- Page 1 Micro Box Hardware Manual 2016/07/05...
-
Page 2: Table Of Contents
Connecting Audio Out Devices (Optional) ............24 Connecting a Serial Devices (Optional)..............25 Other Adjustments and Accessories How to Install / Remove the Memory Card ............26 How to Insert the Memory Card ................26 How to Remove the Memory Card ..............27 www.acti.com... - Page 3 Hardware Manual Accessing the Camera Configure the IP Addresses ................... 28 Using DHCP Server to Assign IP Addresses ............28 Using the Default Camera IP Address ..............30 Access the Camera ....................32 www.acti.com...
-
Page 4: Precautions
Every reasonable care has been taken during the writing of this manual. Please inform your local office if you find any inaccuracies or omissions. ACTi will not be held responsible for any typographical or technical errors and reserves the right to make changes to the product and manuals without prior notice. - Page 5 This product has been tested and found to comply with the limits for Class B Information Technology Equipment according to European Standard EN 55022 and EN 55024. In a domestic environment, this product may cause radio interference in which cause the user may be required to take adequate measures. www.acti.com...
-
Page 6: Safety Instructions
Safety Check Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine if the product is in proper operating condition. www.acti.com... -
Page 7: Introduction
List of Models This hardware manual contains the following models: 2MP Outdoor Micro Box with Basic WDR, SLLS, Fixed lens From the installation perspective, the above models are very similar; therefore one manual is used for all of them. www.acti.com... -
Page 8: Package Contents
Terminal Block Bracket Camera Set Screws (for Power) Terminal Block Terminal Block Quick Installation Guide (for DI/DO) (for RS-232) Warranty Card IMPORTANT: When the camera is taken out from the box, the lens cover is covered by a thin film. www.acti.com... - Page 9 Hardware Manual DO NOT remove this film. It is used to protect the lens cover from scratches or fingerprint marks which may happen during installation. Remove this film only after the camera is securely installed and all connections are complete. www.acti.com...
-
Page 10: Physical Description
See Connecting DI/DO Devices (Optional) on page 21 for information. Camera Port Connects the camera. Audio Input / Output Connects to audio input and output devices, such as microphones and speakers. See Connecting an Audio Out www.acti.com... - Page 11 19 for more information. Reset Button Restores the factory default settings of the camera. To reset the camera, while the power is on, press and hold the Reset Button for at least 5 seconds or until the Power LED goes off. www.acti.com...
-
Page 12: Mounting Options
NOTE: For more information about the mounting solutions and accessories, please check the Mounting Accessory Selector in our website (http://www.acti.com/mountingselector). The above mounting accessories are not included in the package. Contact your sales agents to purchase. www.acti.com... -
Page 13: Installation Procedures
Before installing the bracket, make sure the ceiling or wall can bear more than the weight of the camera and its accessories. Install the bracket to the ceiling or wall using the three (3) screws included in the bracket package. www.acti.com... -
Page 14: Step 2: Attach The Camera
Similar procedures apply when attaching the bracket to the bottom side for wall installation. 1. Attach the camera to the bracket through the screw hole on the rear of the camera module. 2. Loosen the knob and adjust the camera angle. Knob 3. Route the camera cable towards the main unit. www.acti.com... -
Page 15: Step 3: Install The Main Unit
1. Install the mounting rail on the surface using the two (2) screws. 2. Attach the lower end of the main unit to the mounting rail. 3. Slightly push up the main unit and snap the upper end into place. www.acti.com... -
Page 16: Step 4: Connect The Cables
1. Connect the camera cable connector to the Camera port of the main unit. 2. Connect the Audio terminal block to the Audio port of the main unit. Camera Cable Audio 3. For excess cable, properly roll the cable as shown below; do not bend the cable. www.acti.com... -
Page 17: Step 5: Connect To Network
Connecting a Power Adapter (Optional) on page 19 for more information. 3. As needed, connect and power up other devices, such as digital input/output, audio, or serial device. See 錯誤! 找不到參照來源。 on page 錯誤! 尚未定義書籤。 for more information on connecting other devices. www.acti.com... -
Page 18: Step 6: Access The Camera Live View
Power Cable PoE Switch Ethernet Cable AC Power (Data + Power) Source Camera Step 6: Access the Camera Live View Accessing the Camera on page 28 for more information on how to access the Live View of the camera. www.acti.com... -
Page 19: Cable Connections
1. Loosen the screws of the 12V and GND pins of the power terminal block. 2. Take note that a standard power adapter cable has two (2) different wires: Connects to GND Pin White stripe: Connects to 12V Pin www.acti.com... - Page 20 4. Tighten the screws of the 12V pin and the GND pins to secure the wire connection. 5. Set the prepared power adapter for connection later. Below is an example of a power adapter with an attached terminal block. NOTE: The power adapter is not bundled in the package. www.acti.com...
-
Page 21: Connecting Di/Do Devices (Optional)
Connect the wires of the digital input device to GND and Digital Input (DI) To connect an output device (DO), map the pins as below: Device Mapping Instructions Connect the wires of the digital output device to 12V Digital Output (DO) and DO. www.acti.com... - Page 22 DI/DO device to an external power source. In this case, wire connection to GND and DI pins to connect a DI device and use the 12V and DO pins to connect a DO device. See wiring scheme below: www.acti.com...
- Page 23 The illustration below is a graphic example of connecting a relay to a high voltage DO device. 110V-220V AC External Power Source Relay (DO1 Device) Camera Illuminator NOTE: For more information on DI/DO connections, please refer to the Knowledge Base article All About Digital Input and Digital Output downloadable from the link below (http://Download.acti.com?id=516). www.acti.com...
-
Page 24: Connecting Audio Out Devices (Optional)
Press and hold the orange tab as you insert the wire through the pin slot, then release the orange tab to secure the wire. NOTE: The audio input pins are already connected to the built-in microphone. Do not modify this connection. www.acti.com... -
Page 25: Connecting A Serial Devices (Optional)
To connect a serial device, map the pins as below: Terminal Block Wire Mapping Pin Number / Label Main Unit Serial Device Ground pin Press and hold the orange tab as you insert the wire through the pin slot, then release the orange tab to secure the wire. www.acti.com... -
Page 26: Other Adjustments And Accessories
Supports microSDHC and microSDXC cards. How to Insert the Memory Card 1. Open the memory card slot cover. 2. Insert the memory card with the metal contacts facing down the main unit. 3. Push the card until it clicks into place. www.acti.com... -
Page 27: How To Remove The Memory Card
In case there is a need to remove the card, make sure to access the camera Web Configurator to safely “unmount” the card first (see the camera Firmware User’s Manual for more information). Once unmounted from the firmware, push the card to eject it from the slot. www.acti.com... -
Page 28: Accessing The Camera
Windows system – just by pressing the “Network” icon, all the cameras of the local area network will be discovered by Windows thanks to the UPnP function support of our cameras. In the example below, we successfully found the camera that we had just connected to the network. www.acti.com... - Page 29 The IP Utility can be downloaded for free from http://www.acti.com/IP_Utility With just one click, you can launch the IP Utility and there will be an instant report as follows: You can quickly see the camera model in the list. Click on the IP address to automatically launch the default browser of the PC with the IP address of the target camera filled in the address bar of the browser already.
-
Page 30: Using The Default Camera Ip Address
PC has to be configured to match the network segment of the camera. Manually adjust the IP address of the PC: In the following example, based on Windows 7, we will configure the IP address to 192.168.0.99 and set Subnet Mask to 255.255.255.0 by using the steps below: www.acti.com... - Page 31 In such case, please plug in only one camera at a time, and change its IP address by using the Web browser before plugging in the next one. This way, the Web browser will not be confused about two devices having the same IP address at the same time. www.acti.com...
-
Page 32: Access The Camera
When using Internet Explorer browser, the ActiveX control for video stream management will be downloaded from the camera directly – the user just has to accept the use of such control when prompted so. No other third party utilities are required to be installed in such case. www.acti.com... - Page 33 HTTP port of the camera is 80, which can be omitted from the address for convenience. Before logging in, you need to know the factory default Account and Password of the camera. Account: Admin Password: 123456 www.acti.com...
- Page 34 Copyright © 2016, ACTi Corporation All Rights Reserved 7F, No. 1, Alley 20, Lane 407, Sec. 2, Ti-Ding Blvd., Neihu District, Taipei, Taiwan 114, R.O.C. TEL : +886-2-2656-2588 FAX : +886-2-2656-2599 Email: sales@acti.com...
