Drive Assembly - Mantis compact compostumbler Assembly Instructions Manual

A. Slide the Grip onto the end of the Drive Handle.
B. Push the stem of the Grip Cap into the end of the
C. Secure the Grip Cap to the end of the Drive Handle with the #6 Screw.
Tighten the Screw until just snug. Note: The head of the Screw will be
in the hole of the Drive Handle, locking the Grip Cap in position.
A. Push the Drive Gear through the tube in the Drive
Support with the Gear on the inside of the Support.
C. Slide the Cotter Pin through the hole in the end

Drive Assembly

Drive Assembly
Drive Handle Assembly
1 Drive Handle (item 20)
g
1 Grip Cap (item 27)
g
1 #6 Screw (item 28)
g
Drive Handle, aligning the holes.
STEP 8:
Gear Drive Assembly
1 Drive Support (item 19)
g
1 Drive Gear (item 24)
g
1 Drive Handle Assembly (from step 7)
g
1 Cotter Pin (item 25)
g
B. Insert the bar of the Drive Handle through
of the Drive Handle bar.
D. Use pliers to bend the legs of the Cotter Pin
STEP 7:
Select:
1 Grip (item 26)
g
Select:
the Drive Gear.
to keep it in place.
