Index Introduction ................4 Service Centre ................4 Intended use ................5 Package content ..............5 Required accessories .............5 Symbols explication ..............6 Safety notes ................6 Preparation before use ............8 Receiver’s binding ..............8 Transmitter presettings ............9 First use ................10 Initialization of the gyro in the receiver ........10 Installing the propellers ............11 First flight ................11 Technical Data ..............12...
3D Copter and first of all to safely control your models. If you experience any trouble during operation, take the instructions to help or ask your dealer or Graupner Service Centre. Due to technical changes, the information may be changed in this manual without prior notice.
Read through this entire manual before you attempt to assem- ble or use or use the 3D Copter. Graupner/SJ constantly works on the development of all pro- ducts; we reserve the right to change the item, its technology and equipment.
Symbols explication Always follow the information marked with the CAUTION WAR- NING symbol. The signal word WARNING indicates the potential for serious injury, the signal word CAUTION indicates possibility of lighter injuries. The NOTE is an important information that warns you about pos- sible material damages.
Page 7
Only use the components and spare parts that we recommend. Always use matching, original Graupner plug-in connections of the same design and material. Make sure that all of the plug-in connections are tight. When dis- connecting the plug-in connections, do not pull the cables.
Note: After you perceive your model, check if all components are inside the package and undamaged. Remove the battery from the model when transporting or when not in use. During transport protect the model and the transmit- ter from damages. During transport protect the model and the transmitter from damages.
Transmitter presettings In the transmitter it must be selected a free model memory, the model type must be “surface model“ and the channel 1 direction must be set so that in “motor off“ position the power indicator must show -100%. Setting of the flight-mode - attitude The flight mode must be set on channel 5.
First use Risk of injury by rotating propellers. The motors can run up when switching from the Attitude mode to the Rate mode. Hold the throttle stick over center position when switching. Assemble the propellers immediately before flight operations. Always start and land in Attitude mode. WARNING Pay attntion that the throttle travel is different in Rate mode.
Installing the propellers Risk of injury by rotating propellers when starting the motors. WARNING Always unplug the XT-60 connector to the LiPo battery before working on the propeller. Install the propellers as shown in the picture below. Pay atten- tion to install the proper propeller to each motor. The propeller rotation sense is written on the propeller (R/L)! The image repre- sents the copter seen from the top.
Race Copter are available in the Accessories area for the respective items on our website in the online shop: www.graupner. de Declaration of conformity Speed controller Ultra Control 20A 3D Graupner declares that the product is conform to EU norms. EMV 2004/108/EC: EN 61000-6-3: 2007+A1:2011; EN 61000- 6-1:2007 Voltage module + SBEC Graupner declares that the product is conform to EU norms.
The present construction or user manual is for informational pur- poses only and may be changed without prior notice. The cur- rent version can be found on the Internet at www.graupner.de on the relevant product page. In addition, the company Graupner has no responsibility or liability for any errors or inaccuracies that may appear in construction or operation manuals.
