Radio Connections

Each port connector provides all connections needed for your radios. The RC210 comes with two versions of connectors - DB9
computer style connectors or RJ45 modular jacks.
9-Pin RJ-45
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9
Direction
Name/Description
-----►
CTCSS Encode
◄-----
CTCSS Decoder
-----► radio control OUT
TX PTT
-----►
TX Audio
◄-----
Audio input
◄-----► Ground
◄----- RX COS Logic
◄-----► Ground
◄-----► Ground
10
Control OUT
Logic IN
output to radio
from radio
IN
