Features

Ambix+ Technology™: Dual input technology allowing both analog and digital inputs off of one connector (DVI-I) as well as ad-
ditional legacy analog support off of a traditional 15-pin VGA connector. Provides traditional MultiSync technology compatibility for
analog as well as DVI-based digital compatibility for digital inputs. DVI-based digital interfaces include DVI-D,DFP and P&D.
DVI-I: The integrated interface ratifi ed by the Digital Display Working Group (DDWG) that allows both digital and analog connectors
off of one port. The "I" stands for integration for both digital and analog, The digital portion is DVI-based.
DVI-D: The digital-only subset of DVI ratifi ed by the Digital Display Working Group (DDWG) for digital connections between comput-
ers and displays. As a digital-only connector, analog support is not provided off of a DVI-D connector. As a DVI-based digital only
connection, only a simple adapter is necessary for compatibility between DVI-D and other DVI-based digital connectors such as DFP
and P&D.
DFP (Digital Flat Panel): An all-digital interface for fl at panel monitors which is signal compatible with DVI. As a DVI-based
digital only connection, only a simple adapter is necessary for compatibility between DFP and other DVI-based digital connectors such
as DVI and P&D.
P&D (Plug and Display): The VESA standard for digital fl at panel monitor interfaces. It is more robust than DFP since it allows
for other options off a signal connector (options like USB, analog video and IEEE-1394-995). The VESA committee has recognized
that DFP is a subset of P&D. As a DVI-based connector (for the digital input pins), only a simple adapter is necessary for compatibility
between P&D and other DVI-based digital connector such as DVI and DFP.
Pivoting Stand: Allows users to adjust the monitor to the orientation that best fi ts their application, either Landscape orientation for
wide documents, or portrait orientation for the ability to preview a full page on one screen at one time. The Portrait orientation is also
perfect for full screen video conferencing.
Reduced Footprint: Provides the ideal solution for environments requiring superior image quality but with size and weight limita-
tions. The monitor's small footprint and low weight allow it to be moved or transported easily from one location to another.
Control Systems: Allows you to adjust the colors on your screen and customize the color accuracy of your monitor to
AccuColor ®
a variety of standards.
OmniColor™: Combines Six-axis color control and the sRGB standard. Six-axis color control permits color adjustments via six axes
(R, G, B, C, M and Y) rather than through the three axes (R, G and B) previously available. The sRGB standard provides the monitor
with a uniform color profi le. This assures that the colors displayed on the monitor are exactly the same as on the color printout (with
sRGB supporting operating system and sRGB printer). This allows you to adjust the colors on your screen and customise the color ac-
curacy of your monitor to a variety of standards.
OSM ® (On-Screen Manager) Controls: Allow you to quickly and easily adjust all elements of your screen image via simple to
use on-screen menus.
ErgoDesign Features ® : Enhance human ergonomics to improve the working environment, protect the health of the user and save
money. Examples include OSM controls for quick and easy image adjustments, tilt base for preferred angle of vision, small footprint
and compliance with MPRII and TCO guidelines for lower emissions.
Plug and Play: The Microsoft solution with the Windows 95/98/2000/Me/XP operating system facilitates setup and installation
® ®
by allowing the monitor to send its capabilities (such as screen size and resolutions supported) directly to your computer, automatically
optimizing display performance.
IPM (Intelligent Power Manager) System: Provides innovative power-saving methods that allow the monitor to shift to a
®
lower power consumption level when on but not in use, saving two-thirds of your monitor energy costs, reducing emissions and lower-
ing the air conditioning costs of the workplace.
Multiple Frequency Technology: Automatically adjusts monitor to the display card's scanning frequency, thus displaying the
resolution required.
Capability: Allows you to use the entire screen area in most resolutions, signifi cantly expanding image size.
FullScan ®
Wide Viewing Angle Technology: Allows the user to be able to see the monitor from any angle (178 degrees) from any orien-
tation — Portrait or Landscape. Provides full 178 degrees viewing angles either up, down, left or right.
VESA Standard Mounting Interface: Allows users to connect their MultiSync monitor to any VESA standard third party mount-
ing arm or bracket. Allows for the monitor to be mounted on a wall or an arm using any third party compliant device.
NaViSet™: Is a ground-breaking software family providing intuitive access to all monitor setting controls and remote diagnosis via
the Windows interface, based upon the VESA standard, DDC/CI. Using a standard VGA or DVI signal cable, NaViSet can either
benefi t single users or, with NaViSet Administrator, reduce the Total Cost of Ownership through remote network-wide maintenance,
diagnosis and asset-reporting.
CableComp™: Automatic long cable compensation prevents image quality degradation caused by long cable lengths.
No-touch Auto Adjust™ (Analog input only): No-touch auto adjust automatically adjusts the monitor to optimal settings upon
initial setup.
sRGB Color Control: A new optimized color management standard which allows for color matching on computer displays and
other peripherals. The sRGB, which is based on the calibrated color space, allows for optimal color representation and backward
compatibility with other common color standards.
GammaComp™: Internal circuitry automatically converts 8-bit data from the PC to 10-bit and back to 8-bit, producing smooth, ac-
curate color tones. Gamma can be set by using preset values or creating a custom setting from 0.7 to 4.4 in increments of 0.1.
