Specifications

Monitor Specifications
LCD Module Diagonal: 48 cm/19.0 inches
Viewable Image Size: 48 cm/19.0 inches
Native Resolution (Pixel Count): 1280 x 1024
Input Signal
Display Colours
Synchronization Range Horizontal: 31.5 kHz to 81.1 kHz
Viewing Angle Left/Right: ±89° (CR > 10)
Up/Down: ±89° (CR > 10)
Image Formation Time
Resolutions Supported Landscape: 720 x 400*
Active Landscape: Horiz.: 376 mm/14.8 inches
Display Area
Portrait: Horiz.: 301 mm/11.9 inches
Power Supply
Power Consumption
(without optional Sound Bar)
Current Rating
Dimensions Landscape: 402.3 mm (W) x 361.5 - 491.5 mm (H) x 200.0 mm (D)
Height Adjustment: 130 mm/5.1 inches (Landscape)
Weight
Environmental Considerations
Operating Temperature: 5°C to 35°C/41°F to 95°F
Humidity: 30% to 80%
Storage Temperature: -10°C to 60°C/14°F to 140°F
Humidity: 10% to 85%
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
*2 NEC-Mitsubishi Electronics Display cites recommended resolution for optimal display performance.
NOTE: Technical specifications are subject to change without notice.
MultiSync LCD1980FXi Monitor
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync.TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. Positive/Negative
Sync on Green (Video 0.7V p-p and Sync Negative 0.3V p-p)
16,777,216
Vertical: 50 Hz to 85 Hz
18 ms (Typ.)
1
: VGA-Text
640 x 480* 1 at 60 Hz to 85 Hz
800 x 600* 1 at 56 Hz to 85 Hz
832 x 624* 1 at 75 Hz
1
1024 x 768* at 60 Hz to 85 Hz
1152 x 864* 1 at 75 Hz
1280 x 1024 at 60 Hz*
1
Portrait: 480 x 640* at 60 Hz to 85 Hz
1
600 x 800* at 56 Hz to 85 Hz
624 x 832* 1 at 75 Hz
768 x 1024* 1 at 60 Hz to 85 Hz
1
864 x 1152* at 75 Hz
1024 x 1280 at 60 Hz*
Vert.: 301 mm/11.9 inches
Vert.: 376 mm/14.8 inches
AC 100-240V ~ 50/60Hz
48W (typ)
0.48A@100-120V / 0.23A@220-240V (without optional Sound Bar)
0.55A@100-120V / 0.25A@220-240V (with optional Sound Bar)
16.2 inches (W) x 14.4 - 19.5 inches (H) x 7.9 inches (D)
Portrait: 330.3 mm (W) x 397.5 - 521.5 mm (H) x 200.0 mm (D)
13.3 inches (W) x 16.9 - 21.0 inches (H) x 7.9 inches (D)
9.7 kg (21.4 lbs)
Feet: 0 to 10,000 Feet
Feet: 0 to 40,000 Feet
English-13
Notes
Active matrix; thin film transistor (TFT) liquid
crystal display (LCD); 0.294 mm dot pitch;
270 cd/m 2 white luminance, typical;
600:1 contrast ratio, typical.
Digital Input: DVI
Depends on display card used.
Automatically
Automatically
Some systems may not support all modes listed.
2 to 75 Hz
Some systems may not support all modes listed.
2 to 75 Hz
