  • Page 2: Table Of Contents

    Table of Contents Table of ConTenTS WaRnIng and SafeTy InfoRmaTIon FCC Caution ........4 FCC Interference Statement .

  • Page 3: Warning And Safety Information

    Warning and Safety Information FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.

  • Page 4: Fcc Radiation Exposure Statement

    FCC Radiation Exposure Statement This equipment complies with the FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 1.5 cm between the radiator and your body. Safety Precautions Be sure to observe the following warnings.

  • Page 5: Warnings

    for any restrictions or limitations before installing the extender cable on your windshield. • Do not install the FM Extender Cable where it may hinder the function of safety devices such as an airbag. Doing so may prevent the airbag from functioning properly in the event of an accident.

  • Page 6: Package Contents

    Package Contents The following items are included with your purchase of the SIRIUS Stiletto 2 Vehicle Kit. Unpack the kit carefully and make sure that everything shown is present. If anything is missing or damaged, or if the kit fails to operate properly, notify your dealer immediately. It is recom- mended that you retain the original carton and packing materials in case you need to ship your kit in the future.
  • Page 7 fm extender Cable fm extender Cable Package Contents Suction Cups (2) Suction Cups (2) Self adhesive Self adhesive Cable guides (3) Cable guides (3)

  • Page 8: Controls Vehicle Dock 9

    Controls Vehicle Dock Figure 1 and the table following identify and describe the buttons, connectors, and features of the vehicle dock. Direct Entry Tune/ Lock lock IR Remote Receiver Preset Buttons Jump jump FM OUT POWER figure 1 figure 1 Tune Preset tune...
  • Page 9 Vehicle dock button and Connector descriptions button/ action Connector In Tune Mode: Directly selects the channel indicted by the num- bers which were pressed Press 0 – 9 In Preset Mode: Selects presets 0 – 9 Displays the FM Frequency screen where the FM transmitter Press frequency can be selected, or an FM preset selected using the 0 –...

  • Page 10: Remote Control Reference Guide

    Remote Control Reference Guide Figure 2 and the table following identify and describe the buttons of the remote control. The remote control works when the Stiletto 2 is in the vehicle dock. Power Back Media Dial (CCW) Rewind Media Dial (CW) Options Rewind Love...
  • Page 11 button action Press Turns the Stiletto 2 On/Off Power Press Mutes (or un-mutes) the audio mute Pressing Up is equivalent to turning the Media Dial counter-clockwise Pressing Down is equivalent to turning the Media Dial clockwise Press If listening, displays channel or category list Up/down If in a list, menu, or prompt, scrolls to next or previous item Pressing Right is equivalent to Fast-Forward...
  • Page 12 Remote Control button descriptions Continued button action Cycles between the normal/near and car/far display mode, artist Press name, and song title when in the channel browsing mode display Pauses a broadcast Press or resumes playing Play/Pause a paused broadcast If listening, rewinds a broadcast to the previous song or show...
  • Page 13 Remote Control button descriptions Continued button action Saves the song or show if possible, or adds to the when song/show Press cannot be saved While recording, prompts to stop recording love Displays recording setup screen Hold While recording, prompts to stop recording –...

  • Page 14: Remote Control Battery Installation

    Remote Control button descriptions Continued button action Jumps to a preselected traffic/weather channel Press jump A second press returns to the previous channel or song/show Displays the FM Frequency screen where the FM transmitter Press frequency can be selected, or an FM preset selected using the 0–9 buttons Remote ContRol BatteRy InstallatIon To install the remote control battery, locate the battery drawer on the bottom edge.

  • Page 15: Installation

    Installation SIRIUS suggests professional installation of this product in your vehicle. Professional instal- lation provides an experienced technician to install this product in your vehicle, advice for selecting a suitable mounting location, installation of the antenna, and routing all the neces- sary wires and cables.
  • Page 16 Depending upon the mounting method you select, the mount should be assembled as described in one of the following two sections. In choosing a mounting location, be sure that position chosen will not block access to the Lock button on the right side of the vehicle dock. Console mount method (a) To assemble and mount the vehicle dock for the console mount method A as shown in Figure Attach the adhesive foot to the vehicle dock using the provided screws.
  • Page 17 Adhesive Mounting Vehicle Foot Bracket Dock figure 5 figure 5 Installation...
  • Page 18 Vent mount method (b) To assemble and mount the vehicle dock for the vent mount method B as shown in Figure 4: Assemble the vent mount clip as shown in Figure 6. Note that the lower arm may be at- tached in two different positions.
  • Page 19 Vehicle Vent Clip Dock Clip Arms figure 7 figure 7 Installation...

  • Page 20: Installing The Antenna

    Installing the Antenna The installation of the magnetic antenna consists of two installation steps: • Mounting the magnetic antenna and cover/tail on the vehicle • Routing the antenna cable through the vehicle to the SIRIUS radio or vehicle dock The following sections provide instructions for both installation steps. antenna mountIng The SIRIUS Magnetic Mount Vehicle Antenna has a strong magnetic mount designed to hold the antenna in place during normal driving conditions (highway/city).
  • Page 21 Sedan/Coupe Sedan/Coupe Follow this procedure to mount the antenna: Select an appropriate mounting position for your type of vehicle that has an unobstruct- ed area of 3 inches by 3 inches around the antenna. Attach the rubber cover/tail to the antenna, as shown in Figure 9, and press the antenna cable into the rubber cover/tail.
  • Page 22 Protective Material Double check that the location of the antenna and rubber cover/tail are correct, and continue to press firmly down on rubber cover/tail for another 30 seconds. At room temperature (68 degrees), maximum adhesion usually occurs within 72 hours. During this period, avoid car washes and other contact with the antenna and rubber antenna cable cover/tail.

  • Page 23: Cable Routing

    CaBle RoutIng When you have successfully mounted the antenna, you can begin the cable routing portion of the installation. Separate antenna cable routing procedures are provided for each type of vehicle: • Sedan/Coupe on page 24 • Pickup Truck on page 26 •...
  • Page 24 Follow these detailed cable installation instructions: Feed the cable from the antenna underneath the rubber molding around the rear window. Use a plastic putty knife or similar object to lift the rubber molding around the rear window and tuck the antenna cable underneath the molding. Route the antenna cable around and down the window to the lowest point.
  • Page 25 Pickup Truck antenna Cable Routing Procedure Figure 12 shows how the antenna cable should be routed from the antenna to your SIRIUS radio in a pickup truck. Follow these detailed cable installation instructions: Use a plastic putty knife or similar tool to lift the rubber molding around the windshield and tuck the antenna cable underneath it.
  • Page 26 as under the carpet, keeping it away from any vehicle pedals or controls. Secure the excess cable with wire ties. Bring the end of the cable out at the SIRIUS radio location. Leave yourself enough cable so you can easily connect it to the antenna connector of the SIRIUS radio or vehicle dock.
  • Page 27 front of the vehicle. Use a plastic putty knife to lift the plastic trim just enough to tuck the cable under underneath. Avoid side airbag locations on back pillars and above the doors. (Airbag locations are marked with “SRS” logos.) Be careful not to crimp or cut the cable.
  • Page 28 Follow these detailed cable installation instructions: Bring the cable from the antenna into the trunk at the front edge of the trunk lid. Keep any bends in the cable loose. Tape or tie the cable along the inside of the trunk lid to the trunk lid hinge strut.

  • Page 29: Connecting The Cigarette Lighter Adapter

    Connecting the Cigarette Lighter Adapter Connect the provided cigarette lighter adapter to the Power connection at the rear of the vehicle dock. (Figure 15) Power Do not use any other power adapter for the vehicle dock, or connect it directly to the vehicle’s power.

  • Page 30: Docking And Un-Docking The Stiletto 2

    Docking and Un-docking the Stiletto 2 When docking the Stiletto 2, be sure the Lock button of the vehicle dock is in the unlocked position. (Refer to Figure 1 on page 9 for the location of the Lock button.) Grasp the vehicle dock with your free hand and place the Stiletto 2 into the vehicle dock, as shown in Figure 16, and slide it down until it is fully seated.

  • Page 31: Maximizing Audio Quality From Your Stiletto 2 Radio

    Maximizing Audio Quality From Your Stiletto 2 Radio There are two primary ways to connect your SIRIUS radio to your vehicle radio: Wireless Connection or Direct Connection. The following sections will help you obtain the best perfor- mance. For the latest information go to http://www.sirius.com/vehicleinstallation. WIReless ConneCtIon Your SIRIUS radio contains an FM transmitter.
  • Page 32 to locate an FM channel that is not broadcasting in your area. If you use an FM channel that is being used by a local broadcaster, it will interfere with the performance of your SIRIUS radio. Once you have located an FM channel that is not broadcasting in your area, save it as a preset on your vehicle radio.
  • Page 33 Wireless audio Connection Using the fm extender Cable The FM Extender Antenna brings the FM signal transmitted from your SIRIUS radio into close proximity with your vehicle’s FM antenna to provide a strong FM signal for good reception. (Figure 17) If you are using a FM wireless connection to transmit the audio from your SIRIUS radio to your vehicle’s FM radio, using the FEA will provide an stronger FM signal with better audio quality from your SIRIUS radio.
  • Page 34 C. In-glass, in the rear windshield: Several strands of wires in the rear windshield glass, usu- ally near the top of the window. There is a difference between the rear window defroster wires found in many vehicles and the FM antenna. The rear window defroster wires have uniform spac- ing and all wires run from edge to edge in the glass while the FM antenna wires have uneven spacing, breaks in the wires, and some of the wires do not run from edge to edge in the glass.
  • Page 35 Step 2: Prepare the FEA for temporary installation Attach the suction cups to the antenna portion of the FEA in the positions shown in Figure 20. The antenna portion of the FEA is the relatively thinner section of the cable in between the bead and the arrow, and transmits the FM signal to your vehicle’s FM antenna.
  • Page 36 for vehicles with • Whip/aerial mounted on the front fender or hood • Whip/aerial mounted in the A-pillar of car frame Mount the FEA vertically on the front windshield at the edge of the glass, on the same side as the antenna (i.e.
  • Page 37 for vehicles with • In-glass, in the rear windshield • Whip/aerial mounted on rear part of roof FM ANTENNA DEFROSTER WIRES Mount the FEA horizontally along the top edge of the rear windshield. (Figure 4) For vehicles with the roof top antenna, center the FEA below the antenna whip. For vehicles with the in-glass antenna, the FEA should be directly over one of the FM antenna’s wires.
  • Page 38 for vehicles with an type fm antenna: • Whip/aerial mounted on the rear fender or trunk Mount the FEA vertically on the rear windshield at the edge of the glass, on the same side as the antenna (i.e. nearest to the antenna). (Figure 23) Clean the suction cup mounting areas with the alcohol swab.
  • Page 39 for vehicles with • Whip/aerial mounted on the front part of roof • In-glass, in the front windshield Alternate Mounting Location Tucked Behind Headliner Mount the FEA horizontally along the top edge of the front windshield or install it into the headliner of the vehicle just above the front windshield.
  • Page 40 for vehicles with an type fm antenna: • In-glass, in a rear side window If the in-glass antenna wires are vertical, mount the FEA vertically on the glass, directly over the FM radio antenna. If the in-glass antenna wires are horizontal, mount the FEA horizontally on the glass, directly over the FM radio antenna.

  • Page 41: Your Area

    Step 4: Connect the other end of the FEA into the FM OUT connector of your SIRIUS vehicle dock Plug the FM Extender Antenna into the FM OUT connector of the vehicle dock. (Figure 26) FM OUT From FM Extender Antenna Step 5: Find an FM channel which is not broadcasting in your area Turn off your SIRIUS radio.
  • Page 42 in your area, save it as a preset on your vehicle radio. This will become your SIRIUS preset. Step 6: Tune your SIRIUS radio to the same FM channel Turn on your SIRIUS radio. For plug and play radios, press and hold the Menu button until the FM Frequency screen is displayed.
  • Page 43 button on the remote control. For most SIRIUS radios you can also press the Menu but- ton and select Settings and then Audio Level and turn the volume down to zero. (Refer to the user guide which accompanied your SIRIUS radio for more detailed instructions.) Note, your SIRIUS radio is still on.
  • Page 44 REMOVE ADHESIVE BACKING FROM ARROW REMOVE BOTH SUCTION CUPS THIS THINNER PORTION OF THE FEA SHOULD BE TAUT WHEN THE FEA IS PERMANENTLY ADHERED Step 9: Route and hide the cable through the vehicle to your SIRIUS radio Hide most of the cable by properly routing the antenna cable to your SIRIUS radio. (Figure 31) Use the cable guides to hold the cable in place until it reaches the inner trim or moulding at the edge of the window.
  • Page 45 Tips for Identifying the fm antenna Correct identification of your vehicle’s FM antenna is a key to a successful installation. The preceding installation section already showed you the differing kinds of FM antennas found on vehicles, however, there are several types of antennas found on vehicles which you may at first believe to be the FM antenna but in reality they are not.
  • Page 46 Greater confusion may arise with whip type antennas. Figure 33 shows some whip type antennas which can be found on a vehicle’s front or rear roof, or on the rear windshield. Some of these antennas could be the FM antenna and some are not the FM antenna. Antennas with a short 2-4 inch stubby whip or protrusion are not FM antennas, while anten- nas with a whip length of 7 inches or longer are likely to be the FM antenna.

  • Page 47: Direct Connections

    DIReCt ConneCtIons A direct connection provides better audio performance than a wireless connection and removes the possibility of interference from local FM broadcasters. There are several ways to directly connect your Stiletto 2 which are explained in the following sections. Tip: Depending on the model of radio in your vehicle and your level of comfort with in-car Tip: Depending on the model of radio in your vehicle and your level of comfort with in-car installations, a direct connection may require professional installation assistance.
  • Page 48 Cassette adapter If your vehicle radio has a cassette player: Purchase a Cassette Adapter at your local electronics retailer. Connect the adapter between the LINE OUT on the vehicle dock (refer to Figure 1 on page 9), and the vehicle radio’s cassette slot. (Figure 36) note: Refer to the cassette adapter manufacturer’s guidelines for correct use.
  • Page 49 SIRIUS fm direct adapter If your vehicle radio does not have an “AUX IN” or “LINE IN” jack, the SIRIUS FM Direct Adap- tor provides a wired connection between your Stiletto 2 and your vehicle radio, eliminating the outside static and interference you sometimes experience when using a wireless FM connection. (Figure 37) Professional installation may be required.

  • Page 50: Subscribing To The Sirius Service

    Subscribing to the SIRIUS Service Before you can listen to the SIRIUS service, you need to activate your subscription. The Sti- letto 2 must be receiving the SIRIUS signal throughout the activation procedure. The Stiletto 2 has a built-in activation wizard which will guide you through the activation pro- cess.

  • Page 51: Operation

    Operation Battery Charging To charge the battery in your Stiletto 2 place the radio in the vehicle dock. When docked the battery will be charged. Presets Channel presets may be selected using the vehicle dock to tune to a channel by pushing the 0—9 buttons when the vehicle dock is in the preset mode.

  • Page 52: Direct Channel Tuning

    Direct Channel Tuning Channels may be tuned directly by entering the channel number using the 0—9 buttons on the vehicle dock when the vehicle dock is in the tune mode, or by using the remote. The Stiletto 2 must be in the Satellite Radio mode to select channels. To directly tune a channel: Press the Tune button on the vehicle dock.

  • Page 53: Jump Feature

    Jump Feature Jump button on the vehicle dock allows you to jump to a pre-selected traffic/weath- jump er report for your location. The Stiletto 2 must be in the Satellite Radio mode to use the jump feature. When the Jump button is pressed, the traffic/weather report will be tuned. (Figures 43 jump &...

  • Page 54: Auto Shutdown

    Auto Shutdown The auto shutdown feature will automatically turn your Stiletto 2 radio off after 4 hours if no buttons have been pressed. This feature will keep the battery in your vehicle from being dis- charged if the radio is inadvertently left on. The auto shutdown feature can be set by selecting from the Home screen, Settings Low Light Mode The low light mode feature will automatically reduce the brightness of the display when the...

  • Page 55: Troubleshooting

    Troubleshooting Symptom SIRIUS radio does not Blown fuse, or the vehicle dock does not have power or is not power on properly connected. Check the cigarette lighter adapter connection. Refer to the vehicle’s owners manual for the location of the vehicle’s fuse panel and check for a blown fuse.

  • Page 56: Optional Accessories

    Optional Accessories The following optional accessories are available for purchase from your SIRIUS retailer to maximize your SIRIUS Stiletto 2 experience: home Kit (model Slh2) The Stiletto 2 Home Kit is a compact home dock that provides everything you need to use the Stiletto 2 in your home or office. The sleek home dock provides a convenient way to charge your Stiletto 2’s battery along with an...

  • Page 57: Warranty

    Warranty 12 month Warranty SIRIUS Satellite Radio Inc. (the “Company”) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company’s option) without charge for parts and repair labor.

  • Page 58: Specifications

    Specifications Cigarette Lighter Adapter Fuse Requirement ......2A Slow Blow Cigarette Lighter Adapter Cable Length ........1.8m (6ft.) Cigarette Lighter Adapter Operating Temperature .

  • Page 59: Copyrights & Trademarks

    Copyrights & Trademarks © 2007 Sirius Satellite Radio Inc. All Rights Reserved. ® “SIRIUS”, the SIRIUS dog logo, channel names and logos are trademarks of Sirius Satellite Radio Inc. All Rights Reserved. OnStar is a registered trademark of OnStar Corporation. ™...

  • Page 60: Sirius Id

    SIRIUS ID Write down the SIRIUS ID (SID) of your Stiletto 2 in the space provided below. SID: _______________________________________ SIRIUS ID...
  • Page 62 SIRIUS Customer Service: 1-888-539-7474 customercare@sirius-radio.com SIRIUS Satellite Radio Inc. 1221 Avenue of the Americas New York, NY 10020 1-888-539-7474 http://www.sirius.com...
