block. 2. Connect the camera to a switch via Ethernet cable. 3. Connect the power cable from the Network Camera to a power outlet. 1 2 3 4 Ethernet Switch Installation Tips...

  • Page 8: Power Over Ethernet (Poe)

    Power over Ethernet (PoE) When using a PoE-enabled switch This Network Camera is PoE-compliant, allowing transmission of power and data via a single Ethernet cable. Follow the below illustration to connect the Network Camera to a PoE-enabled switch via Ethernet cable. PoE Switch When using a non-PoE switch Use a PoE power injector (optional) to connect between the Network Camera and a...

  • Page 9: Assigning An Ip Address

    “Next” button to continue the program. Installation Wizard 2 3. The program will search for VIVOTEK Video Receivers, Video Servers, and Network Cameras on the same LAN. 4. After searching, the main installer window will pop up. Click on the MAC that matches the one labeled on the bottom of your device to connect to the Network Camera via Internet Explorer.

  • Page 10: Ready To Use

    Ready to Use 1. Access the Network Camera on the LAN. 2. Retrieve live video through a web browser or recording software. For further setup, please refer to the user's manual on the software CD. EN - 9...

  • Page 11: Adjusting The Lens

    Adjusting the Lens Based on the live image retrieved from the camera, adjust the camera lens by doing the following: To adjust the viewing angle 1. Loosen the pan adjustment screw and then turn the lens module left and right. Upon completion, tighten the screw.

  • Page 12: To Adjust The Zoom Factor And Focus Range

    To adjust the zoom factor and focus range 1. Loosen the zoom controller to adjust the zoom factor. Upon completion, tighten the zoom controller. 2. Loosen the focus controller to adjust the focus range. Upon completion, tighten the focus controller. Audio NTSC Int.
