Siemens

Energy & Automation

Kit P/N - TGX:16152-665

This publication provides installation instructions to mount a Siemens SIPART

(single acting) on a Fisher GX valve actuator and to install the mechanical feedback linkage. Two typical

installations are shown below: Linkage P (solid pin) and Linkage U (U-channel). The two installations use

different feedback linkage components.

KIT INSTALLATION INSTRUCTION

Mounting a SIPART PS2 Valve Positioner on a

Fisher GX Valve Actuator

15900-766

Rev 2

December 2008

PS2 valve positioner

Page 1 Mounting a SIPART PS2 Valve Positioner on a Fisher GX Valve Actuator ® This publication provides installation instructions to mount a Siemens SIPART PS2 valve positioner (single acting) on a Fisher GX valve actuator and to install the mechanical feedback linkage. Two typical installations are shown below: Linkage P (solid pin) and Linkage U (U-channel).
Page 2 If desired, a small amount of thread locking solution can be placed on the setscrew threads. PS2: SIPART PS2 Electropneumatic Positioners for Linear and Rotary Actuators, P/N A5E00074631...
Page 3 15900-766 • Linkage U – 1) Place the feedback lever on the positioner input shaft and tighten the clamp screw. 2) Insert the threaded end of the feedback pin into the feedback lever slot and loosely secure the pin with the supplied nut and lockwasher. 5.
Page 4 Automation, Inc. or other supplier companies whose use by third parties for their own purposes could violate the rights of the owners. Siemens Energy & Automation, Inc. assumes no liability for errors or omissions in this document or for the application and use of information in this document. The information herein is subject to change without notice.
