Vivotek FD816C-HF2 User Manual page 281

Technical Specifications
Model FE8182
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 128MB
RAM 256MB
Camera Features
Image Sensor 1/3.2" Progressive CMOS
Maximum Resolution 1920x1920
Lens Type Fixed-focal
Focal Length f = 1.05 mm
Aperture F2.0
180° (Horizontal)
Field of View 180° (Vertical)
180° (Diagonal)
Shutter Time 1/5 sec. to 1/32,000 sec.
WDR Technology WDR Enhanced
ePTZ:
Pan/tilt/zoom Functionalities
4x digital zoom IE plug-in
On-board Storage MicroSD/SDHC/SDXC card slot
Video
Compression H.264 & MJPEG
Maximum Frame Rate 15 fps @ 1920 x 1920
Maximum Streams 3 simultaneous streams
Video Streaming Adjustable resolution, quality and bitrate
Adjustable image size, quality and bit rate; Time
stamp, text overlay, flip & mirror; Configurable
brightness, contrast, saturation, sharpness,
Image Settings
white balance, exposure control, gain, backlight
compensation, privacy masks; Scheduled profile
settings, 3D Noise Reduction, smart stream
Audio
Audio Capability Audio input
Compression G.711, G.726
Interface Buit-in Microphone
Effective Range 5 Meters
Network
Users Live viewing for up to 10 clients
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/
RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS,
Protocols
PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP,
SSL, TLS
VIVOTEK INC.
6F, No.192, Lien-Cheng Rd., Chung-Ho,
New Taipei City, 235, Taiwan, R.O.C.
T: +886-2-82455282 F: +886-2-82455532
E: sales@vivotek.com
Interface
ONVIF
Intelligent Video
Video Motion Detection
Alarm and Event
Alarm Triggers
Alarm Events
General
Connectors
LED Indicator
Power Input
Power Consumption
Dimensions
Weight
Safety Certifications
Operating Temperature
Warranty
System Requirements
Operating System
Web Browser
Other Players
Included Accessories
Others
Dimensions
60 mm
All specifications are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved.
VIVOTEK USA VIVOTEK Europe
2050 Ringwood Avenue, Randstad 22-133, 1316BW Almere,
San Jose, CA 95131 The Netherlands
T: 408-773-8686 F: 408-773-8298 T: +31(0)36-5298-434
E: salesusa@vivotek.com E: saleseurope@vivotek.com
10 Base-T/100 BaseTX Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e
& CAT6 cables which are compliant with the 3P/
ETL standard.
Supported, specification available at www.onvif.
org
Five-window video motion detection
Video motion detection, manual trigger, periodical
trigger, system boot, recording notification,
camera tampering detection, audio detection
Event notification using HTTP, SMTP, FTP and NAS
server, SD Card
File upload via HTTP, SMTP, FTP, NAS server and
SD card
RJ-45 for Network/PoE connection
System power and status indicator
IEEE 802.3af PoE Class 1
Max. 3 W
Ø 60 x 102.5 mm
133g
CE, LVD, FCC Class B, VCCI, C-Tick
Starting Temperature: 0°C ~ 40°C (32°F ~ 104°F)
Working Temperature: -10°C ~ 40°C (14°F ~ 104°F)
24 months
Microsoft Windows 8/7/Vista/XP/2000
Mozilla Firefox 7~10 (streaming only)
Internet Explorer 7/8/9/10
VLC: 1.1.11 or above
QuickTime: 7 or above
Quick installation guide, warranty card
102.5 mm
VIVOTEK India
602, Best sky Tower, Plot No. F-5,
Netaji Subhash Place, Pitam Pura, Delhi-110 034
T: +91-11-45137465
E: salesindia@vivotek.com
User's Manual - 281
VIVOTEK
Ver. 5
