- Page 1 INSTALLATION, AND MAINTENANCE MANUAL FOR GAS FIRED, WALL-HUNG BOILERS RSF 30 E Model TYPE C ROOM SEALED SEDBUK BAND D 0694 TA01A011.B1003 Technical Specification RADIANT BRUCIATORI S.p.A. Montelabbate (PU) ITALY ENGLISH Supplied By www.heating spares.co Tel. 0161 620 6677...
- Page 2 Supplied By www.heating spares.co Tel. 0161 620 6677...
-
Page 3: Table Of Contents
INDEX INSTALLATION INSTRUCTIONS AND WARNINGS page TECHNICAL DATA page OVERALL DIMENSIONS - EXHAUST FLUE SYSTEM page GENERAL INSTALLATION REQUIREMENTS page BOILER INSTALLATION page ELECTRICAL CONNECTIONS page 8;13 BOILER CONTROL PANEL page STARTING UP THE BOILER FOR THE FIRST TIME page MULTIGAS OPERATION page MAIN COMPONENTS... - Page 4 Installation Manual THE FRIENDLY POWER OF HEAT Thank you for choosing RADIANT Declaration for purposes of Art. 7 of Law 46 of 5 April 1990. RADIANT BRUCIATORI S.p.A. hereby declares that all of its products are constructed to industry standards as required by the Article in question and by Article 5 of the law in effect (D.P.R.
-
Page 5: Technical Data
CENTRAL HEATING - DOMESTIC HOT WATER sealed combustion circuit type RSF 30 E - electronic ignition Coaxial vertical C52 Double Coaxial horizontal Technical data... -
Page 6: Overall Dimensions - Exhaust Flue System
Installation Manual OVERALL DIMENSIONS - EXHAUST FLUE SYSTEM TYPE C WALL-MOUNTED BOILERS SEALED COMBUSTION CIRCUIT: Kit G Horizontal coaxial exhaust flue system with 360° rotation. S TOP 55° 60° 70° 50° 50° 60° 80° 45° 40° 40° 30° 65.5 55.5 Kit B Double exhaust/emission twin flue system with 360°... -
Page 7: General Installation Requirements
Installation Manual GENERAL INSTALLATION REQUIREMENTS GAS SAFETY It is the law that all gas appliances are installed by a CORGI registered installer (you can check this by contacting corgi on 01256.372200) in accordance with the regulations listed below. Failure to install appliances correctly could lead to prosecution. It is in your own interest and that of safety to ensure that the law is complied with. - Page 8 Installation Manual FLUE POSITION IMPORTANT: THE FLUE SYSTEM SHALL BE INSTALLED IN ACCORDANCE WITH THE RECOMMENDATIONS CONTAINED IN BS 5440:1. The boiler MUST be installed so that the terminal is exposed to the external air. It is important that the position of the terminal allows free passage of air across it at all times. If the terminal discharges into a pathway or passageway check that combustion products will not cause nuisance and that the terminal will not obstruct the passageway.
- Page 9 Installation Manual MINIMUM DISTANCES FOR FIXING TO WALL KIT A To allow access in the boiler for MOD. 1 KIT H MOD. 2 maintenance operations, MOD. 2 minimum distances shown below must be respected (fig. 1): MOD. 1 CON STAFFA MOD. 1 WITH BRACKET MOD.
- Page 10 Installation Manual GAS CONNECTIONS Table n°1 The gas supply must be connected up by Antifreeze Temperature qualified person. Ethylene glycol freezing point boiling point The following standards must be complied (%) volume (°C) (°C) with: UNICIG 7131/72 and UNICIG 7129/92 (of 21/04/93) Before installing the boiler, make sure of the following:...
-
Page 11: Electrical Connections
Installation Manual ELECTRICAL CONNECTIONS For qualified personell only: the boiler works with 230 V 50 Hz AC current and has maximum input of 170 W. Connection to the electrical mains must be performed with a device having an omnipolar opening of at least 3 mm. Make sure the live and neutral connections conform to the diagram. - Page 12 Installation Manual CONTROL PANEL ELECTRONIC WATER PRESSURE GAUGE LEGEND (see fig. 1) 14 13 ON / OFF POWER SWITCH HEATING TEMPERATURE ADJUSTMENT KNOB DOMESTIC HOT WATER TEMPERATURE ADJUSTMENT KNOB OUTSIDE TEMPERATURE DISPLAY PAD (ONLY WITH OPTIONAL OUTSIDE TEMPERATURE SENSOR FITTED) CHIMNEY-SWEEPER SELECTION PAD / PARAMETER SETTING SERVICE PAD MODE SELECTION PAD (SUMMER...
- Page 13 • empty from the lowest point (where possible). WARNING Please ensure that the boiler in commissioned in line with all BENCHMARK BOOKLET REQUIREMENTS. Failure to do this may in validate the guarentee. COMBI - TA01A011.B1003 Supplied By www.heating spares.co Tel. 0161 620 6677...
- Page 14 GAS DATA TABLE Models: RSF 30 E NATURAL GAS G 20 LIQUID BUTAN GAS G 30 LIQUID PROPANE GAS G 31 Lower Wobbe index (15°C;...
-
Page 15: Main Components
Installation Manual MAIN COMPONENTS 1. FLUE HOOD – ROOM SEALED COMBUSTION CHAMBER 2. COMBUSTION CHAMBER 3. ROOM SEALED CHAMBER COVER 4. ROOM SEALED CHAMBER BACK 5. HEAT EXCHANGER Mod. 30.000 6. FLAT PLATE TYPE EXCHANGER 7. MULTIGAS BURNER WITH 17 RAMPS 8. -
Page 16: Electrical Connections
Installation Manual ELECTRICAL CONNECTION PRINTED CIRCUIT BOARD CVI-M SM20015 (cod. 76655LA) DISPLAY DIGITAL BOARD 2000 SKO6206 (COD. 76654LA) - LINE - NEUTRAL - AIR PRESSURE SWITCH - WATER PRESSURE SWITCH - ELECTRONIC FLOWSWITCH - MAIN SWITCH - D.H. WATER SENSOR ELECTRONIC IGNITION BOARD - HEATING SENSOR 1,5bar... - Page 17 Installation Manual WIRING DIAGRAM FOR REMOTE CONTROL INSTALLATION (no zone valves) Interfaccia Fig. 3 grey orange Fig. 2 P.B.C. INTERFACE REMOTE Fig. 4 EXTERNAL SENSOR M1 1 REMOTO Fig. 5 Fig. 1 Fit the interface (fig. 2) on the circuit board (fig. 1) into the holes A and B provided (see fig. 1). Connect plug M1 on the interface circuit board (fig.
-
Page 18: Maintenance
Installation Manual MAINTENANCE To keep the boiler in efficient and safe operating condition, we recommend you perform the following checks at least once a year: • Check all seals on the gas side and replace gaskets to restore perfect seal as required. •... - Page 19 Installation Manual SPARE PARTS SHORT LIST CODE DESCRIPTION RSF 30 E 20046LA 24 PLATE EXCHANGER 17B1902406 21032LA GAS BURNER 17 R. 1,20 NATURAL GAS 21033LA GAS BURNER 17 R. 0,75 L.P.G. 24040LA CIRCULATING PUMP GOLD 50V1 SHUL CLF6 15/6 W/ AIR VENT...
- Page 20 RADIANT BRUCIATORI s.p.a. Via Pantanelli, 164/166 - 61025 Loc. Montelabbate (PU) Tel. +39 0721 9079.1 • fax. +39 0721 9079279 e-mail: tecnico@radiant • Internet: http://www.radiant.it UK – Radiant Helpline – 01329.828555 ALL DESCRIPTIONS AND ILLUSTRATIONS CONTAINED IN THIS LEAFLET HAVE BEEN CAREFULLY PREPARED BUT WE RESERVE THE RIGHT TO MAKE CHANGES AND IMPROVEMENTS IN OUR PRODUCTS WHITCH MAY AFFECT THE ACCURANCY OF THE INFORMATION CONTAINED IN THIS LEAFLET.
